Elektroapparate AG
Language
ENA Micro 1
ENA Micro 9 OT
IMPRESSA A5 OT
Author: Patrik Studer
Date:
Rev. G:
06.10.2011
20.02.2014
Disassembling manual
ENA Micro line / IMPRESSA A line
EN
Checked:
Rev. B:
Rev. C:
21.03.2012
19.09.2012
ENA Micro 5
IMPRESSA A9 OT TFT
Approved:
Docu.-name:
L:\Geräte\Linie_A\A5_OT\Schulungsunterlagen\E\Demontag
e_ENA_Micro_EN.docx
Rev. D:
Rev. E:
14.11.2012
27.03.2013
Technical Support
Demontage_ENA_Micro_EN.docx
Rev. F:
Page 1/26
17.09.2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENA Micro Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jura ENA Micro Series

Summary of Contents for Jura ENA Micro Series

  • Page 1 Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language ENA Micro 1 ENA Micro 5 ENA Micro 9 OT IMPRESSA A5 OT IMPRESSA A9 OT TFT Author: Patrik Studer Checked: Approved: Docu.-name: Demontage_ENA_Micro_EN.docx L:\Geräte\Linie_A\A5_OT\Schulungsunterlagen\E\Demontag e_ENA_Micro_EN.docx Date: Rev.

  • Page 2: Table Of Contents

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language Table of contents: Disassembling (example ENA Micro 9 OT): ................3 Service cover / side panel 1 generation: ................... 4 Service cover / side panel 2 generation and IMPRESSA A line: ..........6 Disassembling of further components: ..................

  • Page 3: Disassembling (Example Ena Micro 9 Ot)

    When exchanging components, it is very important to put back the cable wiring the same way as it was before !  Remove water tank, grounds container, aroma preservation lid, powder funnel 1. Turn JURA emblem anticlockwise 2. Unscrew the Oval screw (e.g. with a suction disc).

  • Page 4: Service Cover / Side Panel

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language Service cover / side panel 1 generation: 5. Push with a small screw driver (no. 0) or alike 6. Remove cover of the service plug simultaneous in both immersions of the interlock (between both lateral- and front parts).
  • Page 5 Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language 9. Position of the lower barb of the lateral part 10. Position of the upper barb of the lateral part Author: Patrik Studer Checked: Approved: Docu.-name: Demontage_ENA_Micro_EN.docx L:\Geräte\Linie_A\A5_OT\Schulungsunterlagen\E\Demontag e_ENA_Micro_EN.docx...

  • Page 6: Nd Generation And Impressa A Line

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language Service cover / side panel 2 generation and IMPRESSA A line: 11. Insert a metal ruler (thickness max. 0.5 mm) on 12. Sliding-in a small screw driver to release upper the front side and slide it to the left barb and keep in position (pay attention to not scratch the control panel)

  • Page 7: Disassembling Of Further Components

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language 13. Sliding-in a small screw driver to release lower 14. On both sides, pull outside the lateral part with barb (slot under appliance base) and keep in your thumb (or similar aid).
  • Page 8 Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language 17. Unscrew 3x TORX 15 to remove the brewing unit 18. Remove hose 19. Unscrew 2x TORX 15. 20. Unscrew 2x TORX 15. Remove control panel (display module). Remove the front shield upwards.
  • Page 9 Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language 23. Remove coffee spout 24. Release 3x snap-locks of the bottom of the coffee (Press interlocks on both sides) spout and remove the lid 25. Unscrew 2x TORX 10 of the top of the coffee 26.
  • Page 10 Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language 29. Unscrew TORX 15 of the hose shield 30. Remove hose shield. Hose connection to brewing unit. 31. Pull out the fluid system support. 32. Remove the shield upwards Detach the shield of the fluid system support.
  • Page 11 Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language 35. Unscrew 2x TORX 15 (front side). 36. Release 4x snap-locks Remove top case cover upwards. 37. Remove thermoblock cover 38. Unscrew 3x TORX 15 (See also cable wiring chapter 6 ) 39.
  • Page 12 Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language 41. Pull down carefully the snap-lock of the multi- 42. Pull out the pump of the pump support valve support and remove the multi-valve 43. Pull with a small screw driver into the slot to 44.
  • Page 13 Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language 47. View: 48. Variation 2: Tank base with inner distributing collar Release with screw driver snap-lock of the tank base. 49. View: 50. Release snap-lock of the coffee powder funnel Tank base / bayonet lock.
  • Page 14 Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language 53. Press snap-lock and slide the Zero Energy Switch 54. Pull down the 2x snap-locks and slide down the (ZES) ZES to remove 55. Unscrew 2x TORX 15 and press snap-lock to 56.

  • Page 15: Coffee Spout Ena Micro 5

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language Coffee spout ENA Micro 5: 57. Coffee spout lock 58. Insert ENA/Micro spout remover Art.Nr. 71398 59. View: Rotating coffee spout detached 60. Remove cover (3x snap-locks) with a suction disc upwards 61.
  • Page 16 Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language 63. View: 2x bonnet cams 64. Remove coffee distributor towards you REED contact Magnet 65. View: Coffee distributor 66. To reinsert parts, hold thorn and snap-in rotating coffee spout and then all other parts Author: Patrik Studer Checked:...

  • Page 17: Coffee Spout Impressa A5 Ot/A9 Ot Tft

    ENA Micro line / IMPRESSA A line Language Coffee spout IMPRESSA A5 OT/A9 OT TFT: 67. Press coffee spout and release it downwards Turn JURA emblem anticlockwise (e.g. with a suction disc). Rather pulling than pushing when removing. 69. Unscrew TORX 10 entfernen...
  • Page 18 Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language 73. View: Hot water spout View: Combi spout detached Author: Patrik Studer Checked: Approved: Docu.-name: Demontage_ENA_Micro_EN.docx L:\Geräte\Linie_A\A5_OT\Schulungsunterlagen\E\Demontag e_ENA_Micro_EN.docx Date: Rev. G: Rev. B: Rev. C: Rev. D: Rev.

  • Page 19: View Appliance, Right

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language View appliance, Right: Grinder (Zero Energy Switch Membrane controller Pump Power-Logic print Multi-valve Encoder Heater TB2010 Brewing unit motor Drain motor Author: Patrik Studer Checked: Approved: Docu.-name: Demontage_ENA_Micro_EN.docx L:\Geräte\Linie_A\A5_OT\Schulungsunterlagen\E\Demontag...

  • Page 20: View Appliance, Left

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language View appliance, Left: Brewing unit (BU) Flowmeter Author: Patrik Studer Checked: Approved: Docu.-name: Demontage_ENA_Micro_EN.docx L:\Geräte\Linie_A\A5_OT\Schulungsunterlagen\E\Demontag e_ENA_Micro_EN.docx Date: Rev. G: Rev. B: Rev. C: Rev. D: Rev. E: Rev.

  • Page 21: View Appliance, Top

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language View appliance, Top: Service-plug Aroma lid detector Control panel View appliance, Back: Transformer Connector mains feeder Suppression filter Author: Patrik Studer Checked: Approved: Docu.-name: Demontage_ENA_Micro_EN.docx L:\Geräte\Linie_A\A5_OT\Schulungsunterlagen\E\Demontag e_ENA_Micro_EN.docx Date: Rev.

  • Page 22: View Power-Logic Print, Cable Wiring (Ena Micro 9 One Touch)

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language View power-logic print, cable wiring (ENA Micro 9 One Touch): TM5A to ZES TM6 to mains L TM5 to supp. filter L Inp. TM6A to ZES TM2 to heater N CP2D to grounds switch CP5 to control panel...

  • Page 23: Block Schematic Ena Micro 9 Ot/Impressa A5 Ot

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language Block schematic ENA Micro 9 OT/IMPRESSA A5 OT: Blockschema IMPRESSA A9 OT TFT: Author: Patrik Studer Checked: Approved: Docu.-name: Demontage_ENA_Micro_EN.docx L:\Geräte\Linie_A\A5_OT\Schulungsunterlagen\E\Demontag e_ENA_Micro_EN.docx Date: Rev. G: Rev. B: Rev.

  • Page 24: Block Schematic Ena Micro 1/5

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language Block schematic ENA Micro 1/5: Author: Patrik Studer Checked: Approved: Docu.-name: Demontage_ENA_Micro_EN.docx L:\Geräte\Linie_A\A5_OT\Schulungsunterlagen\E\Demontag e_ENA_Micro_EN.docx Date: Rev. G: Rev. B: Rev. C: Rev. D: Rev. E: Rev. F: Page 24/26 06.10.2011 20.02.2014...

  • Page 25: View Multi-Valve Connections Ena Micro 9 Ot/ Impressa A5 Ot/A9 Ot Tft

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language View multi-valve connections ENA Micro 9 OT/ IMPRESSA A5 OT/A9 OT TFT: 1. Direction to Fluid terminal outlet (Hot water) 2. Direction to Fluid terminal outlet (Steam) 3.

  • Page 26: Fluid System Ena Micro 1/5

    Disassembling manual Technical Support Elektroapparate AG ENA Micro line / IMPRESSA A line Language Fluid system ENA Micro 1/5: Author: Patrik Studer Checked: Approved: Docu.-name: Demontage_ENA_Micro_EN.docx L:\Geräte\Linie_A\A5_OT\Schulungsunterlagen\E\Demontag e_ENA_Micro_EN.docx Date: Rev. G: Rev. B: Rev. C: Rev. D: Rev. E: Rev. F: Page 26/26 06.10.2011 20.02.2014...
