Put the sprayer in manual mode using the key
Start the sprayer using the key
Raise the spraying pressure to exactly 3 bars using the keys
handle or in the complementary mask 2.
Verify the flow of various nozzles using a test tube for exactly one minute.
Stop then the spraying using the key
Divide the quantity obtained by the number of nozzles verified and input the thus obtained value in the
slot l/min
Start the sprayer using the key
Faire monter la pression de pulvérisation à une pression choisie, tout en restant dans la plage
d'utilisation de la buse, à l'aide des touches
masque complémentaire 2.
Verify the flow of various nozzles using a test tube for exactly one minute.
Stop then the spraying using the key
key .
Divide the quantity obtained by the number of nozzles verified and input the thus obtained value in the
slot l/min
Input also the pressure of the second measure in the calibration mask.
The calibration procedure is now completed. The accuracy of the result depends on the care brought
during the measurement and the precision of the measuring tools.
INSTRUCTIONS FOR USE
OF REGULATIONS
NOVATEC ISOBUS AND NOVATOP
of the multi-functions handle or in the complementary mask 2.
of the multi-functions handle or in the complementary mask 2.
of the multi-functions handle or in the complementary mask 2.
et
and put the sprayer back to automatic mode with the
