Henley End Table
Assembly Instructions -
Dimensions
Width - 45cm
Depth - 45cm
Height - 45cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
614 / 3150
614 / 3167
Issue 1 -18/10/11
Advertisement
Related Manuals for Argos Henley End Table 614/3150
Summary of Contents for Argos Henley End Table 614/3150
- Page 1 Henley End Table Assembly Instructions - Please keep for future reference 614 / 3150 614 / 3167 Dimensions Width - 45cm Depth - 45cm Height - 45cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 -18/10/11...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • To ensure an easier assembly, • Keep these instructions for • Do not use this item if any future use. components are missing or we strongly advise that all fittings damaged. -
Page 3: Components - Parts
Components - Parts If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the parts listed below Inside Inside Underside Side panel ( right ) Side panel ( left) Top panel (45 x 45cm) (42 x 43 .2cm) (42 x 43 .2cm) Inside... -
Page 4: Tools Required
Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Wood dowel x 6 Locking nut x 13 Metal dowel x 13 Drawer handle x 1 19mm Screw x 1... - Page 5 Assembly Instructions Step 1 Preparing panels Place left and right side panels top panel flat on the floor with the fixing holes facing up. Screw metal dowels into panels Bottom as shown. Note: Insert metal dowels as far as shown. Do not overtighten.
- Page 6 Assembly Instructions Step 2 Attaching back panel Locate back panel onto right side panel Holes to face inside Note: Ensure the fixing holes are facing in as shown. Insert locking nuts into the holes in back panel as shown. Using a screwdriver, turn locking nuts clockwise to secure.
- Page 7 Assembly Instructions Step 4 Attaching left side panel Insert wood dowel into the end of lower stretcher as shown. With help, carefully align left side panel locate into position. Insert locking nuts into back panel stretchers Turn locking nuts clockwise to secure. Step 5 Attaching top panel Place top...
- Page 8 Assembly Instructions Step 6 Assembling drawer a: Assemble drawer side panels and drawer back together using screws Note: Ensure the Align grooves grooves in all 3 panels are aligned at the bottom. b: Slide drawer base into the grooves as shown.
- Page 9 Assembly Instructions Step 8 Locating drawer Carefully stand the unit upright. Warning: The table is heavy! Lift with care. a: Fully extend all drawer runners out as shown. Pull out the side panel drawer runners for proper insertion of the drawers. b: Carefully locate the runners on the drawer, into the runners on the...
