- Page 1 CT850 EXTENDED HANDRAILS INSTALLATION GUIDE...
- Page 3 Congratulations on your new Extended Handrails and welcome to the Spirit Fitness family! Thank you for your purchase of this handrail extension from Spirit Fitness. This handrail extension was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available.
- Page 4 WARNING: This product may contain a chemical known to the state of California to cause cancer, birth defects, or other reproductive harm.
- Page 5 CT850 EXTENDED HANDRAILS STEP ONE HARDWARE FOR STEP 1 PART TYPE DESCRIPTION BOLT M8X1.25X25L SPLIT WASHER FLAT WASHER 1. Attach the RIGHT HANDRAIL UPRIGHT TUBE (4) to the underside of the treadmill frame with 3 BUTTON HEAD SOCKET BOLTS (5), 3 SPLIT WASHERS (6), and 3 WASHERS (7).
- Page 6 CT850 EXTENDED HANDRAILS STEP TWO 1. Remove 4 PHILLIPS HEAD SCREWS (134) that secure console assembly to the CONSOLE SUPPORT (5). 2. Disconnect the UPPER COMPUTER CABLE, HAND PULSE ASSEMBLY, TOUCH PAD/BACKLIT CABLE and GROUND WIRE from the board on the back of the CONSOLE (28).
- Page 7 CT850 EXTENDED HANDRAILS STEP THREE HARDWARE FOR STEP 3 PART TYPE DESCRIPTION 3/8”X3/4”L BOLT SPLIT WASHER 3/8” FLAT WASHER 3/8” 1. Remove the 14 screws on the bottom of both sides to take TOP COVER (29) apart. 2. Remove the BUTTON HEAD SOCKET BOLTS (187),...
- Page 8 CT850 EXTENDED HANDRAILS STEP FOUR 1. Connect the UPPER COMPUTER CABLE, HAND PULSE ASSEMBLY, TOUCH PAD/BACKLIT CABLE and GROUND WIRE to the board on the back of the CONSOLE (28). 2. Use 4 PHILLIPS HEAD SCREWS (134) to secure console assembly to the CONSOLE SUPPORT (5).
- Page 9 NOTES www.spiritfitness.com...
- Page 10 NOTES Spirit Fitness...
- Page 11 NOTES www.spiritfitness.com...
- Page 12 800.258.4555 Spirit Fitness spiritservice@spiritfitness.com 3000 Nestle Road www.spiritfitness.com Jonesboro, AR 72401 CT850 Extended Handrails Installation Guide © 2018 All Rights Reserved Revision: 02.28.2018...
