Gima LUXOR Quick Start Manual
Hide thumbs Also See for LUXOR:

Advertisement

Available languages

Available languages

NO.
DESCRIZIONE
DISEGNO
A
POLTRONA
B
BASE 01
C
BASE 02
D
Vite (M6 X 60)
E
Accessori-1
F
Vite (M6 x 12)
G
Chiave inglese
MODELLO: 28005/28006
QT.
1
1
1
Separare la sezione superiore e inferiore.
4
Girare la sezione inferiore.
1
2
1
Pagina 1
POLTRONA LUXOR-MECCANICA
Istruzioni di assemblaggio
Allentare le 4 viti.
Si prega di stringere il dado alla pompa idraulica.
Nel caso non siano presenti danneggiamenti si prega di stringere il dado e reinstallare.
Estrarre la sezione superiore.
Girare la sezione inferiore.
Allentare le 2 viti con il pedale.
GIMA S.p.A. - Via Marconi, 1 - 20060 Gessate (MI) - Italy
Made in P.R.C.
