- Page 1 INSTALLATION MANUAL FT-VIDEO-LVDS AUD4 REV 161117...
- Page 3 PRESENTATION • Congratulations for purchasing the video interface FT-LVDS-AUD4. • Please, read this manual with attention before installing your new device. • Keep this manual with you to check the functioning procedures and the security information. • We recommend that a professional, with experience in the field of installation of vehicle devices, is the one to install this interface.
-
Page 4: Dip Switches
Cars with a 5,8” screen: DIP 4 and DIP 5 down DVD AND TV SELECTION DIP SWITCHES FT-TV-1SEG DIP 6 up and DIP 7 down FT-TV-1SEG II FAAFTECH TV DIP 6 down and DIP 7 down FT-TV-1SEG III FT-TV-HD II LBSAT TV... - Page 5 CONNECTIONS Connect to the radio located Connect to inside the glove compartment the whip Connect to Connect to the radio’s pink the whip or gray LVDS plug Connect to the AUX entry on the console or on the glove compartment DATA OUT/ SELECT UPDATE...
-
Page 6: Accessories Connections
Accessories Connections Check this example on the installation of a DVD, a TV, a front camera on the AV3 input and a rear camera. Use the auxiliary exits to power the accessories, such as DVD, TV and camera, if you install them. MOBILE MULTI-MEDIA PLAYER Receptor de TV Digital Rear Camera... - Page 7 FUNCTIONING Follow the steps bellow to access the accessories that are installed on the device’s inputs. 1st Select the AUX audio source from the multimedia; 2nd Press and hold the button (on the steering wheel) or the MENU button (on the dashboard or central console) to gain access to the interface’s AV mode; 3rd Simply touch the same button to toggle between the DVD (AV1), TV (AV2) and the AV3;...
- Page 8 FUNCTIONING See below the available commands to control the DVD and the TV through the vehicle’s original commands. Steering wheel commands Command TV command DVD command Simply touch the 1 button Channel - Track - Simply touch the 2 button Channel + Track + Hold the 2 button for 3 seconds...
-
Page 9: Camera Functions
CAMERA FUNCTIONS Rear Camera Once you put your vehicle on reverse, the rear camera will automatically show on the screen. As you spin the steering wheel, the parking lines will move, showing the vehicle’s approximate direction as you keep going. Important Notice: The parking lines do not offer 100% precision on the track they show. - Page 10 CAMERA FUNCTIONS Camera Visualization You can view your installed cameras at any point by following these steps: • Press and hold the OK button on the steering wheel for three seconds, to view your rear camera; • Simply touch the OK button if you want to alter between the rear camera and the front camera (in case both are installed);...
- Page 11 Video visualization is strictly forbidden to the vehicle’s driver. The visualization of video is reserved only to the passengers in the vehicle. FAAFTECH holds no responsibility over eventual damaged caused by the poor usage of this function.
-
Page 12: Setup Menu
SETUP MENU See below how you can access the FT-LVDS-AUD4 Setup Menu: 1st Access AV1 (DVD), AV2 (TV) or AV3; 2nd Press the iDrive button and hold for about 5 seconds to open the setup menu; 3rd Turn the iDrive left or right to choose between the menu functions and press the button to select the function you want. -
Page 13: Idioma (Language)
SETUP MENU AV2: Chooses the name of auxiliary entry AV2: TV or AV2. AV3: AV3 – Choose this option if you want to use AV3 as a third audio/video input. NAV – Choose this option if you want to use AV3 for the GPS. CAM FRONT –... - Page 14 Problem Solving 1. After installing the interface, the multimedia won’t turn on. • Review the installation and check if the cables are connected according to the images on pages 3 and 4; • Check if all the cables are well connected, and if there are no wires coming out of the connectors.
-
Page 15: Warranty
Warranty FAAFTECH assures their clients a 01 (one) year period against defects in materials and workmanship, proved by presenting both the receipt of purchase from the reseller to the costumer and the present Warranty Certificate filled, observing the following: 1. FAAFTECH will null the warranty if Faaftech or their authorized technical... -
Page 16: Technical Support
TECHNICAL SUPPORT Follow us on social media +55 0800 603 2330 or +55 62 3241 4600 suporte@faaftech.com.br www.faaftech.com.br Available from Monday to Friday, from 8 a.m. to 6 p.m. Brasilia time...
