ADURO H1 Update Manual

ADURO H1- SYSTEM UPDATES VIA SD CARDS
In this guide we will illustrate how to access the control board to update the stove's
system. Normal updates are automatically via internet and do not require a technical
intervention.
IMPORTANT: ONLY PERFORM UPDATES VIA SD CARD IF INSTRUCTED DIRECTLY BY
THE COMPANY. ALWAYS UNPLUG THE STOVE FROM THE POWER SUPPLY WHEN
PERFORMING MANTAINANCE OPERATIONS.
HOW TO ACCESS THE CONTROL BOARD
Important: The control board is located in the bottom left
part of the stove. You can access from the front or the
back of the stove. Use great caution when handling the
board as any damage (due to impact, liquid, moisture, dirt
or other) might have serious consequences.
You will need:
A dry cloth.
A screwdriver with Torx bits.
A small clipper (or wire cutter)
A MICRO SD card.
BACK ACCESS
Accessing from the back is the easiest way to
reach the MICRO SD card slot on the control
board. To do so:
1- Clean the back of the stove with a dry cloth
to remove all dust and dirrt that might
otherwise come in contact with the board.
2 - Carefully remove the 4 tork screws on the
left and right side of the panel.
3 – it might by easier to reach the slot by
clipping the fastener holding the cables on the
back of the board.
Now you can access the SD CARD slot on the
control board.
adurofire.com ∙ tips.adurofire.com ∙ aduroshop.com ∙ info@aduro.dk adurofire.com ∙ tips.adurofire.com ∙ aduroshop.com ∙ info@aduro.dk
Aduro H1 – where to find the
control board
Screws holding the back panel
