Generac Power Systems PWRcell Installation Manual page 19

Figure 4-5
Figure 4-5. Mounting Bracket (1 of 2)
Figure 4-6
Figure 4-6. Mounting Bracket (2 of 2)
DANGER
Electrocution. Put the Generac PWRcell Inverter into
Safety Shutdown before installing wiring. If there are any
other batteries connected to REbus, toggle their front
Battery Disconnect switches to OFF. Failure to do so
will result in death or serious injury.
WARNING
Equipment damage. Connect only to REbus-compatible
devices. Never connect to any other power source.
Connecting to other power sources could result in
equipment damage.
WARNING
Equipment damage. Never connect REbus conductors to
ground. Connecting Rebus condutors to ground could
result in equipment damage.
•
•
•
•
•
.
(000606)
(000598)
(000607)
Table 4-1
