Sharp KSH-206 Service Manual

Automatic rice cooker
Hide thumbs

Advertisement

SHARP SERVICE MANUAL
PARTS IDENTIFICATION AND SPECIFIC INFORMATION ..................................................
CAUTIONS FOR USE............................................................................................................
HOW TO CLEAN THE COOKER...........................................................................................
WIRING DIAGRAM AND CIRCUIT DIAGRAM.......................................................................
METHOD OF OPERATION....................................................................................................
ADJUSTMENT OF SWITCH LEVER AND CONTACTS.........................................................
INSPECTION AFTER REPAIRING.........................................................................................
TESTING OPERATING CONDITION......................................................................................
PROBLEMS AND SOLUTIONS..............................................................................................
SERVICE PARTS LIST...........................................................................................................
AUTOMATIC RICE COOKER
MODELS
In the interests of user-safety (Required by safety
regulation in some countries) the set should be
restore to its original condition and only parts identical
to those specified should be used.

TABLE OF CONTENTS

SHARP CORPORATION
KSH-206 / 211
KSH-215 / 218
KSH-222 / 228
Page
2
3
3
4
5
6 - 7
8
8
9
10-26

Advertisement

loading

  Summary of Contents for Sharp KSH-206

  • Page 1: Table Of Contents

    SHARP SERVICE MANUAL AUTOMATIC RICE COOKER MODELS KSH-206 / 211 KSH-215 / 218 KSH-222 / 228 In the interests of user-safety (Required by safety regulation in some countries) the set should be restore to its original condition and only parts identical to those specified should be used.
  • Page 2: Parts Identification And Specific Information

    Knob “WARM” indicator lamp Upper lid “COOK” indicator lamp Inner pot Handle Panel Outer pot Power cord plug Cook switch (Model KSH-206 cord is fixed with the pot) SPECIFIC INFORMATION Model KSH-206 KSH-211 KSH-215 KSH-218 KSH-222 KSH-228 Rated voltage (V)
  • Page 3: Cautions For Use

    8. In case the power cord is broken, it must be replaced by manufacturer or appointed service providers or equivalent professionals to avoid any damages. (Model : KSH-206) In case the power cord is broken, it must be replaced with specialized power cord or the standard power cord made by manufacturer or appointed service providers.
  • Page 4: Wiring Diagram And Circuit Diagram

    WIRING DIAGRAM Model : KSH-206 Neon lamp ass’y Terminal AMP (D) Tube Closed terminal Micro SW. Connecting ring Warm heater ass’y Blue Power cord Terminal AMP (D) Heater plate ass’y Tube Cord stopper Temp. fuse ass’y Brown Model : KSH-211 KSH-215 Neon lamp ass’y...
  • Page 5: Method Of Operation

    METHOD OF OPERATION Different degree of temperature at various parts of the cooker during its operation. HEATER PLATE INNER POT 100 C THERMOSTAT RICE TEMPERATURE THERMOSTAT CUTS OFF TIME 30 MINUTES After being switch “ON” the operation will be started by generating heat from the heater plate and spread through the bottom of inner pot.
  • Page 6: Adjustment Of Switch Lever And Contacts

    ADJUSTMENT OF SWITCH LEVER AND CONTACTS 1. Turn over the outer pot with inner pot inside, disclose its bottom lid. Push cook switch, adjust switch lever and switch angle. Bottom lid Outer pot Cook switch Inner pot A. Thermostat rod must not be drew up by switch lever. It should be moving left and right easily. Micro switch Switch lever Micro switch...
  • Page 7 2. As soon as inner pot is lifted up from outer pot, switch lever must be spring up and micro switch is pressed completely. This rice cooker is so designed that the cook switch will not be put in “COOK” position whenever the inner pot is taken off or not set into the cooker before use.
  • Page 8: Inspection After Repairing

    INSPECTION AFTER REPAIRING 1. Cook switch should be at the center of panel. 2. Ensure that there is no any contaminants, deposits, stains exist on heater plate, thermostat and outside bottom of inner pot. 3. Firmly put inner pot inside the cooker, move inner pot right and left to ensure it can be closely contact with outer pot.
  • Page 9: Problems And Solutions

    PROBLEMS AND SOLUTIONS Problems Possible causes Solution Check . Incompletely cooked 1. Adjust or replace. Boil about 800 cc. of 1. Inner pot improperly rice. water. Check the state contacted with heater of bubbles at the bottom plate. of inner pot. 2.
  • Page 10: Service Parts List

    SERVICE PARTS LIST KSH-206 PARTS CODE REF. NO DESCRIPTION Q’TY PRICE (FEC) PRINTING & PACKAGING MATERIAL 1B631 * INSTRUCTION BOOK 1U6018 SET PACKING CASE 1U604 CARTON BOX 21A5062 MEASURING CUP 1U6052 BOTTOM PAD 1U6092 UPPER PAD MECHANICAL PARTS 1U1033BASY UPPER LID ASS’Y...
  • Page 11 PARTS CODE REF. NO DESCRIPTION Q’TY PRICE (FEC) ELECTRIC PARTS 1U4187 POWER CORD PLUG 1U2014 * HEATER PLATE ASS’Y 1U2021ASY * THERMOSTAT ASS’Y 1U4917ASY NEON LAMP ASS’Y 1U2391 TEMP. FUSE ASS’Y 1U4201 WARM HEATER ASS’Y 2A410 MICRO SWITCH...
  • Page 12 KSH-211 PARTS CODE REF. NO DESCRIPTION Q’TY PRICE (FEC) PRINTING & PACKAGING MATERIAL 1B631 * INSTRUCTION BOOK 1A6029 SET PACKING CASE 1A6344 CARTON BOX 21A5062 MEASURING CUP 1A6052 BOTTOM PAD 1A6093 UPPER PAD MECHANICAL PARTS 1A1034BASY UPPER LID ASS’Y Sky Blue 1A1034GRASY UPPER LID ASS’Y Green...
  • Page 13 PARTS CODE REF. NO DESCRIPTION Q’TY PRICE (FEC) ELECTRIC PARTS 1B4934ASY POWER CORD ASS’Y 1A2014 * HEATER PLATE ASS’Y 1A2021ASY * THERMOSTAT ASS’Y 1A4917ASY NEON LAMP ASS’Y 1A2394 TEMP. FUSE ASS’Y 1A2076 WARM HEATER ASS’Y 2A410 MICRO SWITCH...
  • Page 14 KSH-215 PARTS CODE REF. NO DESCRIPTION Q’TY PRICE (FEC) PRINTING & PACKAGING MATERIAL 1B631 * INSTRUCTION BOOK 1J6019 SET PACKING CASE 1J6045 CARTON BOX 21A5062 MEASURING CUP 1J6052 BOTTOM PAD 1J6092 UPPER PAD MECHANICAL PARTS 1J1032BASY UPPER LID ASS’Y Sky Blue 1J1032GRASY UPPER LID ASS’Y Green...
  • Page 15 PARTS CODE REF. NO DESCRIPTION Q’TY PRICE (FEC) ELECTRIC PARTS 1B4934ASY POWER CORD ASS’Y 1J2011 * HEATER PLATE ASS’Y 1A2021ASY * THERMOSTAT ASS’Y 1J4918ASY NEON LAMP ASS’Y 1C2392 TEMP. FUSE ASS’Y 1B4201 WARM HEATER ASS’Y 2A410 MICRO SWITCH...
  • Page 16 KSH-218 PARTS CODE REF. NO DESCRIPTION Q’TY PRICE (FEC) PRINTING & PACKAGING MATERIAL 1B631 * INSTRUCTION BOOK 1B6032 SET PACKING CASE 1B6264 CARTON BOX 21A5062 MEASURING CUP 1B6052 BOTTOM PAD 1B6093 UPPER PAD MECHANICAL PARTS 1B1032BASY UPPER LID ASS’Y Sky Blue 1B1032GRASY UPPER LID ASS’Y Green...
  • Page 17 PARTS CODE REF. NO DESCRIPTION Q’TY PRICE (FEC) ELECTRIC PARTS 1B4934ASY POWER CORD ASS’Y 1B2012 * HEATER PLATE ASS’Y 1A2021ASY * THERMOSTAT ASS’Y 1B4951ASY NEON LAMP ASS’Y 1C2392 TEMP. FUSE ASS’Y 1B4201 WARM HEATER ASS’Y 2A410 MICRO SWITCH...
  • Page 18 KSH-222 PARTS CODE REF. NO DESCRIPTION Q’TY PRICE (FEC) PRINTING & PACKAGING MATERIAL 1B631 * INSTRUCTION BOOK 1H6015 SET PACKING CASE 1H6253 CARTON BOX 21A5062 MEASURING CUP 1H6511 BOTTOM PAD 1H6521 UPPER PAD MECHANICAL PARTS 1H1032BASY UPPER LID ASS’Y Sky Blue 1H1032GRASY UPPER LID ASS’Y Green...
  • Page 19 PARTS CODE REF. NO DESCRIPTION Q’TY PRICE (FEC) ELECTRIC PARTS 1H4931ASY POWER CORD ASS’Y 1G2011 * HEATER PLATE ASS’Y 1A2021ASY * THERMOSTAT ASS’Y 1H4919ASY NEON LAMP ASS’Y 1C2392 TEMP. FUSE ASS’Y 1G420 WARM HEATER ASS’Y 2A410 MICRO SWITCH...
  • Page 20 KSH-228 PARTS CODE REF. NO DESCRIPTION Q’TY PRICE (FEC) PRINTING & PACKAGING MATERIAL 1B631 * INSTRUCTION BOOK 1C6014 SET PACKING CASE 1C6253 CARTON BOX 21A5062 MEASURING CUP 1C6052 BOTTOM PAD 1C6092 UPPER PAD MECHANICAL PARTS 1C1032BASY UPPER LID ASS’Y Sky Blue 1C1032GRASY UPPER LID ASS’Y Green...
  • Page 21 PARTS CODE REF. NO DESCRIPTION Q’TY PRICE (FEC) ELECTRIC PARTS 1D492ASY POWER CORD ASS’Y 1C2011 * HEATER PLATE ASS’Y 1A2021ASY * THERMOSTAT ASS’Y 1C491ASY NEON LAMP ASS’Y 1C2392 TEMP. FUSE ASS’Y 1C420 WARM HEATER ASS’Y 2A410 MICRO SWITCH...
  • Page 22 2-1-2 2-1-1 2-1-3 2-1-4 2-11 2-10 KSH-206...
  • Page 23 2-1-2 2-1-1 2-1-3 2-1-4 2-11 2-10 KSH-211...
  • Page 24 2-1-2 2-1-1 2-1-3 2-1-4 2-11 2-10 KSH-215...
  • Page 25 2-1-2 2-1-1 2-1-3 2-1-4 2-11 2-10 KSH-218...
  • Page 26 KSH-222 KSH-228...

This manual is also suitable for:

Ksh-211Ksh-215Ksh-218Ksh-222Ksh-228
