After discharging any static build-up, remove the module from the static bag. Do not discard the static
bag. Always use this bag for protection against static damage when the module is not inserted into the
I/O backplane.

2.4 Configuring the Module

The Model 2553 must be configured to operate in normal counting mode or N-Tooth counting mode.
The module must also be configured to report the measurements in "Frequency" or "Period" and digital
filtering/no filtering mode before inserting the module into the I/O base. As shipped, the module is
configured for normal counting mode, "Frequency" and digital filtering disabled
(see Figure 5).
Changing the module input channel configuration involves the following steps:
1. Select Normal or N-Tooth Counting mode for each channel.
2. Select the number of teeth on the wheel (N-Tooth mode only).
3. Select frequency or period measurement for the module.
4. Select digital filtering or no filtering for the module.
5. Select proper input signal conditioning.
Each of these steps is described in the following sections.
6

Figure 5 Jumper Locations
