USER GUIDE
PXIe-416x Remote Sense
Resistor Accessory
Sense Resistor Accessory for the PXIe-4162/PXIe-4163
This document explains how to install and use the PXIe-416x Remote Sense Resistor
Accessory with a PXIe-4162/PXIe-4163 source measure unit (SMU)-collectively referred to
as the PXIe-416x-and includes PXIe-416x Remote Sense Resistor Accessory specifications.
The PXIe-416x Remote Sense Resistor Accessory is used to modify the behavior of the
PXIe-4162/PXIe-4163 SMU when the module is used in remote sense mode.
Read this document and the documents listed in the Additional Resources section about
installation, configuration, and operation of this product before you install, configure, operate,
or maintain this product. Users are required to familiarize themselves with installation and
wiring instructions in addition to requirements of all applicable codes, laws, and standards.
Caution
the product in a manner not specified can damage the product and compromise the
built-in safety protection. Return damaged products to NI for repair.
Attention
documentation d'utilisation. L'utilisation du produit de toute autre façon que celle
spécifiée risque de l'endommager et de compromettre la protection de sécurité
intégrée. Renvoyez les produits endommagés à NI pour réparation.
Notice
This device is intended for use only with the PXIe-4162/PXIe-4163 SMU.
For more information about the PXIe-4162/PXIe-4163, refer to ni.com/manuals.
Contents
Icons.......................................................................................................................................... 2
Getting Started with the PXIe-4162/4163 Remote Sense Resistor Accessory......................... 2
Kit Contents and Other Equipment................................................................................... 2
Installing the PXIe-416x Remote Sense Resistor Accessory............................................2
PXIe-416x Remote Sense Resistor Accessory Specifications.................................................. 5
Definitions.........................................................................................................................6
Derating.............................................................................................................................6
Physical............................................................................................................................. 6
Observe all instructions and cautions in the user documentation. Using
Suivez toutes les instructions et respectez toutes les mises en garde de la
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NI PXIe-416 Series
Summary of Contents for NI PXIe-416 Series
-
Page 1: Table Of Contents
Observe all instructions and cautions in the user documentation. Using the product in a manner not specified can damage the product and compromise the built-in safety protection. Return damaged products to NI for repair. Attention Suivez toutes les instructions et respectez toutes les mises en garde de la documentation d'utilisation. -
Page 2: Icons
PXIe-416x. If you use the PXIe-416x Remote Sense Resistor Accessory with a PXIe-4162/PXIe-4163, refer to your module specifications at ni.com/manuals for pinout and signal information during installation. 2 | ni.com | PXIe-416x Remote Sense Resistor Accessory User Guide... - Page 3 Figure 1. Installed PXIe-416x Remote Sense Resistor Accessory Connect a compatible cable or connectivity accessory to the PXIe-416x Remote Sense Resistor Accessory. Refer to your cable or accessory documentation for more information. Refer to the following pinouts for your respective module to make the appropriate connections for your application.
- Page 4 CH9 Output HI CH10 Output HI CH9 Sense LO CH9 Sense HI CH10 Sense HI CH11 Guard CH10 Guard CH11 Output HI CH11 Sense LO CH10 Sense LO CH11 Sense HI 4 | ni.com | PXIe-416x Remote Sense Resistor Accessory User Guide...
-
Page 5: Pxie-416X Remote Sense Resistor Accessory Specifications
The PXIe-4162 is a 12-Channel, ±24 V, 100 mA SMU, and the PXIe-4163 is a 24-Channel, ±24 V, 50 mA SMU. Refer to the module specifications at ni.com/manuals more information. PXIe-416x Remote Sense Resistor Accessory User Guide | © National Instruments | 5... -
Page 6: Definitions
8 mm × 72 mm × 16 mm (2.9 in. × 2.8 in. × 0.6 in.) Weight 89 g (3.15 oz) Environmental Guidelines Notice This model is intended for use in indoor applications only. 6 | ni.com | PXIe-416x Remote Sense Resistor Accessory User Guide... -
Page 7: Compliance And Standards
For additional environmental information, refer to the Commitment to the Environment web page at ni.com/environment. This page contains the environmental regulations and directives with which NI complies, as well as other environmental information not included in this document. Waste Electrical and Electronic Equipment (WEEE) -
Page 8: Additional Resources
This product may also be subject to additional license requirements of other countries' regulations. Additionally, this product may also require export licensing before being returned to NI. The issuance of a Return Material Authorization (RMA) by NI does not constitute export authorization. -
Page 9: Worldwide Support And Services
Worldwide Support and Services The NI website is your complete resource for technical support. At ni.com/support, you have access to everything from troubleshooting and application development self-help resources to email and phone assistance from NI Application Engineers. Visit ni.com/services for information about the services NI offers. - Page 10 . You can find patents.txt ni.com/patents information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer to the Export Compliance Information at for the NI global trade compliance policy and how ni.com/legal/export-compliance...
