QU-AX GentlemenBike Owner's Manual

GentlemenBike
Owners manual
Thanks for buying a quality product. QU-AX wishes you lots of fun with this cool
and relaxed bicycle. This should be the content of your box:
36" Wheel incl. tire & cranks
Frame incl. fork, rear-wheel, brake
both sides. Tighten only as much as wheel still runs free easily. The right crank is marked
with "R" on the inside of the crank. The pedal is marked the same way on the axle, too.
Take care to assemble it with the crank on the right side and the pedal in the right crank.
The right pedal is tightened by screwing it in clockwise with a 15mm wrench, the left pedal
by screwing it in counter-clockwise.
bearing-cups,
screws
pedals
Wheel and pedals
Start by placing the wheel
into the fork take care
to put it in in the right
direction! The cranks are
marked with "R" for right
and "L" for left. Then, put
the bearing cups on and put the screws and nuts on like on the photo at
the left. Make sure both sides are tightened equally so that the distance
between frame and cups is same on
saddle incl.
mount
handlebar & stem
incl. brake-lever
assembly-instructions
