- Page 1 R175 Replacement Cartridge Online user guide for Shure R175 replacement cartridge. Version: 3.0 (2020-H)
- Page 2 Shure Incorporated Table of Contents General Description R175 Replacement Cartridge Cartridge Replacement...
- Page 3 Shure Incorporated R175 Replacement Cartridge General Description Cartridge Replacement Figure 1...
- Page 4 Figure 2 The Shure Model R175 is a direct replacement cartridge for the Shure Model BETA 52 supercardioid dynamic instrument mi crophone. With proper installation, the R175 offers the same high–quality performance as the original cartridge. To install the R175 replacement cartridge in the BETA 52, proceed as follows: Unscrew and remove the screen and grille assembly, see Figure 1. Carefully remove the cartridge from the case. Using a Phillips head screwdriver, remove the screw holding the circuit board from inside of the case.
- Page 5 Shure Incorporated Carefully wind the YELLOW and GREEN lead wires around the back end of the cartridge to take up some of the excess slack. Insert the new cartridge in the case, making sure the TOP label on the face of the cartridge is aligned with the logo on top of the case.
