Summary of Contents for TimeTec Smart AC1/TD
- Page 1 . t i m e t e c c l o u d . c o m Smart AC1/TD Face Recognition Access Device with Fever Detection User Guide...
- Page 2 TimeTec Holding. Every precaution has been made to supply complete and accurate information. Information in this document is subject to change without prior notice.
-
Page 3: Table Of Contents
18-19 COMMUNICATION SETTINGS 5.1 Network Settings 5. Pc Connection 5. Cloud Server Setting 5.4 Wiegand Setup -4 SYSTEM SETTINGS 6.1 Date And Time 6. Access Logs Setting 6. Face Parameters 7-8 6.4 Fingerprint Parameters 6.5 Palm Parameters 6.6 Factory Reset Smart AC1/TD... - Page 4 Combined Verification Settings Anti-passback Setup Duress Options Settings 10 ATTENDANCE SEARCH 44-45 11 AUTOTEST 12 SYSTEM INFORMATION 13 CONNECT TO SOFTWARE 1.1 Connect to AWDMS/ Ingress Software 1. Software Quick Installation 48-51 1. Configure AWDMS Setup Tool 5-5 1.4 Configure AWDMS in Ingress Software APPENDIX 55-57 Smart AC1/TD...
-
Page 5: Notice For Use
1.55m-1.85m is 1.5m. Users may slightly move forwards and backwards to improve the quality of facial images captured. Facial expression and standing posture Note During enrol- ment and veri- fication, please remain natural facial expression and standing posture. Smart AC1/TD... -
Page 6: Palm Registration
If a part of the face is covered with a hat, a mask, an eye patch, or sunglasses authentication may fail. Do not cover the face, allow the device to recognize both the eyebrows and the face. Smart AC1/TD... -
Page 7: Standby Interface
Click [En] to switch to English keyboard. Press [123] to switch to the nu- meric and symbolic keyboard, and click [ABC] to return to the alphabetic keyboard. Click the input box, virtual keyboard appears. Click [ESC] to exit the input. Smart AC1/TD... -
Page 8: Verification Mode
If the user has registered the face and password in addition to his/her palm, and the verification method is set to palm/ face/ password verifica- tion, the following screen will appear. Select the palm icon to enter palm verification mode. Smart AC1/TD... -
Page 9: Fingerprint Verification
Users may try verifying their identities with 1:1 veri- fication mode when they cannot gain access with 1: N authentication method. Click the button on the main screen to enter 1:1 fingerprint verification mode. 1. Input the user ID and press [OK]. Smart AC1/TD... -
Page 10: Facial Verification
Conventional verification: Compare the acquired facial images with all face data registered in the device. The following is the pop-up prompt box of comparison result. 1:1 Facial Verification Compare the face captured by the camera with the facial template related to the entered user ID. Smart AC1/TD... -
Page 11: Password Verification
1. Input the user ID and press [OK]. If an employee registers palm and face in addi- tion to password, the following screen will appear. Select the icon to enter password verifica- tion mode. . Input the password and press [OK]. Smart AC1/TD... -
Page 12: Combined Verification
2. You must register the required verification information before using the combination verification mode, otherwise the verification may fail. For example, if a user uses Face Registration but the verification mode is Face + Password, this user will never pass verification. Smart AC1/TD... -
Page 13: Main Menu
Query the specified access record, check attendance photos and blacklist photos. To automatically test whether each module functions properly, Autotest including the screen, audio, camera and real-time clock. To view data capacity, device and firmware information of the System Info current device. Smart AC1/TD... -
Page 14: User Management
The administrator owns all management privileges. If a custom role is set, you can also select user defined role permissions for the user. Click User Role to select Normal User or Super Admin. Smart AC1/TD... - Page 15 Click Password to enter the password registration page. Enter a password and re-enter it. Click OK. If the two entered passwords are different, the prompt “Password not match” will appear. Note: The password may contain one to eight digits by default. Smart AC1/TD...
-
Page 16: Search For Users
Click the search bar on the user list and enter the retrieval keyword (The keyword may be an ID, surname or full name.). The system will search for the users related to the information. Edit Users Choose a user from the list and click Edit to enter the edit user interface: Smart AC1/TD... -
Page 17: Deleting Users
Choose a user from the list and click Delete to enter the delete user interface. Select the user information to be deleted and click OK. Note: If you select Delete User, all information of the user will be deleted. Smart AC1/TD... -
Page 18: User Role
1. Click any item to set a defined role. Click the row of Enable Defined Role to enable this defined role. Click Name and enter the name of the role. . Click Define User Role to assign the privileges to the role. The privilege assignment is completed. Click Return. Smart AC1/TD... - Page 19 If the device has a role enabled, you may assign the roles you set to users by clicking User Mgt. > New User > User Role. If no super administrator is registered, the device will prompt “Please register super ad- ministrator user first!” after clicking the en- able bar. Smart AC1/TD...
-
Page 20: Communication Settings
Please adjust it according to the actual network situation. Port DHCP Dynamic Host Configuration Protocol, which is to dynamically allocate IP addresses for clients via server. Display in To set whether to display the network Status Bar icon on the status bar. Smart AC1/TD... -
Page 21: Pc Connection 1
IP address of the ADMS server. Server Port Port used by the ADMS server. Enable Proxy Server When you choose to enable the proxy, you need to set the IP address and port number of the proxy server. Smart AC1/TD... -
Page 22: Wiegand Setup
Consists of 4 bits of binary code. The 1st bit is the even parity bit of the nd to 17th bits, while the 4th bit is the odd parity bit of the 18th to rd bits. The nd to 5th bits are the card numbers. Smart AC1/TD... - Page 23 “C “denotes the card number; “E” denotes the even parity bit; “O” denotes the odd parity bit; “F“ denotes the facility code; “M” denotes the manufacturer code; “P” denotes the parity bit; and “S” denotes the site code. Smart AC1/TD...
- Page 24 The time width represents the changes of the quantity of electric Pulse Width(us) charge with high-frequency capacitance regularly within a speci- fied time. Pulse Interval(us) The time interval between pulses. Select between User ID and badge number. ID Type Smart AC1/TD...
-
Page 25: System Settings
For example, the user sets the time of the device (18:35 on March 15, 2019) to 18:30 on January 1, 2020. After restoring the factory settings, the time of the equipment will remain 18:30 on January 1, 2020. Smart AC1/TD... -
Page 26: Access Logs Setting 6
1 and 99. The length of time that the message of successful verification dis- Confirm Screen plays. Valid value: 1~9 seconds. Delay(s) Face comparison To set the facial template matching time interval as needed. Valid value: 0~9 seconds. Interval (s) Smart AC1/TD... -
Page 27: Face Parameters 7-8
The pitch angle tolerance of a face for facial registration and comparison. If a face’s pitch angle exceeds this set value, it will be filtered by the algo- rithm, i.e. ignored by the terminal thus no registration and comparison interface will be triggered. Smart AC1/TD... - Page 28 Notes Improper adjustment of the exposure and quality parameters may severely affect the performance of the device. Please adjust the exposure parameter only under the guidance of the after-sales service personnel of our company. Smart AC1/TD...
-
Page 29: Fingerprint Parameters
Show for match: to display the fingerprint image on the screen only during verification. Always show: to display the fingerprint image on screen during enrollment and verification. None: not to display the fingerprint image. Smart AC1/TD... -
Page 30: Palm Parameters
Factory Reset Restore the device, such as communication settings and system settings, to factory settings (Do not clear registered user data). Click Reset on the System interface. Click OK to reset. Smart AC1/TD... -
Page 31: Personalize Settings
Press any key or finger to resume normal working mode. You can disable this function or set a value within 1-999 minutes. To select the main screen style according to your personal prefer- Main Screen Style ence. Smart AC1/TD... -
Page 32: Voice Settings
Repeat Set the repetition cycle of the bell. Ring Tone Select a ring tone. Set the duration of the inter- Internal bell nal bell. Valid values range delay(s) from 1 to 999 seconds. Smart AC1/TD... -
Page 33: Punch States Options
Manual Fixed Mode: After punch state key is manually switched, the punch state key will remain unchanged until being manually switched next time. Fixed Mode: Only the fixed punch state key will be shown and it cannot be switched. Smart AC1/TD... -
Page 34: Shortcut Keys Mappings 4
Users may define shortcuts as attendance status or functional keys. On the main interface, when the shortcut keys are pressed, the corresponding attendance status or function interface will quickly display. Click Shortcut Key Mappings on the Personalize interface. Smart AC1/TD... - Page 35 Delete Access Control To delete all access data. Delete User Photo To delete all user photos in the device. Delete Wallpaper To delete all wallpapers in the device. To delete the screen savers in the device. Delete Screen Savers Smart AC1/TD...
- Page 36 Delete All or Delete by Time Range. Selecting Delete by Time Range, you need to set a specific time range to delete all data with the period. Select Delete by Time Range. Set the time range and click OK. Smart AC1/TD...
-
Page 37: Access Control Options 8
In default settings, new users are allocated into the first group with the default group time zone and access combo as “1“ and set in unlocking state. Smart AC1/TD... - Page 38 Verification Mode The supported verification mode includes password/face, User ID only, password, face only, and face + password. Door available time To set time period for door, so that the door is available only period during this. Smart AC1/TD...
-
Page 39: Time Schedule 9
1. Click the grey box to input a time zone to search. Enter the number of time zone (maximum: 50 zones). . Click the date on which time zone settings is required. Enter the starting and ending time, and then press OK. Smart AC1/TD... -
Page 40: Holiday Settings
Click Holidays on the Access Control interface. Add a New Holiday Click Add Holiday on the Holidays interface and set the holiday parameters. Smart AC1/TD... -
Page 41: Combined Verification Settings
4 consists of three people. The first person is from AC group , the second person is from AC group 5, and the third person is from AC group 8. Delete a door-unlocking combination Set all group number as 0 if you want to delete door-unlocking combinations. Smart AC1/TD... -
Page 42: Anti-Passback Setup
In/Out Anti-passsback: After a user checks in/out, only if the last record is a check-out record, the user can check in again; or a check-in record, the user can check out again; otherwise, the alarm will be triggered. Smart AC1/TD... -
Page 43: Duress Options Settings
Alarm signal will not be transmitted until the alarm delay time is elapsed. The value ranges from 1 to 999 seconds. Set the 6-digit duress password. When the user enters this du- Duress Password ress password for verification, an alarm signal will be generated. Smart AC1/TD... -
Page 44: Attendance Search
1. Enter the user ID to be searched and click OK. If you want to search for records of all users, click OK without entering any user ID. . Select the time range in which the records you want to search for. Smart AC1/TD... - Page 45 . t i m e t e c c l o u d . c o m . The record search succeeds. Click the record in green to view its details. 4. The below figure shows the details of the selected record. Smart AC1/TD...
-
Page 46: Autotest
To test the RTC. The device tests whether the clock works normally Test Clock RTC and accurately with a stopwatch. Touch the screen to start counting and press it again to stop counting. Smart AC1/TD... -
Page 47: System Information
Device Info Displays the device’s name, serial number, MAC address, face algo- rithm version information, platform information, and manufacturer. Displays the firmware version and other version information of the Firmware Info device. Smart AC1/TD... -
Page 48: Connect To Software
Kindly ensure the firewall and Antivirus software on the PC have been switched off before proceeding. Run the AWDMS setup tool after installing the AWDMS and reboot your PC. First, right click on the AWDMS.1.zip file, then click Extract All Smart AC1/TD... - Page 49 Look for setup.exe and click on setup.exe. Once the User Account Control permission is prompted, select to continue. The AWDMS setup will run an en- vironment testing prior to the actual installation, click Continue when the test is completed. Smart AC1/TD...
- Page 50 . t i m e t e c c l o u d . c o m Click Next to continue. End-user Software License Agree- ment. Select “I accept the agree- ment”, then click Next. Leave the Port and ADMS Port in default mode, click Next. Click Next. Click Next. Smart AC1/TD...
- Page 51 Once this icon appears on the desktop, double tap on the “TimeTec Cloud AWDMS” icon to run the AWDMS. The ADWMS login screen will be launched in the web browser. The default login username is “admin” and default password is “admin”. Smart AC1/TD...
-
Page 52: Configure Awdms Setup Tool 5-5
MySQL for better support. In order to switch to MySQL, please run the AWDMS setup tool after the screen below appears. Right click on the AWDMS Setup Tool.zip, click Extract All. Click Extract Go the folder where AWDMS Setup Tool is located. Click AWDMSSetup. exe. Smart AC1/TD... - Page 53 Click “Yes” at the popup dialog box to continue. Once com- pleted, press any key to exit this window. Right click on the awdms.bat, click “Run as administrator”. Press any key to start running the batch file. Once completed, press any key to exit this window. Smart AC1/TD...
-
Page 54: 1.4 Configure Awdms In Ingress Software
Select online device activation, then click Add. After adding the device, it will appear in the Devices list. The AWDMS installation is now completed. You may now launch the software and start pulling or updating data from the AWDMS devices. Smart AC1/TD... -
Page 55: Appendix
7. Please face right towards the capturing device, and locate your face in the image capturing area as shown in Image 1. 8. Do not include more than one face in the capturing area. 9. 50cm - 80cm is recommended for capturing distance adjustable subject to body height. Image1: Face Capture Area Smart AC1/TD... - Page 56 8. Plain face or smile is preferred, showing teeth is not preferred. 9. The captured person should be clearly seen, natural in color, and without image obvious twist, no shadow, light spot or reflection in face or background, and appro priate contrast and lightness level. Smart AC1/TD...
- Page 57 . t i m e t e c c l o u d . c o m Right to Privacy TimeTec thank you for opting this robust biometric recognition product. At TimeTec, we care about privacy. Being one of the renowned providers of core biometric recog-...
- Page 58 . t i m e t e c c l o u d . c o m © 00 Timetec Cloud Sdn Bhd. All rights reserved • 0600...
