- Page 1 THANKS FOR PURCHASING OUR PRODUCT EWELDM253 Inverter MIG/MMA Semi-auto ARC Welding Machine Advanced Product Operation Manual (Read the manual carefully before installation ,operation and maintenance)
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS Follow these precautions carefully. Improper use of any welder can result in injury or death. 1. ONLY CONNECT WELDER TO A POWER SOURCE FOR WHICH IT WAS DESIGEND. The specification plate on the welder lists this information. When welding outdoors only use an extension cord intended for such use. - Page 3 Prolegomenon We do very appreciated for your selecting our products. This kind of welding power Model EWELDM253 is taken foreign advanced technology to develop and manufacture the new generation inverter integrated controlling Semi-auto MIG/MAG ARC and MMA Welding machine. It can be composed the EWELDM253 MIG/MMA multi function Welding system equipped with wire feeder and welding gun .It has many characteristic such as easy Arc starting .good Arc springiness...
- Page 4 1. Main characteristic and suitable range This kind of welding power Model EWELDM253 is taken foreign advanced technology to develop and manufacture the new generation inverter integrated controlling Semi-auto MIG/MAG Arc welding machine.It makes use of the import key parts such as Siemens IGBT module of Germany,alloy magnetic core and the resume diode module of America.
-
Page 5: Main Technical Data
★ Adjusting the arc thrusting: Control the splash and steady arc. ★ Strong resistance for the fluctuate of the electricity 2.Main technical Data : MODEL EWELDM253 Voltage 1xAC220V 50Hz/60Hz INPUT Rated Input current 47.5A Rated Input power 11KVA No-load Voltage... - Page 6 ,control the welding splash and the steady Arc. Normally,. If the thrusting is low ,the arc is soft and splash . If the thrusting is high,the arc is strong and high splash. Use the arc thrusting continuously by the control knob on the front panel of EWELDM253.
- Page 7 3.3 Function of arc drawing back ★ Reduce the welding criterion at the end of welding line in order to fill the short coming of welding end. ★ Change the knob on the welding gun ,you may get two kinds of welding criterions to fit for different position and different thickness.Turn on the switch of :"Arc drawing back".the power now has the function of Arc drawing back.The voltage adjusting is used by the current knob on the front panel.
- Page 8 4. Indicating and warning on the EWELDM253 control panel 4.1 Indicating and adjusting EWELDM253 4.1.1 Start current /Welding current/Peak(arc force)/End current Display meter The current indicating meter on the front panel indicates the actual welding current during the ， welding indicates the preset current during no welding.
- Page 9 4.1.5 unit V-- unit of voltage S -- unit of burnbacktime, pre& post flow time % -- unit of pulse width Hz-- unit of pulse freq. 4.1.6 Memory chanel LED Display 0 to 9 @MMA or CO or PMIG or DPMIG ，...
- Page 10 5.Safe and installation caution Read the safe caution before installation and operation .It come down to the high voltage electricity,electric Arc and high temperature splash.So keep the safe regulation ,operate the machine properly,avoid the danger of electricity and high temperature arc. ★...
- Page 11 Black wire - Live TO LOAD WIRE SPOOL: 1. Loosen and remove the hand nut by turning it counter-clockwise. – Green/Yellow Wire Earth ( 2. Align the locating pin with the hole on the wire spool (if present). 3. Slide spool onto the shaft. Make sure wire is unwinding from the bottom of the spool. Ground) 4.
-
Page 12: Side View
front panel. SIDE VIEW welding gun working piece front panel. SIDE VIEW welding gun NO GAS working piece SYNERGIC AND BASIC MIG OPERATION Synergic vs. Manual Setup and Operation How Synergic MIG operates: The Synergic function of the SYN. MIG component allows the user to only need to use the wire feed speed control to make the unit operate. - Page 13 How to setup the Synergic and Manual functions: 1. Turn unit on. Wait for it to go through the power up cycle. 2. Select the SYN MIG icon with the Process Selector button. the syn. LED is lighting. 3. Select the wire diameter of the wire being used. so that the wire will not jam or birds nest while feeding.
- Page 14 7. Operatings ★ "ON" and "OFF" indicating switch on the real panel. ★ Preset the welding voltage ,welding current(wire speed).and Arc force.Diagram 4 ★ Confirm the specification of the wire feed hose ★ Confirm the specification of nib base .It affects the extended length of the wire . ★...
-
Page 15: Maintenance
8. working elements Diagram for the EWELDM253 working elements.Digram9 working piece rectifier rectifier inverter input filter filter circuit wire feeder welding gun input output IGBT control circuit panel indictor Digram 9 Input AC220V,rectifier and filter it into 620VDC. Control the IGBT by PWM+PFM,inverter the 620VDC to 20KHZ AC. - Page 16 10.Troubles and Remedy Troubles and remedy and remedy are as the form 10 as following Troubles Cause Remedy 1.Fan not works 1.the fan line lose 1.Connect the line properly 2.Fan breakage 2.Change the fan 1.the power line lose 1.Check the power,Connect the line 2.No indicating on 2.Change it( φ...
- Page 17 11.Transportation,storage and environment conditions ★ The package (Wooden cases or cartons)of the manufacturer is suitable for air ,sea ,railway and highway (three class more) transportation.. ★ Pay attention to the indication on the package during the transportation. ★ the environment conditions ℃...
-
Page 18: Packing List
─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ Name of product: MIG/MAG / MMA Semi-auto ARC Welding Machine Type of product: EWELDM253 Packing Test results of this welder fulfils_____________ _________technical requirements and its release from the works is granted. - Page 19 Do not touch electrically live parts or Keep flammable materials away. Wear eye, ear and body protection. WARNING electrode with skin or wet clothing. Insulate yourself from work and ground. Spanish No toque las partes o los electrodos Mantenga el material combustible Protéjase los ojos, los oídos y el AVISO DE bajo carga con la piel o ropa moja-...
- Page 20 Keep your head out of fumes. Turn power off before servicing. Do not operate with panel open or Use ventilation or exhaust to guards off. WARNING remove fumes from breathing zone. Spanish Los humos fuera de la zona de res- Desconectar el cable de ali- No operar con panel abierto o AVISO DE...
