Configuring the Modem Router
1. Connecting your computer to the modem router (Wired
or Wireless).
Wired
Connect the computer to the LAN port on your modem router with an Ethernet
cable.
Ethernet cable
WIFI
ON/OFF
WPS/
POWER RESET LAN ADSL
Wireless
a. Find the SSID (network name) and
Wireless Password printed on the
product label at the bottom of the
modem router.
b. Click the network icon of your computer or go to Wi-Fi Setting of your smart
device, then select the SSID to join the network.
Connections are available
Wireless Network Connection
OR
TP-LINK_XXXX
Connect automatically Connect
√
Computer
2. Configuring the modem router via a web browser.
Please consult your ISP (Internet Service Provider) for the following information
before configuring the modem router.
ISP Connection Type:_______ VPI:_______ VCI:_______
Connection Type (Encapsulation Type):_______
If your ISP Connection Type is PPPoE/PPPoA, please get further information of
your account username and password.
A Enter http://tplinkmodem.net or 192.168.1.1 in the address bar of a web
browser. Use admin for both username and password, and then click Login.
Note: If the login window does not appear, please refer to FAQ > Q1.
http://tplinkmodem.net
Username: admin
Password: admin
Login
B Select Quick Start from the menu and click RUN WIZARD.
Quick
Start
This ADSL Router is ideal for ......
C A Quick Start window will pop up. Click NEXT, and select your Time Zone, then
click NEXT.
D Complete the Internet Settings with the information provided by your ISP and
click NEXT. Here we use PPPoE/PPPoA for demonstration.
Notes:
1. Per FCC regulations, all Wi-Fi products marketed in the U.S. must be fixed to the U.S. region only.
2. All the Internet settings in the figure below are used for demonstration only. If you are unsure of the
Internet settings, please contact your ISP.
Quick Start - Internet Settings
< Settings Wi-Fi
Wi-Fi
CHOOSE A NETWORK...
TP-LINK_XXXX
E Verify or change the Wlan settings (wireless network settings) and click to continue.
Other...
Note: You may personalize your SSID (wireless network name) and key. Once done, you will have to
reconnect to your wireless network using the new SSID and key.
Smart Device
Quick Start - Wlan
Click SAVE to complete the configuration.
F
Interface Advanced Access
Maintenance Status
Setup Setup Management
RUN WIZARD
Country: Other
ISP: Other
ISP Connection Type: PPPoE/PPPoA
Username: XXXXXXXXXXX
Password:
*************
VPI: 8 (0~255)
(32~65535)
VCI: 35
Connection Type: PPPoE LLC
BACK
Access Point : Activated Deactivated
SSID : TP-LINK_XXXXXX
Broadcast SSID : Yes No
Authentication Type: WPA2-PSK
Encryption : AES
Pre-Shared Key : XXXXXXXX
BACK
FAQ (Frequently Asked Questions)
Help
Q1. What can I do if the login page does not appear?
A1. Make sure the computer is connected to the modem router properly.
A2. If the computer is set to a static or fixed IP address, change it to obtain an IP address
automatically from the modem router.
A3. Verify http://tplinkmodem.net is correctly entered in the web browser and press Enter.
A4. Use another web browser and try again.
A5. Reboot your modem router and try again.
A6. Disable and enable the active network adapter.
Q2. What can I do if I cannot access the Internet?
A1. Make sure the telephone and Ethernet cables are plugged in correctly.
A2. Try to log into the web management page of the modem router using the default
address at http://tplinkmodem.net. If you can, try the following answers. If you cannot,
change your computer to obtain an IP address automatically from the modem router.
A3. Consult your ISP and make sure all the VPI/VCI, Connection Type, account username and
password are correct. If they are not, please replace them with the correct settings and try
again.
A4. Restore the modem router to its factory default settings and reconfigure the modem
router by following the instructions in this Quick Installation Guide.
A5. Please contact our Technical Support if the problem still exists.
Q3. How do I restore the modem router to its factory default
settings?
A1. With the modem router powered on, press and
hold down the WPS/RESET button on the rear
panel of the modem router for at least 10
seconds until some LEDs go off, then release
the button.
NEXT EXIT
A2. Log into the web management page of the
modem router, and go to Maintenance >
SysRestart, select Factory Default Settings
and click RESTART, then wait until the reset
process is complete.
Q4. What can I do if I forget my password?
Web Management page password:
Refer to FAQ > Q3 to reset the modem router, and then use admin (all lowercase) for both
username and password to log in.
Wireless Network password:
A1. The default Wireless Password/PIN is printed on the product label of the modem router.
A2. If the default wireless password has been changed, log into the modem router's web
management page and go to Interface Setup > Wireless to retrieve or reset your
password.
NEXT EXIT
Q5. What can I do if the ADSL LED
A1. Check your cables and make sure they are all plugged in correctly, including the
telephone lines and power adapter.
A2. Manually change your DSL settings. Log into the modem router's web management page.
Go to Advanced Setup > ADSL, change the ADSL Mode to G.DMT, and click SAVE. If
this cannot work, try to change the ADSL Mode to ADSL2 and click SAVE.
A3. Restore your modem router to its factory default settings.
A4. Remove the ADSL splitter, directly connect the modem router to the phone jack and then
reconfigure the modem router by following the instructions in this Quick Installation
Guide.
A5. Contact your Internet service provider to verify if the ADSL line is in good status.
A6. If you have tried all the suggestions above and the problem still exists, contact our
Technical Support.
WIFI
WPS/
ON/OFF POWER LAN
RESET
WPS/RESET Button Press & Hold 10 seconds
does not turn solid on?
