Detect vehicles and monitor areas and assets at your...
...Home
THE BASICS
A sensor detects any vehicles entering a monitored area
It also detects assets moving such as trailers, RVs, tractors, boats, or
anything a sensor is attached to.
A control panel receives a signal from the sensor and triggers an
internal chime with volume control
DA-100
The DA-100 is a COMPLETE KIT which includes:
•
One DA-100CP Control Panel receiver with built-in chime, volume
control, and three choices of chimes
•
One DA-611TO Sensor/Transmitter with 50 feet of cable
•
Zoning Control to monitor up to three different areas and provides a
different tone for each. (NOTE: additional Sensor/Transmitters are
needed for each additional area to monitor)
DA-611TO
Sensor/Transmitter
DA-100 Drive-Alert
now with new Zone Control and Alert Tone Selection features
...Farm
...Workshop
DA-100CP
Control Panel
...Remote Buildings
...Equipment
MORE OPTIONS
The DA-100 allows you to monitor up to three separate areas with
one receiver! You may monitor multiple areas, lanes, driveways by
adding additional DA-610TO or DA-611TO sensor/transmitters.
You may also add alert chimes to multiple buildings by installing
DA-100CP control panels in those areas.
Use these systems in conjunction with Mier's other wireless Drive-
Alert systems such as DA-600s or DA-605s.
Optional set-up shown here includes:
•
One DA-100CP Control Panel receiver
•
One DA-610TO Sensor/Transmitter with the
sensor inside the transmitter box
DA-610TO
Sensor/Transmitter
...Drive-Up Window
DA-100CP
Control Panel
PN: MP0105326
Advertisement
Table of Contents
Related Manuals for Mier products DA-100
Summary of Contents for Mier products DA-100
- Page 1 MORE OPTIONS A sensor detects any vehicles entering a monitored area The DA-100 allows you to monitor up to three separate areas with one receiver! You may monitor multiple areas, lanes, driveways by It also detects assets moving such as trailers, RVs, tractors, boats, or adding additional DA-610TO or DA-611TO sensor/transmitters.
- Page 2 NOTE: Some early models of the DA-611TO may not have a power switch or red LED. These units become active as soon as the batteries are installed. Reinstall the cover being careful not to over tighten the screws which could crack the cover. Turn off the DA-100 Control Panel after confirming that it chimed in Step 4. See next page for EASY Installation Instructions...
- Page 3 DA-100 Installation Manual page 3 EASY Installation is often completed in under 30 minutes! AFTER BENCH TESTS FROM PAGE 2 ARE COMPLETED: install the DA-611TO Sensor/Transmitter, or the entire DA-610TO, within 3 feet of the drive or area you wish to monitor, parallel to the traffic for best performance. (See Figure 1 and Examples below) The sensor should be at least 30 feet from power lines and 40-50 feet away from street traffic if possible.
- Page 4 “B”. Mier Products offers the FREE service of using satellite imaging like the photo shown, and talking with the installer to determine which equipment needs to be installed in each location to satisfy the customer’s need.
