Inovonics E 4080 Series Quick Start Manual

For amazon web services mqtt
Hide thumbs

Advertisement

Quick Links

Download this manual
Tech note
E*4080 IP Gateway Amazon Web Services MQTT Quick Start

Advertisement

loading
Need help?

Need help?

Do you have a question about the E 4080 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Inovonics E 4080 Series

Summary of Contents for Inovonics E 4080 Series

  • Page 1 Tech note E*4080 IP Gateway Amazon Web Services MQTT Quick Start...

  • Page 2: Contact Information

    • Traffic allowed on the following ports:  Port 9000 (TCP for OTA upgrades)  Port 123 (UDP for NTP sync)  Port 8883 (standard MQTT port)  Port 443 (HTTPS) • USB flash drive. • A computer. 11/19/18 TN1114C © Inovonics, 2018 - www.inovonics.com...
  • Page 3 2. Select “Create” in the top right of the AWS IoT dashboard. 3. Select “Create a Single Thing.” 4. Give your thing a name • No other fields are required. 5. Select "Next." 6. Select "One-Click certificate creation." 11/19/18 TN1114C © Inovonics, 2018 - www.inovonics.com...
  • Page 4 • The thing has been created with AWS. 10. Navigate to the “Secure” tab and select “Policies.” Figure 3 Select “Policies” on the AWS IoT dashboard. 11. Select "Create." 12. Give your policy a name. 11/19/18 TN1114C © Inovonics, 2018 - www.inovonics.com...
  • Page 5 USB flash drive. • All of the files that need to be on the USB flash drive are shown in Figure 5. These include the configuration .yaml file, 11/19/18 TN1114C © Inovonics, 2018 - www.inovonics.com...
  • Page 6 USB flash drive. • private_key: This is the name of the private key placed on the USB flash drive. • client_id_prefix: This is the string for your client id to start with. 11/19/18 TN1114C © Inovonics, 2018 - www.inovonics.com...

  • Page 7: Test Connection

    USB flash drive to boot the IP gateway. The IP gateway should now be connected to AWS. • The orange connection light on the IP gateway should light and remain illuminated after booting completes. Test Connection 11/19/18 TN1114C © Inovonics, 2018 - www.inovonics.com...

  • Page 8: Change Settings

    MQTT, a message will be sent on your publish_conf_topic that shows the current state of each editable setting, including the most recent change. update-status can be: • Success: Configuration was updated successfully. 11/19/18 TN1114C © Inovonics, 2018 - www.inovonics.com...
  • Page 9 1. Select the “Act” tab on the AWS IoT dashboard and click “Create” to start a new rule. 2. Configure settings as desired. Following are the minimum settings required. Figure 8 Configure rule settings. 11/19/18 TN1114C © Inovonics, 2018 - www.inovonics.com...
  • Page 10 5. Set a Hash key value. 6. Select a role and update it. 7. Click “Add action.”After that, you can create the rule. 8. Check the AWS "Act" tab and ensure your rule is listed as enabled. 11/19/18 TN1114C © Inovonics, 2018 - www.inovonics.com...
  • Page 11 "status": { "stat1bit4": false, "tamper": true, "stat1bit0": false, "stat1bit1": false, "stat0bit1": false, "stat0bit0": false, "rapidTransmissionMode": false, "stat1bit5": false, "stat0bit7": false, "lowBattery": true, "shipping": false, "deltaTotalizer": false, "supervision": true, "stat1bit3": false, "stat1bit2": false, "reset": false 11/19/18 TN1114C © Inovonics, 2018 - www.inovonics.com...
  • Page 12 'level': 15, 'margin': 15 'payload': { 'name': 'RepeaterApplicationPayload', 'repeaterPayload': { 'name': 'RepeaterStatusWithBroadcastRepeater', 'pti': 0, 'status': { 'tamper': True, 'noChange': True, 'neighborListAssigned': False, 'limitedScanningRemotes': False, 'lowBattery': False, 'onlyOneNeighbor': False, 'jammed': False, 'stat0bit0': False, 'layer': 0, 11/19/18 TN1114C © Inovonics, 2018 - www.inovonics.com...
  • Page 13 'stat0bit2': False, 'lossOfLinePower': False, 'reset': False, 'statusAck': False 'mcb': 65 'network-type': 'echostream', 'market': 'Repeater', 'txid': 8086348, 'timestamp': '2018-06-26T14:54:59.190750' 11/19/18 TN1114C © Inovonics, 2018 - www.inovonics.com...
