Specifications:
Model
Power Supply
Power Consumption
LEDs
Color Mixing
Beam Angle
Dimmer
Operating Modes
DMX Channels
Safety Class
Connections
Dimensions (L x W x H)
Weight
Troubleshooting:
The following overview serves as an aid for quick troubleshooting. If you are unsure, contact the
manufacturer, the dealer or the corresponding specialist personnel. Never open the device on
your own!
Symptom
No function
No reaction in DMX mode
No reaction in remote mode
If the specified corrections have not led to success, please contact our service staff. The contact
details can be found at www.musicstore.de
Pixelbar Switch
AC 110-240V, 50/60HZ
60 Watt
224 SMD-5050
RGB
(Red – Green – Blue)
120°
0 - 100%
Auto, Sound Control, Master/Slave, DMX
3, 5, 8, 24, 48 or 53
IP20
DMX In-/Output (3-pole)
Power Outlet (Input/Output)
1100 x 100 x 100 mm
1,8 kg
Troubleshooting
Check the mains connection and the fuse
Check the cable connections
Check your DMX address setting
If available, try an alternative DMX controller
Change the battery in your remote control
Ensure that the IR transmitter and receiver are at
close and clear distances from each other
ENGLISH
