SIGMATEK C-IPC 171 Manual

C-dias ipc with amd fusion g-t56n
Hide thumbs
Table of Contents

Advertisement

Quick Links

C-IPC 171
C-DIAS IPC
with AMD Fusion G-T56N
Date of creation: 27.07.2017
Version date: 04.11.2019
Article number: 01-450-171-E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-IPC 171 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIGMATEK C-IPC 171

Summary of Contents for SIGMATEK C-IPC 171

  • Page 1 C-IPC 171 C-DIAS IPC with AMD Fusion G-T56N Date of creation: 27.07.2017 Version date: 04.11.2019 Article number: 01-450-171-E...
  • Page 2 (print, photocopy, microfilm or in any other process) without the express permission. We reserve the right to make changes in the content without notice. The SIGMATEK GmbH & Co KG is not responsi- ble for technical or printing errors in the handbook and assumes no responsibility for damages that occur through...
  • Page 3 V1.1 interface. In addition, an expansion card with further interface connections is available. Compatibility Completely PC-compatible. The C-IPC works with a standard PC BIOS; no SIGMATEK- specific BIOS is therefore needed. LASAL is provided as the operating system. 04.11.2019 Page 1...

  • Page 4: Table Of Contents

    C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N Contents Technical Data ................ 4 Performance Data ................. 4 Standard Configuration ..............5 Electrical Requirements ............... 5 Miscellaneous ................6 Environmental Conditions ............6 Xilinx Version ................7 Post Codes ..................7 Mechanical Dimensions ............
  • Page 5 C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 CAN Bus Termination ..............25 RS485 ................... 26 USB Interface Connections ............27 DIAS Bus Termination ..............27 The DIAS Bus Connection ............27 Connecting DIAS Modules ............29 Buffer Battery ................ 30 Cooling ...................

  • Page 6: Technical Data

    C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N Technical Data Performance Data Processor AMD G-T56N Dual Core 1.65GHz Internal program memory 1x Compact Flash (1x 512-MByte card) (CompactFlash) Internal program memory (SRAM) 256 Kbytes (battery powered) Internal program memory (DDR-RAM)

  • Page 7: Standard Configuration

    Problems can arise if a control is connected to an IP network, which contains mod- ules that do not run on a SIGMATEK operating system. With such devices, Ethernet packets could be sent to the control with such a high frequency (i.e. broadcasts), that the high interrupt load could cause a real-time runtime error or runtime error.

  • Page 8: Miscellaneous

    être certifié par un NRTL (National Recognized Testing Laboratory, par exem- ple, UL). Miscellaneous Article number C-IPC 171 1 GB Fusion T56N 1 GB DDR3-RAM, 1x 512 MB CompactFlash 01-450-171 TC-IPC 171 1 GB Fusion T56N 1 GB DDR3-RAM, 1x 512 MB CompactFlash...

  • Page 9: Xilinx Version

    C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 Xilinx Version Directly after the C-IPC is turned on, the Xilinx version number is shown in the display. In display D1, 43 is shown and in display 41, the version number can be seen. This infor- mation can also be found on the identification label.

  • Page 10: Mechanical Dimensions

    C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N Mechanical Dimensions Page 8 04.11.2019...

  • Page 11: Connector Layout

    C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 Connector Layout 04.11.2019 Page 9...

  • Page 12: Connector Layout

    C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N Connector Layout X1 COM 1 (10-pin Weidmüller plug) Function n.c. X2 COM 2 (10-pin Weidmüller plug) Function RS232 Function RS422 Function RS485 RS422 TxD+ RS485 A RS422 TxD- RS485 B RS422 RxD+ n.c.
  • Page 13 C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 X4 CAN Bus Terminal (6-pin Weidmüller plug) Function CAN A = LOW CAN B = HIGH CAN A = LOW CAN B = HIGH n.c. X5 DIAS Bus (6-pin Weidmüller plug) Function...
  • Page 14 C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N X8 Ethernet (8-pin RJ45) Function n.c. n.c. n.c. n.c. X9 Video (RGB) Function green blue Vsync Hsync For using the X9 video output, it is necessary to either connect a display before the C-IPC is started or restart the C-IPC after a display has been connected.

  • Page 15: Applicable Connectors

    10-pin RM 2.54 Power: 2-pin Phoenix FK-MCP 1.5/2-ST-3.5 USV: 6-pin Phoenix FK-MCP 1.5/6-ST-3.5 The complete C-DIAS CKL 012 connector set with spring terminals is available from SIGMATEK under the article number 12-600-012. S-DVI Cable 0.3 m Art.No.: 05-950-003 Art.No.: 05-950-020 Art.No.: 05-950-030 Art.No.: 05-950-035...

  • Page 16: Bottom Connectors

    C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N Bottom Connectors X12 C-DIAS Bus Connector X13 DIAS Bus Connector Function MBUS+ MBUS- SBUS+ SBUS- DCOK 9 – 13: +5 V CAUTION! To connect the DIAS module to X13 of the C-IPC, a DIAS power module (power booster) between the C-IPC and DIAS module is required.

  • Page 17: Status Displays

    C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 Status Displays LED 1 Green DC OK Lights when the supply voltage is correct. LED 2 Green Lights when the program is running LED 3 Error Lights when an error occurs Button 1...

  • Page 18: Setting C-Ipc Parameters With The Set Button (Under Lasal Operating System Only)

    C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N Setting C-IPC Parameters with the SET Button (under LASAL operating system only) To enter the mode to change settings, press and hold the SET button while the C-IPC is booting When the following display appears The SET button can be released.
  • Page 19 C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 Gr ... graphics resolution 01 ... QVGA 320x240 02 ... VGA 640x480 03 ... SVGA 800x600 04 … XGA 1024x768 L1 … Lasal Online COMx interface number 01 ... COM1 02 ... COM2 L2 ..
  • Page 20 C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N I1, I2, I3, I4 IP Address I1.I2.I3.I4, hexadecimal 00-FF respectively S1, S2 ,SI3, S4 Subnet Mask SI1SI2.S3.S4, hexadecimal 00-FF respectively G1, G2, G3, G4 Gateway G1,G2.G3.G4, hexadecimal 00-FF respectively Page 18 04.11.2019...

  • Page 21: Design Layout

    C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 Design Layout The CPU module is placed on the left side of the C-DIAS module carrier. Front view with cover 04.11.2019 Page 19...
  • Page 22 C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N Rear view with cover Page 20 04.11.2019...
  • Page 23 C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 Front view without cover Battery 04.11.2019 Page 21...

  • Page 24: Exchanging The Compactflash Card

    C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N Exchanging the CompactFlash Card To exchange the CompactFlash card, remove the screws and carefully tilt the cover to the front as shown below. Next, remove the old flash card and insert the new card as shown. Finally, replace the cov- er and tighten the screws.

  • Page 25: Storage Media

    The CompactFlash card in the master slot is always the primary BOOT device. Storage Media It is recommended that only storage media provided by SIGMATEK (CompactFlash cards, microSD cards etc.) be used. The number of read and write actions have a significant influence on the lifespan of the storage media.

  • Page 26: Exchanging The Battery

    C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N Exchanging the Battery The battery can only be exchanged when the C-IPC is OFF! To exchange the battery, re- move the screws and carefully tilt the cover to the front as shown below.

  • Page 27: Can Bus Termination

    C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 CAN Bus Termination In a CAN bus system, both end modules must be terminated. This is necessary to avoid transmission errors caused by reflections in the line. Module1 Module 2 Module 3 Module n I.e.
  • Page 28 C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N RS485 • Because the RS485 requires a defined quiescent point, a pull-up and pull-down resistor is required in addition to the termination resistor. • The terminating resistors with 120 Ω must be placed on each end of the bus •...

  • Page 29: Usb Interface Connections

    C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 USB Interface Connections The C-IPC control panel has a USB interface. The terminal has a USB interface connection that can be used to connect various USB devices (keyboard, mouse, storage media, hubs, etc.) in LASAL.
  • Page 30 C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N • To connect the individual wires to the connector, the insulation must be removed and the exposed shielding shifted to the side. Only remove as much of the insulation and shielding as needed.

  • Page 31: Connecting Dias Modules

    C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 Connecting DIAS Modules The C-IPC can also be connected to DIAS modules. Here, 2 options are available: Connection over a DIC 121 The DIAS bus connection between the C-IPC and DIC 121 is a point-to-point connec- tion and must therefore be terminated on both sides.

  • Page 32: Buffer Battery

    C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N Buffer Battery The exchangeable buffer battery ensures that programs and data in the user memory (RAM) are preserved in the absence of a supply voltage. A lithium battery is installed at the manufacturer.

  • Page 33: Cooling

    C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 Cooling The terminal's power loss can reach up to 45 Watts. The built-in fan removes most of the generated heat. Also when mounted, heat dissipation must be ensured. At processor temperatures above the allowed limit, the C-IPC will shut down auto- matically! The C-IPC will only resume normal operation after a sufficient cooling period (1 minute).

  • Page 34: 10 Status And Error Messages

    C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N 10 Status and Error Messages Status and error messages are shown in the status test of the LASAL CLASS software. If the CPU has a status display, the status or error number is also show here as well.
  • Page 35 C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 WATCHDOG The program was interrupted via the Possible Causes: watchdog logic. User program interrupts blocked over a longer period of time (STI command forgotten) Programming error in a hardware interrupt. INB, OUTB, INW, OUTW instruc- tions used incorrectly.
  • Page 36 C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N STOP BRKPT The CPU was stopped by a breakpoint INFO in the program. CPU STOP The CPU was stopped by the program- INFO ming software. INT ERROR The CPU has triggered a false interrupt...
  • Page 37 OP INSTALLED The operating system has been rein- INFO stalled. OS TOO LONG The operating system cannot be loaded; Restart; report error to SIGMATEK. too little memory. NO OPERATING Boot loader message. Restart; report error to SIGMATEK. SYSTEM No operating system found in RAM.
  • Page 38 An error has occurred during a floating- ERROR point operation. DIAS-RISC-ERROR Error from the Intelligent DIAS Master. Restart; report error to SIGMATEK. INTERNAL ERROR An internal error has occurred; all appli- Restart; report error to SIGMATEK. cations are stopped. FILE ERROR An error has occurred during a file operation.
  • Page 39 C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 Solution: This depends on the cause S-DIAS ERROR A connection error with an S-DIAS Possible Causes: module has occurred. real network does not match the project S-DIAS client is defective Solution: analyze log file...
  • Page 40 C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N C_OK The CPU is ready for operation. C_UNKNOWN_CID An unknown object from a stand-alone or embedded object, or an unknown base class was detected. C_UNKNOWN_CONSTR The operating system class cannot be created; the operating system is proba- bly wrong.
  • Page 41 C-DIAS IPC WITH AMD FUSION G-T56N C-IPC 171 LSL SAVE LSL LOAD CONTINUE PRERUN The application is started. PRERESET The application is ended. CONNECTION BREAK 04.11.2019 Page 39...
  • Page 42 C-IPC 171 C-DIAS IPC WITH AMD FUSION G-T56N Documentation Changes Change date Affected Chapter Note page(s) 19.10.2017 1.3 Electrical Requirements Supply voltage 21.11.2017 5. Setting C-IPC Parameters Sentence for graphics resolution removed 15.03.2018 6.5 RS485 Chapter added 24.06.2019 1.4 Miscellaneous Variant -T added 04.11.2019...
