Quick Installation Guide
150Mbps Wireless N ADSL2+ Modem Router
TD-W8151N
Connecting the Hardware
If you don't need the phone service, just directly connect the modem router
to the phone jack with a phone cable, then follow steps 3 and 4 to complete
the hardware connection.
Power adapter
Modem Router
3
Turn on the modem router.
2
Connect the modem router to the
ADSL splitter.
ADSL splitter
Connect to the phone (Optional)
4
Verify that the hardware connection
is correct by checking these LEDs.
Power
ADSL
Wireless
On
On
On
Notes:
1. The ADSL LED
takes about 1 to 2 minutes to stabilize.
2. If the Wireless LED
is off, please press the WIFI button on the rear
panel for 2 seconds, then check the LEDs again in a few seconds.
Phone jack
1
Connect the ADSL splitter
to the phone jack.
