- Page 1 INSTALLATION MANUAL FT-VIDEO-LVDS AUD4 REV 161117...
- Page 3 • DVD and TV can be controlled via steering wheel commands and iDrive • 12V, ACC and CAMERA output • Plug and play connections • 1-year warranty against manufacturer defect • Compatible vehicles: www.faaftech.com/produtos/interface-de-video/ft-lvds-aud4 *3rd AV input can be setup to be used as AV, NAV or Front Camera.
-
Page 4: Dip Switches
DIP 5 Cars with a 5,8” screen: DIP 4 and DIP 5 DOWN TV and DVD selection FT-TV-1SEG DIP 6 up DIP 7 down FT-TV-1SEGII TV FAAFTECH DIP 6 down DIP 7 down FT-TV-1SEG III FT-TV-HD II TV LBSAT LBCR-1100... - Page 5 CONNECTIONS Plug in to the radio located Plug in to inside the glove compartment the whip Plug in to Plug in to the Pink or Gray the whip LVDS plug on the radio Connect to the AUX input in the console or in the glove compartment DATA OUT/ SELECT...
-
Page 6: Accessory Connections
ACCESSORY CONNECTIONS Check an example of an installation with a DVD, TV, front camera in the AV3 input, and a rear camera. Use the auxiliary outputs to power the accessories, such as DVD, TV and camera, in case they are being installed MOBILE MULTI-MEDIA PLAYER Digital TV Receptor... - Page 7 FUNCTIONING Follow the steps below in order to access the accessories you have installed on the interface’s AV inputs. 1° Select the AUX audio input on the multimedia; 2° Press and hold the button on the steering wheel commands or the MENU button on the central console to access the interface’s AV mode;...
- Page 8 FUNCTIONING Check below the commands available to control the DVD and the TV through the vehicle’s original commands. Steering wheel commands MOVEMENT TV COMMANDS DVD COMMANDS Simply touch button 1 Channel - Track - Simply touch button 2 Channel + Track + Scan --------...
- Page 9 FUNCTIONING OF THE CAMERAS Rear Camera The rear camera will show automatically once you put the car on the reverse gear. When you spin the steering wheel, the parking guide lines will move, showing the approximate direction the vehicle will go to. Important Notice The parking guides are not 100% precise regarding to the way they show.
- Page 10 FUNCTIONING OF THE CAMERAS Camera Viewing You can view the installed cameras at any time by following the steps below: • Press and hold the OK button on the steering wheel for 3 seconds to view the rear camera; • Simply touch the OK button to switch between the rear and the front camera (in case both are installed);...
- Page 11 We recommend that you block the video while moving when you use the GPS. The utilization of the video while moving function is strictly forbidden to the driver and restricted to the passengers. FAAFTECH will not be held accountable for any damages caused by the misusage of this function.
-
Page 12: Setup Menu
SETUP MENU Check below how to access the setup menu of the FT-LVDS-AUD4: 1. Access the AV1 (DVD), AV2 (TV) or AV3 input; 2. After selecting one of those sources, press the iDrive and hold it for about 5 seconds to view the setup menu; 3. -
Page 13: Idioma (Language)
SETUP MENU AV2: Select the name of the auxiliary input AV2 (TV or AV2). AV3: AV3 – Select to use AV3 as the third audio/video input. NAV – Select to use AV3 as GPS. CAM FRONT – Select to use AV3 as a front camera input. Idioma (Language): PORTUGUES –... -
Page 14: Troubleshooting
TROUBLESHOOTING 1. After installing the interface, the multimedia won’t turn on. • Review the installation process and check if the connections have been done according to the images shown on pages 3 and 4; • Check if the connectors are plugged in tightly and if there are no wires loose on the connectors. - Page 15 WARRANTY FAAFTECH assures their clients a 01 (one) year period against defects in mate- rials and workmanship, proved by presenting both the receipt of purchase from the reseller to the costumer and the present Warranty Certificate filled, observ- ing the following: 1.
-
Page 16: Technical Support
TECHNICAL SUPPORT Follow us on social media +55 0800 603 2330 or +55 62 3241 4600 suporte@faaftech.com.br www.faaftech.com.br Available from Monday to Friday, from 8 a.m. to 6 p.m. Brasilia time...
