Quick Start
AC1000 WiFi Router
Model R6080
Package Contents
Router
Power adapter
Ethernet cable
(varies by region)
1. Position the Antennas
For the best WiFi performance, position the antennas as shown.
2. Restart Your Modem and Plug In Your Router
Unplug your modem, remove and replace the backup battery if it uses one, and
then plug the modem back in. Use the Ethernet cable to connect the modem to
the blue Internet port on the router.
Note:
If your Internet connection does not require a modem, connect your main
Ethernet cable to the blue Internet port on the router.
Connect the router to a power source. The router's Power LED
when the router is ready.
3. Connect to the Internet
Make sure that the router's WiFi LED
is lit. Look on the router label for the
preassigned WiFi network name (SSID) and network key (password).
Open the WiFi connection manager on your computer or other WiFi-enabled
device, find the router's WiFi network name, and use the router's password to
connect.
Launch a web browser. If the NETGEAR installation assistant does not display, visit
www.routerlogin.net. If a login window displays, enter admin for the user name
and password for the password. Follow the onscreen instructions.
The router's Internet LED lights
green when the router is connected to the
Internet.
lights green
