Turning ON Camera
1. Turn the system on. Move the ON/OFF switch to the ON position.
•
The camera takes a few seconds to boot up and be ready to record (the red area under the
switch will be exposed with the switch moved to the ON position).
•
The operation LED will be solid red and then transition to blinking green when the system
goes into BUFFERING mode.
•
The Axon Body 2 camera will go into BUFFERING mode after the boot up sequence.
Buffering is set to capture activities that occur 30 seconds before you activate the EVENT
(recording) mode.
AXON BODY 2
Quick Tip Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the BODY 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Axon BODY 2

Summary of Contents for Axon BODY 2

  • Page 1 The operation LED will be solid red and then transition to blinking green when the system goes into BUFFERING mode. • The Axon Body 2 camera will go into BUFFERING mode after the boot up sequence. Buffering is set to capture activities that occur 30 seconds before you activate the EVENT (recording) mode.

  • Page 2: Recording An Event

    Axon Body 2. The Bluetooth pairing process must start with the Axon Body off. 1. Ensure that the Axon Body camera is turned off. If any red is showing at the power switch, the camera is on. Move the switch so the red portion is covered.
  • Page 3 Axon View. Tagging videos in the field You can use Axon View to tag the videos you record such as ID, title, and category. Axon View transfers the tag information to the Axon camera. 1. Ensure that the Axon camera is turned on and paired to the mobile device.
  • Page 4 For some situations, you may wish to turn off the LED lights, sounds (audio prompts), and vibrations (haptic feedback) on your Axon Body 2 camera. Turning off all the indicators and notifications is also known as stealth mode. There are several ways you can enter and exit stealth mode. You can use the Battery Status button, Axon View (if your camera is paired with Axon View).
  • Page 5 Audio prompt and vibration guide The Axon Body 2 camera emits beeping sounds called “audio prompts” to notify you of the system status. These audio prompts usually occur after you perform an action with the body camera. For some actions, the camera also vibrates while making an audio prompt.

  • Page 6: Checking Battery Status

    Battery capacity is 40-100 percent Green Battery capacity is 20-39 percent Yellow Battery capacity is less than 20 percent Battery is critically low Blinking red and yellow The battery level can also be checked by using the AXON View on your iPhone...
