National Instruments SCXI-1351 Installation Manual

INSTALLATION GUIDE
SCXI -1351 O
™
What You Need To Get Started
™ ™
National Instruments , NI , ni.com
are trademarks or trade names of their respective companies. For patents covering National Instruments products, refer to the appropriate location:
Help»Patents in your software, the
371181A-01
-S
NE LOT
This guide describes how to install the National Instruments SCXI-1351
one-slot cable extender in an SCXI system.
The SCXI-1351 extends the pinout from a 100- or 50-pin digital I/O (DIO)
data acquisition (DAQ) device to one or more SCXI modules. The
SCXI-1351 is intended for use with the SCXI-1181 module for custom
signal conditioning, but you can use it with some other SCXI modules.
To set up and use the SCXI-1351, you need the following items:
❑
Computer
❑
One or more SCXI-1351 one-slot cable extenders
❑
One or more SCXI modules
❑
SCXI chassis
❑
100- or 50-pin DIO DAQ device
❑
One of the following:
– NB5, NB6, or R1005050 cable for a 100-pin DIO device
– NB1 or R5050 cable for a 50-pin DIO device
❑
SCXI-1351 One-Slot Cable Extender Installation Guide
❑
Small flathead screwdriver
❑
Two small screws
™ ™
, and SCXI are trademarks of National Instruments Corporation. Product and company names mentioned herein
file on your CD, or
patents.txt
© 1993–2002 National Instruments Corp. All rights reserved.
C E
ABLE XTENDER
.
ni.com/patents
February 2002
