Sine Wave Plus Long
AC Conduit Box
Owner's Guide
ACCB-L
ACCB-L-L1
Owner's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACCB-L and is the answer not in the manual?

Questions and answers

Related Manuals for Xantrex ACCB-L

Summary of Contents for Xantrex ACCB-L

  • Page 1 Sine Wave Plus Long AC Conduit Box Owner’s Guide ACCB-L ACCB-L-L1 Owner’s Guide...
  • Page 3 Sine Wave Plus Long AC Conduit Owner’s Guide...
  • Page 4 About Xantrex Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with products from 50 watt mobile units to one MW utility-scale systems for wind, solar, batteries, fuel cells, microturbines, and backup power applications in both grid-connected and stand-alone systems. Xantrex products include inverters, battery chargers, programmable power supplies, and variable speed drives that convert, supply, control, clean, and distribute electrical power.

  • Page 5: About This Guide

    Wave Plus Long AC Conduit Box. Chapter 3, “Operation” describes the different modes and operation of the AC Bypass Switch(es) on the ACCB-L-L1, or for the second AC Bypass Switch (ACCB-L-L2) if installed. Warranty and product information is provided at the end of the guide.

  • Page 6: Abbreviations And Acronyms

    ACCB-L-L2 ACCB-L2-PCK ISC-S Related Information You can find more information about Xantrex Technology Inc. as well as its products and services at www.xantrex.com. These notes describe things which are important for you to know, but not as Alternating Current AC Conduit Box Long (with ground bar only)

  • Page 7: Important Safety Instructions

    WARNING This chapter contains important safety and operating instructions for the Sine Wave Plus Long AC Conduit Box (ACCB-L and ACCB-L-L1) and the ACCB-L-L2 (ACCB-L2-PCK add-on package). Read and keep this Sine Wave Plus AC Conduit Box Long Owner’s Guide for future reference.

  • Page 8: Explosive Gas Precautions

    Safety Explosive gas precautions 1. Working in the vicinity of lead-acid batteries is dangerous. Batteries generate explosive gases during normal operation. Therefore, you must read this guide and follow the instructions exactly before installing the Long AC Conduit Box. 2. To reduce the risk of battery explosion, follow these instructions and those published by the battery manufacturer and the manufacturer of the equipment in which the battery is installed.

  • Page 9: Table Of Contents

    Wiring - General - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–14 Accessing the AC Input/Output Terminal Block in the ACCB-L-L1 - - - - - - - - - - - - - - - - - 2–14 Wire Sizes and Disconnect Requirements - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–15...
  • Page 10 Contents 3 Operation The AC Bypass Switch - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–2 Operating the AC Bypass Switch - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–2 Normal Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–3 Bypass Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–3...
  • Page 11 Figure 2-9 Installing the ACCB-L on the Backplate - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–12 Figure 2-10 Installing the ACCB-L to the SW Plus Inverter on Plywood- - - - - - - - - - - - - - - - - - - 2–13...
  • Page 13 ACCB-L-L2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–4...

  • Page 15: Introduction

    Introduction Chapter 1, “Introduction” provides a basic introduction to the design and purpose of the Sine Wave Plus Long AC Conduit Box (ACCB-L). The following topics are covered in this chapter. For this topic: “Introduction” “Specifications” “AC Bypass Switch Assembly”...

  • Page 16: Figure 1-1 The Sine Wave Plus Accb-L Basic

    ACCB-L-L2. The ACCB-L contains a ground bar only and provides no wiring. The ACCB-L-L1 includes a ground wire attached to the ground bar, an AC bypass switch (for a single AC input source) and input/output wiring attached to the AC Input/output Terminals, a Neutral bar with neutral wire installed, and an isolated bar.

  • Page 17: Figure 1-2 The Sine Wave Plus Long Ac Conduit Box (Accb-L-L1, And Accb-L-L2)

    One length white N EUTRAL One length green G ROUND Figure 1-2 The Sine Wave Plus Long AC Conduit Box (ACCB-L-L1, and ACCB-L-L2) 973-0031-01-01 Rev A ACCB-L-L2 is created by installing the ACCB-L2-PCK to the ACCB-L-L1. ACCB-L2-PCK consists of the...

  • Page 18: Specifications

    Specifications The following table contains the specifications for the ACCB-L, the ACCB-L-L1, and the ACCB-L-L2. The ACCB-L-L2 is not available pre-built from the factory, but is created by field-installing an ACCB-L2-PCK into a ACCB-L-L1 model. Table 1-1 Operational and Environmental Specifications for the ACCB-L, ACCB-L-L1, and ACCB-L-L2...

  • Page 19: Figure 1-3 Accb-L Dimensions (Not To Scale)

    Certified by CSA to UL 1741- 2001 (First Edition) and CSA C22.2 No. 107.1-01 a.The ACCB-L-L2 is not available pre-built from the factory, but is created by field-installing an ACCB-L2-PCK into a ACCB-L-L1 model. Outside Figure 1-3 ACCB-L Dimensions (not to scale)

  • Page 20: Ac Bypass Switch Assembly

    Introduction AC Bypass Switch Assembly The AC bypass switch assembly in the ACCB-L-L1 is designed for 120 Vac applications and comes with two 60-amp circuit breakers (one SPST and one DPST). The breaker pair is equipped with a lockout rocker that allows only one breaker to be ON at any given time.

  • Page 21: Blockoff Plates

    Blockoff Plates Upper and Lower Blockoff Plates are included to enclose the open portions of the Long AC Conduit Box chassis. In the event that an inverter is removed for service, the Blockoff Plates secure the enclosure to prevent accidental contact with any AC power within the Long AC Conduit Box.
  • Page 22 1–8...

  • Page 23: Installation

    Installation Chapter 2, “Installation” provides installation and wiring instructions for the Sine Wave Plus Long AC Conduit Box. The following topics are covered in this chapter. For this topic: “Preparing for the Installation” “Configuration Planning” “Installing or Removing the Blockoff Plates” “Mounting”...

  • Page 24: Preparing For The Installation

    Installation Preparing for the Installation Important: cautionary markings located in this guide and in your inverter manual. Code Compliance Governing installation codes vary depending on the location and type of installation. Electrical installations must meet local and national wiring codes. Installations of this equipment should only be performed by skilled personnel such as qualified electricians and Certified Renewable Energy (RE) System Installers.

  • Page 25: Configuration Planning

    Configuration Planning Wiring scenarios will depend upon the configuration of the overall system (i.e., Off Grid or On Grid, and output requirements). Pre-installation and mounting instructions apply to all configurations. Follow the instructions from page 2–4 to page 2–19 for all installations. After the pre-installation procedures have been completed, select the wiring scenario that applies to your configuration.

  • Page 26: Pre-Installation

    Use flexible conduit. • When mounting the components such as the ACCB-L or DCCB-L next to the inverter, bias the mounting screws away from the inverter. This will allow "sliding" room within the mounting holes, so that the ends can slide apart without being removed from their mounted position.

  • Page 27: Ventilation Requirements

    Ventilation Requirements Minimum clearance for ventilation around the Long AC Conduit Box must be at least 12 inches (305 mm) at the top, the ends, and in front. This clearance is needed to prevent recirculating hot air from the inverter’s exhaust (DC side) from going back into the inverter’s intake (AC side).

  • Page 28: Removing And Replacing The Cover

    Installation Removing and Replacing the Cover Remove the top cover to install additional breakers and to connect the AC wiring of the Long AC Conduit Box to the Sine Wave Plus Inverter. Follow the diagram below to locate and remove, or replace, the appropriate screws and washers on the cover of the Long AC Conduit Box.

  • Page 29: Installing Or Removing The Blockoff Plates

    Be sure to disconnect all DC and AC power before removing the inverter and installing the blockoff plates. Align the holes on the Blockoff Plate behind the holes provided from the inside of the ACCB-L chassis. Figure 2-4 The Blockoff Plate on the Long AC Conduit Box 973-0031-01-01 Rev A Pre-Installation Secure with the eight 6x32 phillips screws provided.

  • Page 30: Knockout Preparation

    Square D™ filler plates (QOFP) may be used to refill a knockout panel if the knockout is no longer used or removed in error. 2–8 If larger knockouts are required in the Long AC Conduit Box, an Slots for ACCB-L Cover Tabs 3/4" and 1" (19 mm and 25 mm)

  • Page 31: Figure 2-6 Knockouts Locations

    Outside wall of ACCB-L 3/4 and 1" Dual-Knockouts (x2) 2" Knockout Accessory Wiring Pass-thru slots (x2) 3/4" and 1" Dual-Knockouts (x6 ea) 2" Knockout (x1 ea) 2" Knockout (x1 ea) 1/2" Knockouts (x3 ea) 3/4" and 1" Dual-Knockouts (x6 ea)

  • Page 32: Installing Additional Breakers

    DIN Rail End Clamp Figure 2-7 Installing Additional Breakers on the DIN Rail If creating an ACCB-L-L2 using the ACCB-L2-PCK add-on package, install the second AC Bypass Switch to the right of the factory-installed AC Bypass Switch. See the instructions provided with the package. Ensure the DIN Rail End clamp is tight against the last breaker installed.

  • Page 33: Mounting

    Wave Plus inverter. However, the SW Plus inverter can weigh up to 136 pounds (62 kg). The ACCB-L weighs up to 27 lbs (12.2 kg). Ensure the supporting surface is strong enough to hold twice the total weight being installed. Remember to include the weight of any other accessory, such as the DC Conduit Box, when considering the strength of the supporting surface.

  • Page 34: Figure 2-9 Installing The Accb-L On The Backplate

    Conduit Box to the back plate with 4 ¼-20 phillips screws (provided). Figure 2-9 Installing the ACCB-L on the Backplate 2–12 Ensure the mounting hooks are visible through the holes in the mounting Be sure the mounting hooks are visible in the mounting rail holes.

  • Page 35: Mounting On Plywood

    (top and bottom) away from the inverter for easier servicing if necessary Figure 2-10 Installing the ACCB-L to the SW Plus Inverter on Plywood 973-0031-01-01 Rev A Ensure that the factory-installed cables in the Long AC Conduit Box are Mounting Align Mounting Rails 2–13...

  • Page 36: Wiring - General

    Installation Wiring - General The ACCB-L comes with a ground bar only. The ACCB-L-L1 is pre-wired at the factory and ready for connection to one Sine Wave Plus Inverter/Charger. The factory-installed wires are labeled to assist with the installation procedure.

  • Page 37: Wire Sizes And Disconnect Requirements

    Wire Sizes and Disconnect Requirements The AC Input/Output Terminal block in the ACCB-L-L1 accept wires sized #2/0 to 14 AWG. The ground bar in both models has nine holes and accepts #4 to 14 AWG wires. The AC Bus Bar (for neutral and hot connections) has dual sizes. The smaller nine holes accept #6 to 14 AWG wire and the larger two holes accept #1/0 to 14 AWG.

  • Page 38: Figure 2-11 Accb-L Approved Internal Components

    SX-6 (x2) Service Crimps AC Input/Output Terminals Marathon P/Ns: • 1323572 (3 pole) • 1320572 (1 pole) or equivalent Figure 2-11 ACCB-L Approved Internal Components 2–16 IMPORTANT: Always use approved wiring per NEC/CEC. AC Bus Bar (for Neutral) Xantrex P/N: •...

  • Page 39: Figure 2-12 Accb-L-L1 Internal Components (Factory Installed)

    Ground Bar AC Bus Bar (Neutral) AC Bypass Switch Assembly AC Input/Output Terminals Figure 2-12 ACCB-L-L1 Internal Components (Factory installed) 973-0031-01-01 Rev A Wiring - General AC Bus Bar (L1 H Wire - Connects to the ROUND SW Plus Inverter G...

  • Page 40: Figure 2-13 Accb-L-L1 Internal Components With The Optional Accb-L2-Pkg Installed

    Installation Figure 2-13 ACCB-L-L1 Internal Components with the Optional ACCB-L2-PKG Installed 2–18 Optional Field-installed, AC Bus Bar (L2 H Factory-installed G ROUND SW Plus Inverter #1 G ROUND Field-installed G Wire - Connects to the SW ROUND Plus Inverter #2 G...

  • Page 41: Wiring For Off-Grid Applications

    Xantrex certified dealer. (See www.xantrexREdealer.com). Single Inverter Configurations (120 Vac) The following illustration shows the complete wiring for the ACCB-L-L1 and SW Plus Inverter in an off-grid configuration. This illustration includes the use of a separate AC Distribution Panel.

  • Page 42: Figure 2-15 Wiring An Off-Grid Application Using A Single Inverter (No Sub Panel)

    Installation The following illustration shows the complete wiring for the ACCB-L-L1 and SW Plus Inverter in an off-grid configuration. This illustration includes the use of field-installed circuit breakers in the ACCB-L-L1 for AC distribution, instead of using a separate sub panel.

  • Page 43: Step-Down Configurations (240 Vac To 120 Vac)

    Step-down Configurations (240 Vac to 120 Vac) The following illustration shows the complete wiring for the ACCB-L-L1, TX Autotransformer, and a SW Plus Inverter for a Step-down Configuration to use a 240 Vac-Only Generator. Figure 2-16 Wiring an Off-grid Application Using a Single Inverter and TX Autotransformer in a Step-...

  • Page 44: Figure 2-17 Wiring An Off-Grid Application Using A Single Inverter And Tx Autotransformer For A Step-Down Configuration (No Sub Panel)

    The following illustration shows the complete wiring for the ACCB-L-L1, TX Autotransformer, and a SW Plus Inverter for a Step-down Configuration to use a 240 Vac-Only Generator. This configuration uses the ACCB-L-L1 as the sub panel. Figure 2-17 Wiring an Off-grid Application Using a Single Inverter and TX Autotransformer for a Step- Down Configuration (No Sub Panel) 2–22...

  • Page 45: Step-Up Configuration (Deep Well Pump) (120 Vac To 240 Vac)

    Step-up Configuration (Deep Well Pump) (120 Vac to 240 Vac) The following illustration shows the complete wiring for the ACCB-L-L1, TX Autotransformer, and a SW Plus Inverter for a Step-up Configuration to provide power for a 240 Vac Load. Figure 2-18 Wiring an Off-grid Application Using a Single Inverter and TX Autotransformer for a Step-...

  • Page 46: Dual Inverter Configurations (120 Vac And 240 Vac)

    Dual Inverter Configurations (120 Vac and 240 Vac) The following illustration shows the complete wiring for the ACCB-L-L2 (ACCB-L-L1 with ACCB-L2-PCK installed) and dual SW Plus Inverters in an off-grid application. In this configuration, the generator’s output (L1 and L2) is connected to the AC Bypass breakers, then to the SW Plus input and output.

  • Page 47: Wiring For On-Grid Applications

    Xantrex certified dealer (See www.xantrexREdealer.com). Single Inverter Configurations (120 Vac) The following illustration shows the complete wiring for the ACCB-L-L1 and SW Plus Inverter in an on-grid configuration. This diagram also includes the use of a generator disconnect breaker in the ACCB-L-L1.

  • Page 48: Figure 2-21 Wiring An On-Grid Application Using A Single Inverter (No Sub Panel)

    Installation The following illustration shows the complete wiring for the ACCB-L-L1 and SW Plus Inverter in an on-grid configuration. This diagram includes the use of a generator disconnect breaker and load breakers in the ACCB-L-L1. Figure 2-21 Wiring an On-grid Application Using a Single Inverter (No Sub Panel) 2–26...

  • Page 49: Step-Up Configurations (Utility Backup) (120 Vac To 240 Vac)

    Step-up Configurations (Utility Backup) (120 Vac to 240 Vac) The following illustration shows the complete wiring for the ACCB-L-L1, TX Autotransformer, and a SW Plus Inverter for a Step-up Configuration to provide power for a 240 Vac Load. Figure 2-22 Wiring an On-grid Application Using a Single Inverter and TX Autotransformer for a Step-...

  • Page 50: Dual Inverter Configurations (120 Vac And 240 Vac)

    Dual Inverter Configurations (120 Vac and 240 Vac) The following illustration shows the complete wiring for the ACCB-L-L2 (ACCB-L-L1 with ACCB-L2-PCKinstalled) and dual SW Plus Inverters in an on- grid application. In this configuration, the utility grid is connected to the AC Bypass Breakers, then to the SW Plus input and output.

  • Page 51: Additional Accessory Wiring

    Additional Accessory Wiring If you have any of the following accessories connected (or to be connected) to your inverter, then you will also need to pass their connecting cables through the Long AC Conduit Box to the AC side of the inverter: •...

  • Page 52: Figure 2-25 Accessory Wiring For Dual-Inverter Configurations

    Installation See "IMPORTANT" note in Figure 2-24. Inverter Stacking Cable - Series (ISC-S) Figure 2-25 Accessory Wiring for Dual-Inverter Configurations 2–30 973-0031-01-01 Rev A...

  • Page 53: Operation

    Operation Chapter 3, “Operation” describes the different modes and operation of the AC Bypass Switch(es) on the ACCB-L-L1, or for the second AC Bypass Switch (ACCB-L-L2) if installed. The following topics are covered in this chapter. For this topic: “The AC Bypass Switch”...

  • Page 54: The Ac Bypass Switch

    Operation The AC Bypass Switch During normal operation (Figure 3-2 on page 3–3), AC power passes from the single external AC source (generator or grid) through the inverter to the AC loads. The inverter monitors the incoming power and uses this power to keep the batteries charged.

  • Page 55: Normal Operation

    Normal Operation External AC power passes to the AC Bypass Switch through the inverter to power the load (Figure 3-2). In this configuration, power passes from the inverter, through the AC Bypass Switch, to the connected load. When external AC power is not available, power from the external DC source is used by the inverter to power the AC loads.

  • Page 56: Ac Input/Output Off

    Operation AC Input/Output Off No power to the load or inverter (Figure 3-4). In this configuration, power from both the external sources of AC and the inverter is removed from the loads. This allows the inverter that is connected to the AC Bypass breaker to be removed for service.

  • Page 57: Warranty And Return Information

    The dated dealer invoice or purchase receipt showing original equipment manufacturer (OEM) status, or • The dated invoice or purchase receipt showing the product exchanged under warranty 973-0031-01-01 Rev A This Limited Warranty is provided by Xantrex Technology, Inc. ("Xantrex") In any warranty claim, dated proof of purchase must accompany the WA–1...
  • Page 58 Warranty and Return What does this warranty not cover? product or costs related to the removal, installation, or troubleshooting of the customer's electrical systems. This warranty does not apply to and Xantrex will not be responsible for any defect in or damage to: a) the product if it has been misused, neglected, improperly installed, physically damaged or altered, either inter- nally or externally, or damaged from improper use or use in an unsuitable environment;...

  • Page 59: Return Material Authorization Policy

    Include the following: • The RMA number supplied by Xantrex Technology, Inc. clearly marked on the outside of the box. • A return address where the unit can be shipped. Post office boxes are not acceptable.

  • Page 60: Information About Your System

    Warranty and Return Information About Your System As soon as you open your Sine Wave Plus Long AC Conduit Box package, record the following information and be sure to keep your proof of purchase. Serial Number Purchased From Purchase Date If you need to contact Customer Service, please record the following details before calling.
  • Page 61 Index abbreviations and acronyms 1–6 AC Bypass Switch Assembly AC conduit box - Long (ACCB-L) 1–2 introduction 1–4 specifications 1–2 AC disconnect breakers 2–10 AC load breakers 2–29 additional accessory wiring additional breakers in the ACCB-L Auxiliary Load Module (ALM), wiring for 1–7...

  • Page 62: Index

    Index 2–2 tools required for installation 2–5 Ventilation Requirements warranty WA–3 out of warranty service WA–1 terms and conditions wiring 2–29 additional accessories Xantrex web site IX–2 973-0031-01-01 Rev A...
  • Page 64 Xantrex Technology Inc. 1 800 670 0707 Tel toll free NA 1 360 925 5097 Tel direct 1 800 994 7828 Fax toll free NA 1 360 925 5143 Fax direct customerservice@xantrex.com www.xantrex.com 973-0031-01-01 PC Printed in USA...
