- Page 1 Triton Blue TR 101 User manual...
- Page 2 Manual TR 101 Triton Blue USER MANUAL TR-101 Read these instructions carefully before use. After reading them. Keep them in a safe place for future reference. They will prove useful later when further information is needed or the air conditioner is not working properly.
- Page 3 Manual TR 101 Triton Blue (2) Back chart: 3. Operation 1) MUSIC CONTROL (Sound Activated) DON’T connect the DMX cable and Set the ADDRESS (DIP Switch) on the back of the equipment as shown in Graph (a) below (Set the tenth switch as ON). Power on SUPER-1, now it is under the control of MUSIC.
- Page 4 Manual TR 101 Triton Blue Channel 001 Mode Channel 002 Patterns Channel 003 Rotation Channel 004 X-axes Rolling Channel 005 Y-axes Rolling Channel 006 X/Y Direction Moving Channel 007 Drawing Speed Channel 008 Scanning Speed 4) Multi-units Connected: Connect the first SUPER-1 with a DMX-512 controller and then connect it with other equipments one after another with the DMX-512 cables.
- Page 5 Manual TR 101 Triton Blue B) If the ADDRESS is set as shown in Graph (f), the first and fourth BIT is set on. The amount of the set-on BIT value is 9, so the first controlled channel is channel 009. The description of each...
- Page 6 Manual TR 101 Triton Blue 5. Maintain Maintenance should be performed every 15-day period, by using a sponge which is dipped with alcohol, rather than wet cloth or other chemical liquid, to clean the mirror, Warning: Power must be disconnected before maintenance or repair. Do not look at the light source directly.
