WIRELESS VEHICLE DETECTION AT ITS BEST!!!
5
1
Page(s)
Content
2-4
Wireless Drive-Alert Control Panel/Receiver Installation Guide
5-7
Wireless Drive-Alert Sensor/Transmitter Installation Guide
8
Additional Installation Tips
9
Hooking Up Other Equipment to your Control Panel/Receiver
10
Options for Long Range Installations
11
Accessories: Chimes, Lights, Repeaters, Timer-Controls, Outlets, etc.
12
Supplemental Specifications
13
Troubleshooting
14
Technical Support Information and Warranty
3
2
3
800-473-0213
~
THE BASICS
1) A sensor(s) detect(s) a vehicle entering
monitored area(s)
2) A control panel up to 1000 feet away receives
a signal from the sensor and triggers an alert
inside the home or business (booster antenna
4
increases range to 1/2-mile)
MORE OPTIONS
3) Add remote plug-in and/or portable chimes in
the front room, basement, upstairs, back yard,
by the pool, etc.
4) Add a timer controlled light kit to turn on
outdoor and indoor lights to warn strangers or
welcome friends
5) Activate video surveillance to record activity
and display the driveway on a monitor
6) Activate signs, gates, alarm panels or other
equipment
7) Add a repeater to send the signal another 1000'
to trigger additional alerts in out buildings, or a
booster-antenna to increase range up to 1/2-mile.
info@mierproducts.com
DA-600
DA-605P or DA-605B
~
www.mierproducts.com
600/605-Q12017
Advertisement
Related Manuals for Mier products DA-600
Summary of Contents for Mier products DA-600
- Page 1 Page(s) Content Wireless Drive-Alert Control Panel/Receiver Installation Guide Wireless Drive-Alert Sensor/Transmitter Installation Guide Additional Installation Tips DA-600 Hooking Up Other Equipment to your Control Panel/Receiver Options for Long Range Installations Accessories: Chimes, Lights, Repeaters, Timer-Controls, Outlets, etc. Supplemental Specifications DA-605P or DA-605B...
- Page 2 FIRST, test the equipment by: 1. Plugging in the Control Panel 2. Turning the Whistle Switch ON if you have a DA-600, or plugging in DA-078 Chime if you have a DA-605P, or putting batteries in the DA-080 if you have a DA-605B 3.
- Page 3 The DA-600 Drive-Alert has an internal piezo electric whistle inside the Control Panel as the audible-alert. The whistle may be switched off if desired. The whistle and the whistle switch can be seen on the top of the DA-600 Control Panel.
- Page 4 Wireless Drive-Alert Control Panel Installation Guide Under the Control Panel/Receiver cover you will see the electrical board (FIGURE 1). A Power LED GREEN indicates that the power is on and that the internal 1 Amp Fuse is okay. An Alert LED RED indicates the Sensor/Transmitter has detected a vehicle, the Sensor/Transmitter has been moved, or their is another disturbance in the magnetic field around the Sensor/Transmitter.
- Page 5 Wireless Drive-Alert Sensor Installation Guide DA-610TO Mier Products’ Wireless Drive-Alert Sensor/Transmitters detect the changes in the magnetic field (movement of metal) within 14’ in every direction. Therefore, they will not false-alarm from animals, wind, rain, etc. The Transmitter electrical boards are epoxied and also encased in a durable, weather-sealed, NEMA 4X housing for worry free weather and corrosion protection.
- Page 6 Wireless Drive-Alert Sensor Installation Guide The Sensor portion of a DA-610TO, DA-611TO or DA-612TO contain the sensing and transmitting electronics and should to be placed in the area you wish to monitor moving vehicles or assets. The detection threshold is set by a sensitivity control (See FIGURE 2: Right Hand/Middle) on the transmitter circuit board.
- Page 7 Make certain the alert annunciators are ON: • On DA-600 models containing a piezo whistle, slide Whistle Switch on the Control Panel to the ON position • On DA-605 models using wireless chimes, plug-in or install batteries in the wireless chimes Place Sensor within 3 feet of the edge of the driveway, or the equipment/area to be monitored.
- Page 8 Wireless Drive-Alert Installation Guide Additional Tips for Reliable Installation: • DO NOT mount the Control Panel/Receiver within 10 feet of a wireless modem, cell phone, or cordless phone • DO NOT put the Control Panel/Receiver in a basement unless it is a Long-Range Control/Panel Receiver with a DA-660 Long- Range Antenna •...
- Page 9 Figure 4 shows a detailed description of the contacts available. The terminal block, TB1, provides a convenient wire connection point for external device control and test points. NOTE: All external devices must be rated at 24 VDC FIGURE 4 shows the DA-600 and DA-605 terminals on the bottom of the Control Panel/Receiver green PCB •...
- Page 10 Control Panel/Receivers (DA-100CP, DA-600CP, DA-605CP) up to an additonal 1000 feet away. If a site has multiple buildings and/or locations where an alert is desired, add a DA-REPEATER to a DA-600 or DA-605 Control Panel/Receiver, and then add DA-100CP Chimes with Volume Control (shown below) in those other buildings.
- Page 11 Window or business applications! • The DA-500LKA is a set of Form C Dry Contacts that can be attached to the DA-600, DA-605 or DA-500 Control Panels. • The DA-052V Whistle with Volume Control – is used with the DA-600 when a second whistle is desired (hard-wired installation) •...
- Page 12 DA-066MP WIRELESS CHIME TRANSMITTER: The DA-066MP Remote Chime Transmitter is attached to a DA-605 Control Panel and is an option on the DA-600 or DA-500. It is a 315 Mhz transmitter with ASK/ OOK encoded signal. It is activated by a relay closure on a Drive-Alert, or by pushing the button on the case. It requires 15-30 volts DC on the RED and BLACK wires.
- Page 13 Wireless Drive-Alert Troubleshooting Trees Step 1 - Check to make sure the Power Light is on. If not, replace the internal 1A fuse, or send to Mier Products for repair. Step 2 - Make sure the Control Panel is mounted in an above ground area where its antenna can receive a good signal from the Sensor/Transmitter, and make sure the Sensor/Transmitter is in a position free where it can send a signal freely.
- Page 14 Mier Products, Inc.’s Limited Warranty Program for Drive-Alert Series of Vehicle Detection Systems and Drive-Alert Accessories protects the original owner for one year from the date of purchase against defects in original parts or workmanship. Mier Products, Inc. agrees to repair or replace parts (Mier’s option) that are deemed defective by our Quality Control Team, without charge for parts or labor, if the defective unit is returned prepaid to Mier Products, Inc., Kokomo, IN, within the one-year period.
