WIRELESS VEHICLE DETECTION AT ITS BEST!!!
DA-700 Instruction Manual
Page(s)
Content
2
Product Features
3
Quick Installation Page
4-6
Sensor & Transmitter Comprehensive Installation
7
Control Panel/Receiver Comprehensive Details of Functions
8
Control Panel/Receiver Programming the Timers or the Mute Function
9-11
Control Panel/Receiver Hooking Up Chimes, Lights and Accessories
12
Accessories
13
Long Range Installation Options
14
Supplemental Information
15-16
Troubleshooting
17
Technical Support Information and Warranty
3
2
3
THE BASICS
1) A sensor(s) detect(s) a vehicle entering monitored
area(s) . Up to 3 may be used in different areas.
2) A control panel up to 1000 feet away receives a
signal from the sensor and triggers an alert inside
the home or business (booster antenna increases
4
range to 3/4-mile)
MORE OPTIONS
3) Add remote plug-in chimes in the front room,
basement, upstairs, back yard, by the pool, or in
other buildings
4) Set the DA-700s Timer Relay to turn on outdoor
and indoor lights to warn strangers or welcome
friends
5) Activate video surveillance to record activity and
display the driveway on a monitor
6) Activate signs, gates, alarm panels, etc.
7) Add a repeater to send the signal another 1000
feet to trigger alerts in other buildings, or add a
DA-660 booster-antenna for buildings up to 3/4-
mile away
8) Monitor up to three different driveways and/or
areas with different chimes or signals for each
DA-700
DA-700-611
MP010770
Advertisement
Related Manuals for Mier products DA-700
Summary of Contents for Mier products DA-700
- Page 1 DA-660 booster-antenna for buildings up to 3/4- mile away 8) Monitor up to three different driveways and/or areas with different chimes or signals for each DA-700 Instruction Manual Page(s) Content Product Features Quick Installation Page Sensor &...
- Page 2 Normal reception to 1000 feet, or 3/4-mile if using the DA-660 Booster Antenna (see Options For Long Range Installations page) • Use of an unlimited Wireless Sensor/Transmitters (DA-610TO, DA-611TO, DA-612TO) with a DA-700 Control Panel/Receiver • Compatible with Mier Accessories detailed in this manual (See Accessories Page), as well as many after-market accessories •...
- Page 3 First, BENCH TEST both Pieces in the Same Room: 1. Plug in the white DA-700 Control Panel/Receiver (shown top left, above), and turn the Chime On/Off/Volume Knob all the way up (the knob is on top). Keep the door open for testing.
- Page 4 Wireless Drive-Alert Sensor/Transmitter Installation Guide DA-610TO Mier Products’ Wireless Drive-Alert Sensor/Transmitters detect changes in the magnetic field (movement of metal) within 14 feet in every direction, based on a sedan traveling 5mph. They will not false-alarm from animals, wind, rain, etc. The Transmitter electrical boards are epoxied and also encased in a durable, weather-sealed, NEMA 4X box for worry free weather and corrosion protection.
- Page 5 Wireless Drive-Alert Sensor/Transmitter Installation Guide DA-610TO DA-611TO DA-612TO The Sensor/Probe portion of a DA-610TO, DA-611TO or DA-612TO senses the vehicle and should to be placed less than 3 feet of Zone/area you wish to monitor moving vehicles or assets (the closer the better). The Transmitter portion contains the electronics inside the black box.
- Page 6 If more than one Zone is to be monitored, place jumpers on the Zone Pins on the electrical board in the black box to active them, AND pull the jumper off of the JP3 Jumper Pin inside the white DA-700 or DA-100 Control Panel. The Drive-Alert will give a different Chime tone for each Zone monitored.
- Page 7 DA-700 and DA-700-611 Control Panel Installation Guide Under the DA-700 Control Panel/Receiver cover you will see the electrical board (shown below). A Power LED GREEN indicates that the power is on and that the internal solid-state 1 Amp Fuse is okay.
- Page 8 DA-700 Control Panel Programming the Accessory Timer or the Mute/Delay The Mute/Delay and Accessory Timer are programmed the same way. Both timers are monitored by either relays or logic values. Both retain their programs if the unit is powered off and on, or if there is a power outage. They can be reprogrammed or erased.
- Page 9 The terminal block provides convenient wire connection for external device control and tests. All contacts are dry, rated low voltage/low current, so DO NOT APPLY 120VAC to any of these contacts. Attach your wiring to the terminal block and push it up into the terminal block receptacle of the DA-700. +24 Gnd...
- Page 10 DA-700 Control Panel Hooking Up Other Equipment Connecting a DA-066MP Wireless Chime Transmitter, for DA-078 Chimes, to a DA-700 Control Panel +24 Gnd Timer Relay All Det Relay Gnd +12 +10,0 Mute P/B DC or Relay Relay Relay or DC...
- Page 11 Remote Whistle hooks Contact. Wire from terminal #2 or #17/Ground to -12VDC or 124VDC Max 10 Amp Circuit Contact. up this way too. Connecting a DA-700 Control Panel to a DA-505 or DA-505W Timer Control Unit DA-505 DA-505W +24 Gnd...
- Page 12 Drive-up Window or business applications! • The DA-500LKA is a set of Form C Dry Contacts that can be attached to the DA-700 or DA-500 Control Panels. • The DA-052V Whistle with Volume Control – is used with the DA-700 when a second hard-wired whistle is desired.
- Page 13 This antenna is used to increase the standard reception distance of 1000-feet, to up to 3/4-mile from the Sensor/Transmitter to the Control Panel/Receiver. Simply unscrew the standard antenna on the DA-700 Control Panel or DA-100 Control Panel and 75ohm coaxial cable, RG6, to the F Connectors on the Control Panel and the DA-660 Reception Booster Antenna.
-
Page 14: Supplemental Specifications
DA-066MP Wireless Chime Transmitter (optional accessory): The DA-066MP Remote Chime Transmitter is attached to a DA-700 Control Panel and is an option on the DA-500. It is a 315 Mhz transmitter with ASK/OOK encoded signal. It is activated by a relay closure on a Drive-Alert, or by pushing the button on the case. It requires 15-30 volts DC on the RED and BLACK wires. - Page 15 Check to make sure the Power Light is on. If not, unplug and wait 5 minutes, then power up again to see if the internal solid- state 1A fuse cleared the fault and reset. If not, and the power light still does not come on, send to Mier Products for repair.
- Page 16 DA-700 and DA-700-611 Troubleshooting continued DA-700 and DA-700-611 Troubleshooting continued False Alarms No Detection or Existing Existing Intermittent Detection Check the sensor/transmitter Check the batteries, Power is Check POWER and LO BATT placement - 50’ (min) away from LEDs on the control panel.
- Page 17 Mier Products, Inc.’s Limited Warranty Program for Drive-Alert Series of Vehicle Detection Systems and Drive-Alert Accessories protects the original owner for one year from the date of purchase against defects in original parts or workmanship. Mier Products, Inc. agrees to repair or replace parts (Mier’s option) that are deemed defective by our Quality Control Team, without charge for parts or labor, if the defective unit is returned prepaid to Mier Products, Inc., Kokomo, IN, within the one-year period.
- Page 18 Mier Product’s Drive-Alert Equipment Installed and Part Numbers: _________________________________________________________ ________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________ Name/Contact Information of where the Mier Products’ Drive-Alert Equipment was purchased if different than Installation Company: _______________________________________________________________________________________________________________ Other manufacturer’s and Accessories/Equipment Installed and Part Numbers: _______________________________________________ ________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________...
- Page 19 NOTES...
