Service Manual
Model
PD-6
DVD LOCATION RECORDER
<DANGER>
VISIBLE OR INVISIBLE LASER RADIATION WHEN OPEN.
AVOID DIRECT EXPOSURE TO BEAM.
<CAUTION>
• Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
• The use of optical instruments with this product will increase
eye hazard.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PD-6 and is the answer not in the manual?

Questions and answers

Related Manuals for Fostex PD-6

Summary of Contents for Fostex PD-6

  • Page 1 Service Manual Model PD-6 DVD LOCATION RECORDER <DANGER> VISIBLE OR INVISIBLE LASER RADIATION WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM. <CAUTION> • Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
  • Page 2 CAUTION: CAUTION TO PREVENT ELECTRIC SHOCK, MATCH RISK OF ELECTRIC SHOCK WIDE BLADE OF PLUG TO WIDE SLOT, DO NOT OPEN FULLY INSERT. ATTENTION: CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, POUR ÉVITER LES CHOCS ÉLECTRIQUES, DO NOT REMOVE COVER (OR BACK). INTRODUIRE LA LAME LA PLUS LARGE DE NO USER-SERVICEABLE PARTS INSIDE.

  • Page 3: Table Of Contents

    * Service menus, exploded view, PCB assembly, parts list and circuit diagrams are given in this manual to assist the service technician in maintaining the Model PD-6. * The following accessories are supplied with PD-6 as the standard accessories. PD-6 owner's manual, English...

  • Page 4: Specifications

    PD-6 Service Manual 1. SPECIFICATIONS SPECIFICATION UNIT 0 dBu = 0.775 V r.m.s. INPUT & OUTPUT REFERENCE LEVEL -18 dB / -20 dB (default) (Switchable by SETUP mode) ANALOG INPUT (CH 1 ~ 6) Connector XLR-3-31 type (Pin 1: GND, Pin 2: HOT, Pin 3: COLD) Input Impedance 10 kΩ...
  • Page 5 PD-6 Service Manual TIME CODE INPUT Connector XLR-3-31 type (Pin 1: GND, Pin 2: HOT, Pin 3: COLD) Format SMPTE / EBU Input Impedance 20 kΩ or more Standard Input Level 2 V p-p Minimum Input Level 0.25 V p-p...
  • Page 6 SHIFT REWIND DC + 12 ~ 18 V, MAX 500 mA. VBATT* DC voltage is output regardless of PD-6 POWER ON/OFF condition. DC 12 V IN Connector XLR-4-32 type, male Pin assignment Comply to PD-2. It functions regardless of PANEL LOCK key.
  • Page 7 PD-6 Service Manual OPERATION LOCATE MEMORY Cue Point Chunk: 100 EXT / INT BATT key DISPLAY Black & White LCD (128 x 64 dots) Bargraph level meter, various time display / mode, setting and battery remain display DIMENSIONS 329 (W) x 110 (H) x 245 (D) mm WEIGHT About 3.4 kg (without NP-1 type battery)

  • Page 8: Controls, Indicators & Connectors

    PD-6 Service Manual 2. CONTROLS, INDICATORS & CONNECTORS < FRONT PANEL Section > 7 9 8 18 19 21 22 18. [LOCATE] key 1. [POWER] switch 19. [CLEAR] keys 2. [SHIFT] key / LED 3. [CONTRAST / TC SETUP] key 20.
  • Page 9 PD-6 Service Manual < TOP PANEL Section > 13. [INPUT MODE] switch 1. [TC GEN] switch 14. [PHASE] switch 2. [FRAME] switch 15. [INPUT GAIN] knob 3. [CLOCK] switch 16. [HPF] knob 4. [FS/24] select switch 17. [HPF] switch 5. [REC TR] select switch 18.
  • Page 10 PD-6 Service Manual < SIDE PANEL (left) Section > 1. [ANALOG LINE OUT] connectors 6. [IEEE1394] connector 2. Internal monitor speaker 7. [USB] connector 3. [AUX I/O] connector 8. [EJECT] lever 4. [AUX OUT ATT] switch 9. Battery housing 5. [REMOTE] connector <...

  • Page 11: Software Update

    3. SOFTWARE UPDATE The PD-6 software can be updated by placing a software update file in the top directory tree on the 8 cm DVD-RAM disk formatted by PD-6. There are two ways of copying the software update file from PC to the disk. Read through the following procedures for proper software update.
  • Page 12 3-1-2. There is no ATAPI, IEEE1394 or USB DVD-RAM drive exists in your PC environment; NOTE: As mentioned in the PD-6 owner’s manual, depending on the operating system running on your computer, an IEEE1394 driver software must be installed in your computer to allow to recognize the UDF formatted PD-6 DVD-RAM disk as a rewritable medium prior to the software update.
  • Page 13 “mkXXXrev.bin” to the top directory of the DVD-RAM disk either by direct software file copy onto a 8 cm DVD- RAM bare disk or by putting PD-6 into the IEEE1394 mode and connecting to PC. 2) In the initialize stage, PD-6 automatically finds the firmware update file in the top directory tree and is put into the update mode.

  • Page 14: Service Menus

    PD-6 Service Manual 4. SERVICE MENUS Various Service menus in addition to the normal SETUP menus are available on PD-6 in order to judge if the unit is working correctly. 4-1. Accessing to Service Menus 1) Power on PD-6. 2) While holding down the STOP key, press the SETUP key.
  • Page 15 • USB keyboard To execute, press the ENTER knob in the condition that “Self Check” is highlighted. PD-6 automatically checks the above mentioned circuits. In order to skip one or some of the above checking items, press the EXIT key.
  • Page 16 4-5. Front Check This menu checks if the toggle / rotary / tact switches and LEDs on the PD-6 front panel are correctly working. To check the switches and LEDs operation on the front panel, select the “Front Check” Service menu and press the ENTER knob.
  • Page 17 4-6. Mixer Check This menu checks if the toggle / rotary / tact switches and LEDs on the PD-6 top panel are correctly working. To check the switches and LEDs operation on the top panel, select the “Front Check” Service menu and press the ENTER knob. To get out of this menu, press the ENTER knob again.
  • Page 18 (i.e. power shutdown, blackout). The Flash ROM Card PCB allows to boot up PD-6, copy the system software in the Flash ROM Card PCB to the Flash ROM on the PD-6 MAIN PCB using this “Flash ROM”...
  • Page 19 SERVICE menu select display. With the above procedures, the program inside the Flash ROM on the PD-6 MAIN PCB is transferred to the Flash ROM on the Flash ROM Card PCB. • Rewriting Flash ROM Program on the MAIN PCB 1) Power off PD-6 and disconnect the power cable from the AC adapter AD-15C or remove the NP-1 type internal battery.

  • Page 20: Error Code List

    Too much disc fragmentation (discontinuous sector region) exceeding the UDF management while record- ing an audio files. The disc on which editings were executed on PC were used on PD-6. This error rarely occurs. The cause could be other than PD-6.
  • Page 21 UDF Logical Volume Integrity, it is rewritten. No BWFF Dir. The BWF folder does not exist. The disc formatted by other than PD-6 was used. This does not cause any problems. NewFile Failed! Creating a new audio file when REC mode was initiated failed.

  • Page 22: Exploded View, Pcb Assembly & Parts List

    PD-6 Service Manual 6. EXPLODED VIEW, PCB ASSEMBLY & PARTS LIST PD-6 OVERALL EXPLODED VIEW 1 Parts List Ref. No. Part No. Description Ref. No. Part No. Description 8221 3900 00 Panel, side, L, PD-6 8226 2750 02 Knob, rotary, D...
  • Page 23 PD-6 Service Manual PD-6 OVERALL EXPLODED VIEW 1 M 2 x 10 BZn 2.6 x 8 Cable assy (BLK) Cable assy (BLK) Cable assy (RED) To J1152 Cable assy (RED) Attached to the connector Nut, M4 BBT 3 x 6 BZn BBT 2.6 x 8 BZn...
  • Page 24 PD-6 Service Manual PD-6 OVERALL EXPLODED VIEW 2 B 3 x 6 BZn B 3 x 6 BZn B 3 x 6 BZn Attached to VR B 3 x 6 BZn B 3 x 6 BZn Precision 2.6 x 6...
  • Page 25 PD-6 Service Manual PD-6 OVERALL EXPLODED VIEW 1 Parts List (continued) Ref. No. Part No. Description Ref. No. Part No. Description 8214 4033 00 Spring, cover, PD-6 8260 5930 00 Cushion assy, PD-6 8223 3150 00 Sleeve, open, PD-6 8204 2440 00 PSW, 2.1 x 4 x 0.5...
  • Page 26 PD-6 Service Manual PD-6 OVERALL EXPLODED VIEW 3 Parts List Ref. No. Part No. Description Ref. No. Part No. Description 8221 4310 00 Plate, cover, lock, PD-6 8204 2250 04 Washer, RET-RING E-2 ZMB 8221 4000 00 Bracket, cover, PD-6...
  • Page 27 PD-6 Service Manual PD-6 OVERALL EXPLODED VIEW 3 B 3 x 6 BZn...
  • Page 28 PD-6 Service Manual PD-6 PCB ASSEMBLIES • Parts Side of ADDA PCB D605 D304 D104 D204 D404 D604 D103 D105 D203 D205 D303 D403 D405 D503 D504 D505 D603 D305 Q102 D106 D206 D306 D506 D606 D406 Q101 C229 C429...
  • Page 29 PD-6 Service Manual • Foil Side of ADDA PCB U207 U607 U507 U407 U307 U107 R623 R523 R423 R223 R123 R323 R634 R534 R434 R234 R134 R334 R630 R530 R430 R330 R230 R130 U503 U303 U103 U603 U403 U203 R544...
  • Page 30 PD-6 Service Manual • Parts Side of INPUT AMP PCB REC TR S404 S204 S604 88.2 44.1 C103 C303 C503 C203 C403 C603 C209 C409 C609 48/16 44.1/16 CLOCK DIGITAL R621 R121 R221 R321 R421 R521 FRAME 29.97 23.976 TC GEN...
  • Page 31 PD-6 Service Manual • Foil Side of INPUT AMP PCB D202 C608 C108 C508 C208 C408 C308 U401 U301 U201 U101 C606 C506 C406 C306 C206 C106 C613 C611 C513 C511 C413 C411 C313 C311 C213 C211 C113 C111 R616...
  • Page 32 PD-6 Service Manual • Parts & Foil Side of INPUT SEL PCB J701 XLR IN J702 XLR IN BLACK C701 C704 C703 U701 L702 L701 S401 S501 S301 S101 S201 S601 INAMP INAMP PCB,INPUT SEL,PD-6 INAMP INAMP 8252515104 • Parts & Foil Side of PHONES PCB...
  • Page 33 PD-6 Service Manual • Parts Side of MAIN PCB...
  • Page 34 PD-6 Service Manual • Foil Side of MAIN PCB...
  • Page 35 PD-6 Service Manual R819 R809 R843...
  • Page 36 PD-6 Service Manual...
  • Page 37 Part No. Description D351 8234 5059 00 ST, 1SS355TE-17 D352 8234 5029 00 ST, DAP202K-T146 8274 3940 00 PCB assy, AD/DA-2, PD-6 D353 8234 5029 00 ST, DAP202K-T146 B00001 8251 7240 00 Plain PCB, AD/DA-2, PD-6 D551 8234 5059 00 ST, 1SS355TE-17...
  • Page 38 PD-6 Service Manual Ref. No. Part No. Description Ref. No. Part No. Description R141 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% C102~602 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R R142 8230 5081 01 ST, array, 100Ω x 4, 5%, CN1J4 C103~603 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R...
  • Page 39 W00103 W00302 • XLR IN PCB assy W00303 Ref. No. Part No. Description W00502 8274 3740 00 PCB assy, XLR In, PD-6 W00503 B001 8252 5160 02 Plain PCB, XLR In, PD-6 Ref. No. Part No. Description J101~601 8245 2680 02 CONN, PL, jack, XLR31, NC3FAH2 •...
  • Page 40 Description Ref. No. Part No. Description R001 8230 5108 22 ST, carbon, 1/15W, 8.2kΩ, 5% 8274 3730 00 PCB assy, Front, PD-6 R002 8230 5108 22 ST, carbon, 1/15W, 8.2kΩ, 5% B001 8252 5162 01 Plain PCB, Front, PD-6 R003 8240 2980 04 POT, PI , RK12, 10kΩA x 2,...
  • Page 41 8207 0100 04 Spacer, LED, 4 C107~607 8233 0551 05 ST, ALU, 50V, 1µF, 20%, MV Y007 8216 7921 00 Spacer, LED, LCD, PD-6 C301 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C302 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C304 8233 0491 06 ST, ALU, 16V, 10µF, 20%, MV...
  • Page 42 Part No. Description C003 8233 3314 76 ST, ALU, 6.3V, 47µF, 20%, MVA 8274 3690 00 PCB assy, Input Amp, PD-6 C004, 05 8233 0491 06 ST, ALU, 16V, 10µF, 20%, MV B001 8252 5151 01 Plain PCB, Input Amp, PD-6 C101~601 8232 2962 26 VT, ALU, 50V, 22µF, 20%, LLA...
  • Page 43 Part No. Description Ref. No. Part No. Description 8274 3760 00 PCB assy, LCD, PD-6 8274 3790 00 PCB assy, Input Sel, PD-6 B001 8252 5171 01 Plain PCB, LCD, PD-6 B001 8252 5151 04 Plain PCB, Input Sel, PD-6 RESISTORs Ref.
  • Page 44 8236 5710 02 ST, DG, driver, IMH11A Ref. No. Part No. Description U710~712 8236 5657 00 ST, DG, NJU4051BV 8274 3770 00 PCB assy, Main, PD-6 U713 8236 5658 00 ST, DG, NJU4052BV B00002 8251 7214 00 Plain PCB, Main, PD-6 U714, 15...
  • Page 45 PD-6 Service Manual Ref. No. Part No. Description Ref. No. Part No. Description U1155 8236 5455 41 ST, TSSOP, 74VHC541 R021 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5% U1156 8236 0899 00 TSOP, DG, FROM, M29W010B R022, 23 8230 5101 12 ST, carbon, 1/15W, 1.1kΩ, 5%...
  • Page 46 PD-6 Service Manual Ref. No. Part No. Description Ref. No. Part No. Description R765 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5% R858 8230 5102 23 ST, carbon, 1/15W, 22kΩ, 5% R766 8230 5103 34 ST, carbon, 1/15W, 330kΩ, 5% R859 8230 5104 72 ST, carbon, 1/15W, 4.7kΩ, 5%...
  • Page 47 PD-6 Service Manual Ref. No. Part No. Description Ref. No. Part No. Description R1038, 39 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R1199 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% R1040 8230 5101 05 ST, carbon, 1/15W, 1MΩ, 5% R1200 8230 5102 70 ST, carbon, 1/15W, 27Ω, 5%...
  • Page 48 PD-6 Service Manual Ref. No. Part No. Description Ref. No. Part No. Description C095, 96 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C781, 82 8233 5121 01 ST, CER, 50V, 100pF, 5%, CC11SL C097 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C783 8233 0491 06 ST, ALU, 16V, 10µF, 20%, MV...
  • Page 49 PD-6 Service Manual Ref. No. Part No. Description Ref. No. Part No. Description C1025 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C1100 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C1026 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C1101 8233 0491 06 ST, ALU, 16V, 10µF, 20%, MV...
  • Page 50 J1152 8245 4170 40 CONN, PI, header, 40P, Ref. No. Part No. Description FX2C-40P-1.27DSAL 8274 3700 00 PCB assy, Power, PD-6 J1153 8245 4130 00 CONN, PL, 1394, YKF45-5003 B001 8252 5151 02 Plain PCB, Power, PD-6 L181 8242 5000 21 Coil, ST, 22µH, LFC32...
  • Page 51 PD-6 Service Manual RESISTORs Ref. No. Part No. Description Ref. No. Part No. Description C819 8233 3463 37 ST, ALU, 10V, 330µF, 20%, CV-EX C820 8233 5204 74 ST, CER, 25V, 0.47µF, 20%, GRM21 R801 8230 5102 21 ST, carbon, 1/15W, 220Ω, 5% R802 8230 5111 62 ST, carbon, 1/15W, 1.6kΩ, 1%...

  • Page 52: Circuit & Block Diagrams

    PD-6 Service Manual 4. CIRCUIT & BLOCK DIAGRAMS...
  • Page 53 PD-6 Service Manual...
  • Page 54 PD-6 Service Manual...
  • Page 55 PD-6 Service Manual...
  • Page 56 PD-6 Service Manual...
  • Page 57 PD-6 Service Manual...
  • Page 58 PD-6 Service Manual...
  • Page 59 PD-6 Service Manual...
  • Page 60 PD-6 Service Manual...
  • Page 61 PD-6 Service Manual...
  • Page 62 PD-6 Service Manual...
  • Page 63 PD-6 Service Manual U1032 C1021 U1005 D+5.5 PQ1X501M2ZP 0.01UF 74VHC04 VOUT C1005 DGND 1/50MV C1009 0.1UF C1012 C1033 C1013 VCO_GND 0.01UF L1001 10/16MV 0.01UF ---CLOCK MODE--- C1010 10/16MV 22UH-LFC32 48KHz L H 512fs (24.576MHz) 96KHz H L 256fs (24.576MHz) R1001...
  • Page 64 PD-6 Service Manual...
  • Page 65 PD-6 Service Manual U382 D+5.5 PQ1X501M2ZP VOUT C386 1/50MV C389 0.1UF C392 C399 C393 VCO_GND 0.01UF L381 10/16MV 0.01UF R384 4.7KJ 22UH-LFC32 U383 R385 10KJ C390 10/16MV 1 REF 2 PD LOCK 3 VDDA R381 R383 R386 4 AMPI L382...
  • Page 66 PD-6 Service Manual...
  • Page 67 PD-6 Service Manual...
  • Page 68 PD-6 Service Manual DISK FEED SW Position MODE 1-2,4-5 POST (PUSH ON) -20dBu 2-3,4-5 L BUS S103 20dBu 2-3,5-6 APE2F ST_BUS_L PFL_OUT[1] BUS/SLATE AGND PFL_ON[1] ROOT S101 S103 BUS/SLATE A-24JB APE2F IN_VOL[1] POST[1] -20dBu R103 10KF ANA[1] R106 15KJ BUS_L...
  • Page 69 PD-6 Service Manual DISK FEED SW Position MODE 1-2,4-5 POST (PUSH ON) -20dBu 2-3,4-5 L BUS S303 20dBu 2-3,5-6 APE2F ST_BUS_L PFL_OUT[3] BUS/SLATE AGND PFL_ON[3] ROOT S301 BUS/SLATE A-24JB S303 APE2F IN_VOL[3] POST[3] -20dBu R303 10KF ANA[3] R306 15KJ BUS_L...
  • Page 70 PD-6 Service Manual DISK FEED SW Position MODE 1-2,4-5 POST (PUSH ON) -20dBu 2-3,4-5 L BUS S503 20dBu 2-3,5-6 APE2F ST_BUS_L PFL_OUT[5] BUS/SLATE AGND PFL_ON[5] ROOT S501 BUS/SLATE A-24JB S503 APE2F IN_VOL[5] POST[5] -20dBu R503 10KF ANA[5] R506 15KJ BUS_L...
  • Page 71 PD-6 Service Manual...
  • Page 72 PD-6 Service Manual...
  • Page 73 PD-6 Service Manual...
  • Page 74 PD-6 Service Manual...
  • Page 75 PD-6 Service Manual...
  • Page 76 PD-6 Service Manual...
  • Page 77 PD-6 Service Manual...
  • Page 78 PD-6 Service Manual...
  • Page 79 PD-6 Service Manual PH_VOL_L PH_VOL_R MONITOR VOL. R702 RK09-SW-SPDT 10KAx2 PH_IN_L J703 L701 EXC3BP,120 PH_IN_R HEADPHONE JACK L702 Monitor, EXC3BP,120 MAIN J701 PH_OUT_L J702 PH_OUT_R YKB21-5006 ZH-9P-L Open when HP jack is Open when DGND plugged in. (SP OFF) AGND_PH...
  • Page 80 PD-6 Service Manual...
  • Page 81 PD-6 Service Manual...
  • Page 82 PD-6 Service Manual...

  • Page 83: Location Of Identification / Certification Label

    Numerical Numbers Identification label (4 digits) digit digit This product complies with 21 CFR part 1040.10 Manufacturer & Address: FOSTEX CO. 3-2-35 MUSASHINO, AKISHIMA, TOKYO, JAPAN 196-0021 Manufacturing Site: TOKUSHUSEIKI Production Serial Number Date Serial number label Production Date 1st digit...
  • Page 84 FOSTEX CO. 3-2-35 Musashino, Akishima, Tokyo, Japan 196-0021 FOSTEX AMERICA 15431 Blackburn Ave., Norwalk, CA 90650, U.S.A. © PRINTED IN JAPAN JUL. 2003 8288809000...
