- Page 1 Technical Information Manual Revision n. 3 1 June 2004 MOD. N625 QUAD LINEAR FAN IN / FAN OUT MANUAL REV.3 NPO: 00111/02:N625x.MUTx/03...
- Page 2 User. It is strongly recommended to read thoroughly the CAEN User's Manual before any kind of operation. CAEN reserves the right to change partially or entirely the contents of this Manual at any time and without giving any notice.
-
Page 3: Table Of Contents
Document type: Title: Revision date: Revision: User's Manual (MUT) Mod. N625 Quad Linear Fan In/Fan Out 01/06/2004 TABLE OF CONTENTS MODULE DESCRIPTION ........................4 ............................4 VERVIEW ..........................5 LOCK DIAGRAM TECHNICAL SPECIFICATIONS......................6 ............................6 ACKAGING ........................6 OWER REQUIREMENTS ........................7 RONT AND BACK PANEL ..................8... -
Page 4: Module Description
User's Manual (MUT) Mod. N625 Quad Linear Fan In/Fan Out 01/06/2004 1. Module description Overview The Mod. N625 is a 1-unit NIM module which houses: − Four linear 4 Input + 4 Output Fan in/Fan out sections − One 1 Channel Discriminator Each Fan in/Fan out section produces on all its output connectors, the sum of the signals fed to the inputs, multiplied for the selected gain factor (1 or –1, jumper selectable). -
Page 5: Block Diagram
Document type: Title: Revision date: Revision: User's Manual (MUT) Mod. N625 Quad Linear Fan In/Fan Out 01/06/2004 Block diagram GAIN: ±1 GAIN: ±1 DC OFFSET Fig. 1.1: Fan in/Fan out section block diagram NPO: Filename: Number of pages: Page: 00111/02:N625x.MUTx/03... -
Page 6: Technical Specifications
Document type: Title: Revision date: Revision: User's Manual (MUT) Mod. N625 Quad Linear Fan In/Fan Out 01/06/2004 2. Technical specifications Packaging The module is housed in a one unit wide std. NIM mechanics. Power requirements The power requirements of the module are as follows: Table 2.1: Power requirements... -
Page 7: Front And Back Panel
ZEROADJ GAIN ZEROADJ GAIN ZEROADJ REAR DISCR.SET DISCRIMINATOR OUTPUT WIDTH TRIMMER THRESHOLD TEST POINT DISCRIMINATOR THRESHOLD TRIMMER TRIGGER SLOPE LEDS TRG SLOPE Ser. n. Fig. 2.1: Mod. N625 front and back panel NPO: Filename: Number of pages: Page: 00111/02:N625x.MUTx/03 N625_REV3.DOC... -
Page 8: Mechanical And Electrical Features
Document type: Title: Revision date: Revision: User's Manual (MUT) Mod. N625 Quad Linear Fan In/Fan Out 01/06/2004 Mechanical and electrical features 2.4.1 Fan in/Fan out sections INPUT CONNECTORS: Mechanical specifications: Front panel LEMO 00 type connectors Electrical specifications: Bipolar, DC coupled, 50 Ω impedance... -
Page 9: Fig . 2.2: Jumpers Setting
Document type: Title: Revision date: Revision: User's Manual (MUT) Mod. N625 Quad Linear Fan In/Fan Out 01/06/2004 THRESHOLD TRIMMER: Mechanical specifications: Front panel screwdriver trimmer Function: Allows to adjust the discriminator threshold in the -1200÷+1200 mV range; one test–point allows to monitor the threshold value DISPLAYS: Trigger slope LEDs: 2 Front panel LEDs;... -
Page 10: Technical Specification Table
Document type: Title: Revision date: Revision: User's Manual (MUT) Mod. N625 Quad Linear Fan In/Fan Out 01/06/2004 Technical specification table Table 2.2: Fan in/Fan out technical features bipolar, DC coupled, 50 Ω impedance Inputs DC coupled, inverted or non inverted (internal jumper Outputs selectable), drive 50 Ω...
