FOREWORD
This manual contains an introductory description on
HYOSUNG PRIMA(SF-50) and procedures for its inspec-
tion/service and overhaul of its main components.
Other information considered as generally known is
not included.
Read GENERAL INFORMATION section to familiarize
yourself with outline of the vehicle and MAINTE-
NANCE and other sections to use as a guide for
proper inspection and service.
This manual will help you know the vehicle better so
that you can assure your customers of your optimum
and quick service.
* This manual has been prepared on the basis of
the latest specification at the time of publica-
tion.
If modification has been made since then, dif-
ference may exist between the content of this
manual and the actual vehicle.
* Illustrations in this manual are used to show the
basic principles of operation and work proce-
dures.
They may not represent the actual vehicle exactly
in detail.
* This manual is intended for those who have
e n o u g h k n o w l e d g e a n d s k i l l s f o r s e r v i c i n g
HYOSUNG vehicles. Without such knowledge and
skills, you should not attempt servicing by relying
on this manual only.
Instead, please contact your nearby authorized
HYOSUNG motorcycle dealer.
HYOSUNG MOTORS & MACHINERY INC.
� COPYRIGHT HYOSUNG MOTORS & MACHINERY INC. 1999
GROUP INDEX
GENERAL INFORMATION
PERIODIC MAINTENANCE
ENGINE
FUEL SYSTEM
ELECTRICAL SYSTEM
CHASSIS
SERVICING INFORMATION
1
2
3
4
5
6
7
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HYOSUNG PRIMA
Summary of Contents for HYOSUNG PRIMA
- Page 1 GROUP INDEX FOREWORD This manual contains an introductory description on GENERAL INFORMATION HYOSUNG PRIMA(SF-50) and procedures for its inspec- tion/service and overhaul of its main components. Other information considered as generally known is not included. PERIODIC MAINTENANCE Read GENERAL INFORMATION section to familiarize...
- Page 2 HOW TO USE THIS MANUAL TO LOCATE WHAT YOU ARE LOOKING FOR: 1. The text of this manual is divided into sections. 2. As the title of these sections are listed on the previous page as GROUP INDEX, select the section where what you are looking for belong.
- Page 3 SYMBOL Listed in the table below are the symbols indicating instructions and other information necessary for servicing and meaning associated with them respectively. SYMBOL DEFINITION SYMBOL DEFINITION Torque control required. Apply THREAD LOCK “1324” . Data beside it indicates specified torque. Apply oil.
-
Page 5: Table Of Contents
GENERAL INFORMATION CONTENTS 1 - 1 INFORMATION LABELS 1 - 1 GENERAL PRECAUTIONS 1 - 3 SERIAL NUMBER LOCATION 1 - 3 FUEL AND OIL RECOMMENDATIONS 1 - 4 BREAK-IN PROCEDURES EXTERIOR ILLUSTRATION 1 - 5 SPECIFICATIONS 1 - 6... -
Page 6: General Precautions
1-1 GENERAL INFORMATION WARNING / CAUTION / NOTE Please read this manual and follow its instructions carefully. To emphasize special information, the symbol and the words WARNING, CAUTION and NOTE have special meanings. Pay special attention to the messages highlighted by these signal words. WARNING Indicates a potential hazard that could result in death or injury. - Page 7 GENERAL INFORMATION 1-2 CAUTION ● If parts replacement is necessary, replace the parts with HYOSUNG Genuine Parts or their equivalent. ● When removing parts that are to be reused, keep them arranged in an orderly manner so that they may be reinstalled in the proper order and orientation.
-
Page 8: Serial Number Location
1-3 GENERAL INFORMATION HYOSUNG PRIMA (SF - 50) RIGHT SIDE LEFT SIDE * Difference between photographs and actual motorcycles depends on the markets. SERIAL NUMBER LOCATION The frame serial number or V.I.N. (Vehicle Identification Number) is stamped on the right side of the frame under the footboard. -
Page 9: Break-In Procedures
GENERAL INFORMATION 1-4 ENGINE OIL Specification and classification: APOLLOIL BIKE-K, HYPOL HS BRAKE FLUID Specification and classification: DOT4 WARNING Since the brake system of this motorcycle is filled with a glycol-based brake fluid by the manufacturer, do not use or mix different types of fluid such as silicone-based and petroleum-based fluid for refilling the sys- tem, otherwise serious damage will result. -
Page 10: Exterior Illustration
1-5 GENERAL INFORMATION EXTERIOR ILLUSTRATION 1,270 1,825 Rear reflector Head lamp Tail/Brake lamp ( Rear ) Turnsignal ( Front ) Turnsignal lamp lamp... -
Page 11: Specifications
GENERAL INFORMATION 1-6 SPECIFICATIONS DIMENSIONS AND DRY MASS Overall length 1,825 mm (71.9 in) Overall width 635 mm (25.0 in) Overall height 1,110 mm (43.7 in) Wheelbase 1,270 mm (50.0 in) Ground clearance 125 mm (4.9 in) Dry mass 88 kg (194 lbs) ENGINE Type Two-stroke, forced air cooled... - Page 12 1-7 GENERAL INFORMATION ELECTRICAL Ignition type “CDI”type Ignition timing 20。 B.T.D.C. at 1,000 rpm Spark plug BR8HSA Battery 12V 3Ah/10HR Generator Magneto Fuse Headlamp 15W×2 Turn signal lamp 10W×4 Tail/Brake lamp 5/10W Speedometer lamp 1.7W×2 Oil level indicator lamp 1.7W Turn signal indicator lamp 1.7W CAPACITIES...
