  • Page 1 REVISION HISTORY Refer to the DCA and associated markups for a complete description of the changes incorporated in a revision. REV DCA DATE DRAWN CHECKED APPROVED PUBLISHED W12974 02/26/2013 Ken Marshall Dan Brasher Pat Maneely Linda Andujo THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION. NEITHER RECEIPT NOR POSSESSION OF THIS DOCUMENT CONFERS ANY RIGHT TO REPRODUCE, USE OR DISCLOSE, IN WHOLE OR IN PART, ANY INFORMATION CONTAINED IN THIS DOCUMENT WITHOUT WRITTEN AUTHORIZATION FROM WULFSBERG ELECTRONICS.
  • Page 2 CVC-151 VHF Communication System Installation Manual Installation Manual Engineering and Production of FliteLine™ Components by Wulfsberg Electronics, A Cobham Avionics & Surveillance Group Company Wulfsberg Electronics CVC-151 FliteLine VHF Transceiver System Manual Number 150-048100 Revision H 150-048100 Rev. H Page 2...
  • Page 3 VHF Communication System Installation Manual Wulfsberg Electronics, A Cobham Avionics & Surveillance Group Company located in Prescott, Arizona, designs and manufactures the Wulfsberg Electronics FliteLine™ line of products, including the CVC-151 VHF Communication System. For more than 25 years, Wulfsberg Electronics. has distinguished itself by providing top quality avionics products for civil, air transport, and military applications.
  • Page 4 CVC-151 VHF Communication System Installation Manual Table of Contents Date Date Date Inserted Date Inserted 12/15/2005 01/12/2006 09/08/2006 03/29/2007 08/22/2007 04/21/2009 09/10/2009 03-06-2013 150-048100 Rev. H Page 4 The document reference is online, please check the correspondence between the online documentation and the printed version.

  • Page 5: Table Of Contents

    CVC-151 VHF Communication System Installation Manual Table of Contents Section Page SECTION 1 – GENERAL INFORMATION 1.1 Introduction ............................7 1.2 Applicability ............................7 1.3 Equipment Description ......................... 7 CVC-151 VHF Communications Transceiver ................7 CVC-151 Control Display Unit ....................7 1.4 Available Configuration Variations ......................
  • Page 6 CVC-151 VHF Communication System Installation Manual Table of Contents Section Page SECTION 2 – INSTALLATION (cont’d) CVC-151 Harnesses and Connector Assembly ................ 27 Antenna Installation ........................32 Optional Strapping ........................32 2.4 Post-Installation Check ........................33 System Test ..........................33 2.5 Flight Check ..........................

  • Page 7: Section 1 - General Information

    CVC-151 VHF Communication System Installation Manual Section 1 - General Information SECTION 1 – GENERAL INFORMATION NTRODUCTION This section contains information relative to the physical, mechanical, and electrical characteristics of the Wulfsberg CVC-151 VHF Communications System. PPLICABILITY This manual is applicable to all CVC-151 FliteLine VHF Communication Receivers built at the Prescott, Arizona facility.

  • Page 8: Available Configuration Variations

    CVC-151 VHF Communication System Installation Manual Section 1 - General Information VAILABLE ONFIGURATION ARIATIONS The CVC-151 is designed to be plug compatible with most older VC-401B installations. To accommodate the smaller size and weight of the CVC-151, versions are available with a ballast and/or adapter bracket to fit the large rack of the VC-401B and match the VC-401B weight as required.
  • Page 9 CVC-151 VHF Communication System Installation Manual Section 1 - General Information Table 1-1. CVC-151 Configuration Variations Rev. AA (cont’d) Continue s……. 150-048100 Rev. H Page 9 The document reference is online, please check the correspondence between the online documentation and the printed version.
  • Page 10 CVC-151 VHF Communication System Installation Manual Section 1 - General Information Table 1-1. CVC-151 Configuration Variations Rev. AA (cont’d) Note: Radios with 8.33 kHz capability will tune both 25 kHz and 8.33 kHz channels. The 8.33 kHz tuning may be disabled by grounding pin 48 on the radio when only 25 kHz channels are desired. 150-048100 Rev.

  • Page 11: Technical Specifications

    CVC-151 VHF Communication System Installation Manual Section 1 - General Information ECHNICAL PECIFICATIONS Table 1-2 CVC-151 Specifications CERTIFICATION: Transmitter TSO-C169, DO-186A Class 3 & 5, and EUROCAE ED-23B, DO-160E ENV CAT. [(F2)Z]AAB[S(M)R(B)(B1)U(G)]EWXXXXZZAZCC[FY]H[A3E33]XXAX Receiver TSO-C169, DO-186A Class C & E, and EUROCAE ED-23B, DO-160E ENV.
  • Page 12 CVC-151 VHF Communication System Installation Manual Section 1 - General Information Table 1-2. CVC-151 Specifications (cont'd) CHANNEL SPACING: 8.33 kHz Fixed, 25 kHz Fixed, 8.33/25 kHz Switchable RF POWER OUTPUT: 20 Watts nominal, 16 Watts minimum over temperature DUTY CYCLE: 1 min on 4 min off, continuous at reduced power without damage to unit.

  • Page 13: Recognized Arinc 429 Vhf Tuning Commands And Formats

    CVC-151 VHF Communication System Installation Manual Section 1 - General Information ARINC 429 VHF T ECOGNIZED UNING OMMANDS AND ORMATS The CVC-151 has two ARINC 429 receive buses and one ARINC 429 transmit bus. Data received on either of the ARINC input channels will tune the radio.

  • Page 14: Installation Kits And Accessories

    CVC-151 VHF Communication System Installation Manual Section 1 - General Information NSTALLATION ITS AND CCESSORIES CVC-151 C ONNECTOR Installation of a CVC-151 requires a connector kit, P/N 050-02398-0000. The contents of the kit are as follows: Table 1-7. Part list, CVC-151 Connector Kit (050-02398-0000, Rev E) INGLE OUNTING When installing a single system, use P/N 400-048124-01 (Single Mounting Tray, Non-Safety Wire...

  • Page 15: Recommended Antennas

    CVC-151 VHF Communication System Installation Manual Section 1 - General Information ECOMMENDED NTENNAS The following is list of recommended Wulfsberg antennas for the CVC-151. The installer is responsible for determining if these antennas are appropriate for the given installation. Table 1-8 CVC-151 Recommended Antennas Part number Frequency Range Maximum Aircraft Speed...

  • Page 16: Fcc Compliance

    CVC-151 VHF Communication System Installation Manual Section 1 - General Information 1.14 FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 17: Section 2 - Installation

    CVC-151 VHF Communication System Installation Manual Section 2 – Installation SECTION 2 – INSTALLATION 2.1 General This section contains suggestions and factors to consider before installing the CVC-151. Close adherence to these suggestions will assure a more satisfactory performance from the equipment. Unpacking and Inspecting Equipment Exercise care when unpacking the equipment.

  • Page 18: Dual Installation Considerations

    CVC-151 VHF Communication System Installation Manual Section 2 – Installation C. Dual Installation Considerations (1) Reduction of cross radio interference by using Transmit Interlock feature. All radio transceivers have a noise floor associated with the transmitted output signal. When two or more radios are installed on the same aircraft, the transmitted noise floor can cause the squelch of a radio operating in receive to open if care is not taken to maximize the isolation between the antennas of the two systems.
  • Page 19 CVC-151 VHF Communication System Installation Manual Section 2 – Installation Figure 2-1 Three Radio System Transmit Interlock Wiring 1 150-048100 Rev. H Page 19 The document reference is online, please check the correspondence between the online documentation and the printed version.

  • Page 20: Mounting Tray Installation Drawing, 154-048100 (Figure 2-2)

    CVC-151 VHF Communication System Installation Manual Section 2 – Installation Figure 2-2. CVC-151 Single Mounting Tray Installation (Sheet 1 of 3) (Dwg. No. 154-048100, Rev. D) 150-048100 Rev. H Page 20 The document reference is online, please check the correspondence between the online documentation and the printed version.
  • Page 21 CVC-151 VHF Communication System Installation Manual Section 2 – Installation Figure 2-2. CVC-151 Single Mounting Tray Installation (Sheet 2 of 3) (Dwg. No. 154-048100, Rev. D) 150-048100 Rev. H Page 21 The document reference is online, please check the correspondence between the online documentation and the printed version.
  • Page 22 CVC-151 VHF Communication System Installation Manual Section 2 – Installation Figure 2-2. CVC-151 Single Mounting Tray Installation (Sheet 3 of 3) (Dwg. No. 154-048100, Rev. D) 150-048100 Rev. H Page 22 The document reference is online, please check the correspondence between the online documentation and the printed version.

  • Page 23: Mounting Tray Envelope Drawing, 154-04047 (Figure 2-3)

    CVC-151 VHF Communication System Installation Manual Section 2 – Installation Figure 2-3. Envelope Drawing, Mounting Tray, 4 Inch (Sheet 1 of 2) (Dwg. No. 154-04047, Rev. D) 150-048100 Rev. H Page 23 The document reference is online, please check the correspondence between the online documentation and the printed version.
  • Page 24 CVC-151 VHF Communication System Installation Manual Section 2 – Installation Figure 2-3. Envelope Drawing, Mounting Tray, 4 Inch (Sheet 2 of 2) (Dwg. No. 154-04047, Rev. D) 150-048100 Rev. H Page 24 The document reference is online, please check the correspondence between the online documentation and the printed version.

  • Page 25: Cvc-151 To Cvc-152 Interconnect Wiring Diagram, 152-248130 (Figure 2-4)

    CVC-151 VHF Communication System Installation Manual Section 2 – Installation Figure 2-4. Interconnect Wiring Diagram, CVC-151 TO CVC-152 (Sheet 1 of 1) (Dwg. No. 152-248130, Rev E) 150-048100 Rev. H Page 25 The document reference is online, please check the correspondence between the online documentation and the printed version.

  • Page 26: Cvc-151 & Cvn-251 To Ccn-955 Interconnect Wiring Diagram, 152-248150 (Figure 2-5)

    CVC-151 VHF Communication System Installation Manual Section 2 – Installation Figure 2-5. Interconnect Wiring Diagram, CVC-151 AND CVN-251 TO CCN-955 (Sheet 1 of 1) (Dwg. No. 152-248150, Rev F) 150-048100 Rev. H Page 26 The document reference is online, please check the correspondence between the online documentation and the printed version.
  • Page 27 CVC-151 VHF Communication System Installation Manual Section 2 – Installation D. CVC-151 Harness and Connector Assembly (1) The installer will supply and fabricate all external cables. The connectors and hardware required are supplied in the Wulfsberg installation kits listed in Section 1. Figure 2-5 illustrates the specific aspects of constructing the RF connector and the wiring connector housing.
  • Page 28 CVC-151 VHF Communication System Installation Manual Section 2 – Installation Figure 2-7. CVC-151 Rack Mount Connector 1 150-048100 Rev. H Page 28 The document reference is online, please check the correspondence between the online documentation and the printed version.
  • Page 29 CVC-151 VHF Communication System Installation Manual Section 2 – Installation Table 2-1. CVC-151 Pin-outs DESCRIPTION DESCRIPTION D-DATA NOT USED +28V IN RESERVED +28V IN RESERVED NOT USED RESERVED POWER RETURN RESERVED NOT USED NOT USED POWER RETURN RESERVED NOT USED RESERVED RESERVED NOT USED...
  • Page 30 CVC-151 VHF Communication System Installation Manual Section 2 – Installation Table 2-1. CVC-151 Pin-outs (cont’d) DESCRIPTION DESCRIPTION NOT USED ENABLE COMM AUDIO OUT HI NOT USED NOT USED INTERLOCK RESERVED NOT USED NOT USED COMM AUDIO OUT LO ARINC IN 1B NOT USED GRAY CODE IN 1B ARINC OUT B (429)
  • Page 31 CVC-151 VHF Communication System Installation Manual Section 2 – Installation Figure 2-8. CVC-151 Polarizing Post Assembly 1 150-048100 Rev. H Page 31 The document reference is online, please check the correspondence between the online documentation and the printed version.
  • Page 32 CVC-151 VHF Communication System Installation Manual Section 2 – Installation (5) The Interconnect Wiring Diagram Figures 2-3 and 2-4 identifies those wires that must be shielded or twisted. (6) Connect the external wiring to the CVC-151 and associated equipment using the appropriate interconnect drawings.
  • Page 33 CVC-151 VHF Communication System Installation Manual Section 2 – Installation Table 2-2. Strapping Options Optional Function Strap (CVC-151) Active Frequency Tuning P1001-71 to ground System Number “1” P1001-54 to ground System Number “2” P1001-95 to ground System Number “3” P1001-95 and P1001-54 ungrounded Remote Transfer Function P1001-56 to one terminal of a momentary SPST (Panel or Yoke Mounted)
  • Page 34 CVC-151 VHF Communication System Installation Manual Section 2 – Installation Flight Check A flight test is recommended after the installation is completed to ensure satisfactory performance of the equipment in its normal environment. Check all aircraft control movements to be sure no electrical cables interfere with their operation. To check the communications transceiver, maintain an appropriate altitude and contact a ground station facility at a range of at least fifty nautical miles.
  • Page 35 CVC-151 VHF Communication System Installation Manual Section 3– Operation 3.1 General Refer to Pilot's Guide, Avionics Systems, FliteLine, Publication No. 150-047012. 150-048100 Rev. H Page 35 The document reference is online, please check the correspondence between the online documentation and the printed version.
