4.7.3 Air flow sensor
This device prevents the unit operating in the absence of air flow. The control is effected by a differential pressure switch
which measures the pressure difference upstream and downstream of the evaporator coil and the air filter, or by a differen-
tial pressure transducer in units where EC fans with control of the air flow are present. The going-off of the microprocessor
alarm is delayed by the intervention of the sensor.
To test its operation:
- With AC fans: open the circuit breakers of the fan section and the compressors (QMV and QMC on the wiring diagram),
and then turn on the unit. The microprocessor alarm should appear within a few tens of seconds.
- With EC fans: open the automatic compressor switches (QMC on the wiring diagram), remove the terminal with the
control signal for the EC fan (terminal J4) from the microprocessor card, turn on the unit as above and wait for the alarm.
4.7.4 Dirty filter sensor (optional)
The check of the level of air filter clogging is carried out by means of a differential pressure switch which measures the
upstream and downstream pressure drop of the filter.
The control panel will signal, via an alarm on the display, the need to replace or clean the filter. The machine will continue
to work in any case.
The fouling of the filter may cause a decrease in the flow rate and therefore of the machine's performan-
ce; restoring the filter as quickly as possible from the time of reporting is recommended.
4.7.5 Discharge air pressure sensor (optional)
For units with air delivery pressure switch under the raised floor (accessory), once the unit is installed, the installer must
connect the PVC tubes to the air differential pressure transmitter.
The small tubes supplied in coils inside the unit, must be positioned as follows:
- the tube connected to the negative inlet of the air differential pressure transducer should be positioned in the suction
unit, preferably in an intake plenum or in any case in such a position that the air pressure measurement is not influenced
by the dynamic component;
- the tube connected to the positive inlet of the air differential pressure transducer should be positioned under the floor,
at a sufficient distance from the supply unit in order that the air pressure measurement is not influenced by the dynamic
component;
The tubes must be positioned taking care not to make any small radius curves and not to choke the
tubes with clamps; incorrect positioning of the ends of the tubes, sharp bends or kinks may cause false
air pressure readings.
