- Page 1 ECGO-GKP Cellular Telephone Entry 4G with 3G Fallback Technology Setup Manual Read Prior to Installing ***For Professional Install Only...
-
Page 2: Table Of Contents
Set 5 digit PIN Code ............................... 8 Other Options ................................9 Settings ..................................9 Programming .................................. 10 Programming via Text ..............................10 Keypad Programming ..............................14 Operating the ECGO-GKP ..............................15 ECGO Warranty ................................16 2 | P a g e... -
Page 3: Important Safety Instructions
Important Safety Instructions When installing and using the unit, the following basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury. Unplug all the connections to the product before cleaning. Use a damp cloth for cleaning. Do not use •... -
Page 4: Introduction
Introduction The ECGO-GKP 4G is a telephone entry system installed at the entrance of a building or outside of a gated area. It is an ideal product to consider as a replacement for a traditional phone entry for the following reasons: •... -
Page 5: Installation Instructions
ECGO-GKP Control Board 4G or 3G SIM card Standard Size Only Please refer to the flyer included with your ECGO-GKP unit with detailed instructions for the consumer when selecting and purchasing your SIM card. The following should be noted: •... -
Page 6: Grounding Unit
1 wire for grounding run back to Main incoming power ground on gate operator Power Supply The ECGO-GKP is designed to work with power supplies 12V~24V AC/DC. The power supply should be capable of supplying a constant current of no less than 1 amp. A transformer is supplied for your assistance. Connect a 12~24volt DC power supply to terminals marked “12V~24V AC/DC”. -
Page 7: Programming Via The Ecgo App (Recommended)
Hold Gate Release Gate Relay 2 – The ECGO-GKP can be wired to communicate to two devices. Typically, when used, Relay 2 is configured to control a secondary gate, lights or garage door. Consult with your installer or dealer to determine if and how Relay 2 is needed. -
Page 8: Add Owners
Add Owners The primary owner number must be added prior to adding “family and friends”. Up to three owners may be added. The order (owner 1,2,3) that the owners are specified is the same order that the unit will attempt to reach when the CALL button on the unit is pressed. -
Page 9: Other Options
Other Options Select here for the following: Signal Strength, Retrieve a list of numbers that have accessed the gate, and Get Status Settings Navigate here to enter the phone number of the SIM Card inserted into the unit. The homeowner also has the options to reset the programming code and/or access code on this page. -
Page 10: Programming
To add friends and family members that you wish to access the gate Keep in mind that the ECGO-GKP has two Relays. As mentioned previously, the primary gate should always be configured to use Relay 1. Therefore, when the owner is ready to grant access to the primary gate, Relay 1 should be specified when configuring the system via text messaging. - Page 11 To check the ECGO-GKP signal strength (0~30 levels): When a request for ECGO-GKP signal strength message is sent to the ECGO-GKP, a response will be sent with a value that represents the signal strength. The code will be between 0-30. Signal strength lower than level 14 may cause operational problems such as loss of speech quality, and possible missing DTMF tones and network loss.
- Page 12 The following are commands that can be entered and sent directly to the SIM card in the unit to achieve the function described below. Function Code Note Momentary trigger gate open *33*5678# Relay 1 Latch or Hold Relay *34*5678# Relay 1 Release Relay *35*5678# Relay 1...
- Page 13 Function Code Note *12*1234#51 + relay time# relay time= n *0.5sec n:1~9 Relay Time Note: 51 for relay 1 50 for relay 2 default = 1 divert time :10~99 Divert Time *12*1234#52 +divert time# (2 digit codes) Default = 20 seconds call time:005~999 sec (3 digit codes) Must Call Time...
- Page 14 Function Code Note X=0~9 / * /＃ Change relay 2 hold code 68 [ X ] # Default = 8 X=0~9 / * /＃ Change relay 2 release code 69 [ X ] # Default = 9 Default = 5 digits Note that this is the same number of digits that would be...
-
Page 15: Keypad Programming
Keypad Programming The homeowner can send a text to the unit to configure pin codes that can be entered at the key pad. For example, if the homeowner would like to enter a pin code at the keypad to hold the gate open while mowing the lawn and re-enter the same pin code to close the gate, you can do that by following the instructions (See Function 2) shown below. -
Page 16: Operating The Ecgo-Gkp
Once configured either thru the ECGO app or text messaging described above, when a visitor pushes the call button to activate the ECGO-GKP, a ring tone will be heard from the unit. If the primary owner number is busy or does not answer, the call will “roll”...
