Williams Sound SoundPlus Infrared System WIR SYS 90V Specification Sheet page 3

SoundPlus ® Infrared System •
D
D
Fig. 3: Receiver Coverage Area with TX90 Transmitter in Single Channel Mode
Feet
90
80
70
60
50
40
30
20
10
0
-10
-20
-30
-40
-50
-60
-70
-80
-90
Feet 0
10 20 30
The coverage area for the TX90 will vary depending on the receiver being used. The diagram
above demonstrates the receiver coverage when operating a single TX90 transmitter in single chan-
nel mode. Patterns are direct radiation patterns.
Note: Reflections of the infrared light from walls, ceilings and floors may change these patterns.
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
©2008, Williams Sound Corp. MCAT 064A
RX16 RX14-2
90 100 110 120 130 140 150 160
40 50 60 70 80
Model WIR SYS 90V
Receiver Coverage Area with TX90
Transmitter in Single Channel Mode
RX22-4
3
RX22-4 Receiver
RX14-2 Receiver
RX16 Receiver
