PREFACE

This Installation and Operation Guide provides installation and operation instructions for the
CTI 2553 Two Channel Isolated MAG METER Module for SIMATIC® 505 Series programmable
controllers. We assume you are familiar with the operation of SIMATIC® 505 Series programmable
controllers. Refer to the appropriate SIMATIC® user documentation for specific information on the
SIMATIC® 505 Series programmable controllers and I/O modules.
This Installation and Operation Guide is organized as follows:
Chapter 1 provides a description of the module.
Chapter 2 covers installation and wiring.
Chapter 3 is a guide to troubleshooting.
Figure 1 The Model 2553 2-Channel Isolated MAG METER Input
