Rhein - Nadel Automation GmbH
VT-BA-GL-GB
Operating instructions
Linear feeder
GL 1
GL 01
1
BA
Rhein-Nadel Automation GmbH
Date: 14.04.2014

Advertisement

loading
Need help?

Need help?

Do you have a question about the GL 1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RNA GL 1

  • Page 1 Operating instructions Linear feeder GL 1 GL 01 Rhein-Nadel Automation GmbH Rhein - Nadel Automation GmbH Date: 14.04.2014 VT-BA-GL-GB...
  • Page 2: Table Of Contents

    Contents Technical data Page 3 Safety instructions Page 4 Construction and function of the linear feeder Page 5 Transport and mounting Page 5 Starting/Adjustment Page 6 Specifications for the design of the track Page 7 Maintenance Page 8 Stockkeeping of spare parts and after-sales service Page 8 What to do, if..? Page 8...
  • Page 3: Technical Data

    Notice All linear feeders listed in the table may only be operated in connection with a RNA control unit at a mains voltage of 230V/50Hz. Special voltages and frequencies see separate data sheet Technical data Linear feeder type GL 01...
  • Page 4: Safety Instructions

    2 Safety instructions The conception and production of our linear feeders has been carried out very carefully, in order to guarantee trouble-free and save operation. You too can make an important contribution to job safety. Therefore, please read this short operating instruction completely, before starting the machine. Always observe the safety instructions! Make sure that all persons working with or at this machine carefully read and observe the following safety instructions! This operating instruction is only valid for the types indicated on the front page.
  • Page 5: Construction And Function Of The Linear Feeder

    binding regulation for the qualification of electricians and personnel instructed in electrical engineering is valid, as defined in IEC 364 and DIN VDE 0105 part 1. Attention: Since the electromaget-field may have an impact on persons arrying pacemakers it is recommended to keep a minimum distance of 25 cm.
  • Page 6: Transport And Mounting

    Width in mm Vibration buffer thread GL 01 GL 1 Table bore data Make sure that the linear feeder cannot come into contact with other devices during operation. Further details on the control unit (bore plan, etc.) are please taken from the operating instructions of the control unit separately delivered.
  • Page 7 Attention The electric connection of the linear feeder may only be made by trained personnel (electricians)! In case modifications are made at the electric connection, it is absolutely necessary to observe the operating instructions "control units".  The available supply voltage (frequency, voltage, output) is in accordance with the connection data of the control unit (see type plate at the control unit).
  • Page 8 Conveying speed Resonant frequency of the system Resonance curve (not true to scale) Spring power Notice The resonant frequency of the linear feeder may not correspond to the mains frequency In case the conveying capacity decreases after loosening the spring fastening screw, proceed as described under point 5.1.
  • Page 9: Specifications For The Design Of The Track

    Adjustment of the linear feeder type GL 1: For the adjustment of the oscillator in parallel to the counter-mass four leaf springs are included in the delivery. These leaf springs must be inserted between the spring assemblies and the distance cams (one each above and below).
  • Page 10 Trouble Possible cause Remedy Linear feeder does not Mains switch off Switch on the mains switch start when being switchen Mains plug of the control unit is not plugged in Plug in the mains plug. Connecting cable between linear feeder and control Plug in the 5-pole plug at the control unit unit is not plugged in Replace the fuse...
  • Page 11 Rhein-Nadel Automation GmbH Reichsweg 19/23  D - 52068 Aachen Tel (+49) 0241/5109-159  Fax +(49) 0241/5109-219 Internet www.rna.de  Email vertrieb@rna.de Rhein-Nadel Automation GmbH Zweigbetrieb Lüdenscheid Nottebohmstraße 57  D - 58511 Lüdenscheid Tel (+49) 02351/41744  Fax (+49) 02351/45582 Email werk.luedenscheid@rna.de...
