- Page 1 Installation Manual FT-RC-AUD3 REV 220616...
- Page 2 PRESENTATION • Congratulations for purchasing the video interface FT-RC-AUD3. • Please, read this manual with attention before installing your new device. • Keep this manual with you to check the functioning procedures and the security information. • We recommend that a professional, with experience in the field of installation of vehicle devices, is the one to install this interface.
-
Page 3: Setup Dip Switches
INSTALLING Follow the steps below to install the FT-RC-AUD3 interface: 1st Remove the original radio to install the interface; 2nd Setup the interface’s DIP Switches according to the chart on “DIP SWITCH- ES” section; 3rd Connect the whips according to the “CONNECTIONS” section;... - Page 4 CONNECTIONS Connect to the Connect to the whip radio Connect to the Connect to the radio’s whip LVDS GREY or PINK plug VIDEO UPDATE SELECT IN/POWER...
-
Page 5: Camera Connections
CAMERA CONNECTIONS VIDEO UPDATE SELECT IN/POWER *Front Camera *Rear Camera *Cameras sold separately. -
Page 6: Rear Camera
FUNCTIONING Rear Camera Once you put your vehicle on reverse, the rear camera will automatically show on the screen. As you spin the steering wheel, the parking lines will move, showing the vehi- cle’s approximate direction as you keep going. Press the OK button on the steering wheel while you are on gear to alter between the rear camera visualization and the parking sensor. - Page 7 FUNCTIONING Camera Visualization You can view the installed cameras while the vehicle is moving at any time, by following the steps below: • Press and hold the OK button on the steering wheel for 3 seconds. This will show you the rear camera; •...
-
Page 8: Troubleshooting
3. On the rear camera or on the front camera, I see an “incompatible video” message. • Check if the installed camera is compatible. FT-RC-AUD3 only works with a NTSC video system camera, any other format is not compatible; 4. When I switch my car out of gear, I see a “front camera” message, and the screen goes black with a “No Signal”... -
Page 9: Warranty
WARRANTY FAAFTECH assures their clients a 01 (one) year period against defects in mate- rials and workmanship, proved by presenting both the receipt of purchase from the reseller to the costumer and the present Warranty Certificate filled, observ- ing the following: 1. -
Page 10: Technical Support
TECHNICAL SUPPORT Follow us on social media +55 0800 603 2330 or +55 62 3241 4600 suporte@faaftech.com.br www.faaftech.com.br Available from Monday to Friday, from 8 a.m. to 6 p.m. Brasilia time...
