  • Page 1 Operating instructions Linear feeder SLL 175 SLL 400 SLL 800 SLL 804 SLF 1000 and hopper type BV Rhein-Nadel Automation GmbH...
  • Page 2: Table Of Contents

    Instructions for trouble-shooting 1 Technical data Notice All linear feeders listed in the table may only be operated in connection with a RNA control unit at a mains voltage of 230V/50Hz.. Special voltages and frequencies see separate data sheet. Pin assignment...
  • Page 3 Linear feeder type SLL 175 Linear feeder type SLL 175-175 SLL 175-250 200x62x63 275x62x63 Dimensions L x B x H (mm) Weight IP54 IP54 Insulation type 1.800 1.800 Connecting cable length (VA) Power consumption 70 mA 70 mA Current consumption...
  • Page 4 Max. useful weight of the linear feeder dependent on the mass moment of inertia and required running 1,5 – 2 kg 1,5 – 2 kg 1 - 1,5 kg 1 – 1,5 kg speed Linear feeder type SLF 1000 Linear feeder type SLF 1000-1000 SLF 1000-1500 1.100 x 244 x 178...
  • Page 5 running speed 1.100 1.300 1.500 1.700 (mm) Max. track length Max. useful weight of the linear feeder dependent on the mass moment of inertia and required running 4 - 8 kg 4 – 8 6 - 10 6 - 10 speed Linear feeder type SLL 800 - 1600 SLL 800 - 1800 SLL 800 - 2000 SLL 804 - 2400...
  • Page 6: Safety Instructions

    running speed 1.100 1.300 1.500 1.700 (mm) Max. track length Max. useful weight of the linear feeder dependent on the mass moment of inertia and required running 12 – 15 kg 12 – 15 kg 12 – 15 kg 12 – 15 kg speed Linear feeder type SLL 804 - 1600 SLL 804 - 1800 SLL 804 - 2000 SLL 804 - 2800...
  • Page 7: Construction And Function Of The Linear Feeder

    • Rheinnadel- Conditions for purchasing • VDE- Standards The linear feeder may only be operated in the configu- ration drive unit, control unit and oscillating unit, as • VDMA- Conditions of delivery specified by the manufacturer. No additional loads may act upon the linear feeder, apart from the material to be transported, for which the special type is designed.
  • Page 8: Transport And Mounting

    Plug in the mains cable of the control unit and switch on the control unit by the mains switch. SLL 175-175 SLL 175-250 SLL 400 - 400 Notice SLL 400 - 600 At linear feeders which are delivered as a...
  • Page 9 set the turning knob to the marking.. The optimal operative range of the linear feeder is at a controller position of 80% at the control unit. In case of higher deviations (≥±15%) a readjustment should be carried out. 5.2 Adjustment with spring assemblies for a conveying track weight, which is approx.
  • Page 10 spring assembly is dismounted. The dismounted area of the counterweight and the vibrator at the linear spring assembly must be horizontally clamped into a feeder's feeding side. After that the individual spring parallel jaw vice with smooth clamping jaws, in order assemblies can be screwed down in the required to dismount or install the leaf springs.
  • Page 11 At the rear spring assembly the earthed conductor at Spring angle larger than the gravity center angle the upper spring seat must be unscrewed before the spring assembly is dismounted. The dismounted The force direction of the springs is initiated before spring assembly must be horizontally clamped into a the gravity center of the vibrator.
  • Page 12: Specifications For The Design Of The Track

    The adjustment of the air gap can be made from the The higher the feeding speed is, the larger must the outside without dismounting any component parts. clearance between upper edge of the part to be con- Slightly loosen both armature fastening screws ("A" or veyed and the lower edge of the cover of the convey- "A"...
  • Page 13: What To Do, If

    sequently the height amplitude too high. In this case proceed as follows: • Change the gravity center angle (make it more "flat"), by displacing the counterweight "F" against the running direction, installing additional weight plates at the counter weight, installing an additional weight in the oscillating profile and choosing a lighter design for the conveying track if necessary.
  • Page 14 Trouble Possible cause Remedy Linear feeder does not Mains switch off Switch on the mains switch start when being switched on Mains plug of the control unit is not Plug in the mains plug. plugged in Plug in the 7-pole plug at the control unit Connecting cable between linear feeder and control unit is not plugged in Replace the fuse...
  • Page 15 Email werk.ergolding@rna.de HSH Handling Systems AG Wangenstr. 96 CH - 3360 Herzogenbuchsee Tel +(41) 062/95610-00 Fax (+41) 062/95610-10 Internet www.rna.de Email info@handling-systems.ch RNA AUTOMATION LTD Hayward Industrial Park Tameside Drive, Castle Bromwich GB - Birmingham, B 35 7 AG Tel (+44) 0121/749-2566 Fax (+44) 0121/749-6217 Internet www.rna-uk.com Email rna@rna-uk.com...
