- Page 1 7232 Thank you for choosing OMP Global Style. AMERICAS EUROPE/MIDDLE EAST ASIA PACIFIC 200 Norfinch Drive Common Lane 1D Quadrant Dr, Toronto, Ontario, Setchey, Kings Lynn Gracefield, Canada Norfolk, PE33 0AT Lower Hutt, 5010 M3N 1Y4 England New Zealand Tel: 1-416-667-9909...
- Page 2 Under no circumstances should this product be mounted to metal framing studs. To provide maximum viewing flexibility, the M7232 is capable of a wide range of Never exceed the maximum load capacity of 56.7kg (125lbs).
- Page 3 MOUNTING TO WOODEN STUDS STEP 2a The wall plate can be mounted on up to three wooden studs. Using a high-quality wall stud finder, find the location of the wall studs. Mark the centre of the wall stud (an edge to edge stud finder is highly recommended). Use a level to draw a vertical line down the centre of the stud.
- Page 4 Using the template, drill holes with a diameter of 14mm (1/2”), to a depth of 90mm (3 1/2”) into a solid portion of the cinderblock wall. These holes should be in a vertical line. Using a level is recommended. Insert the anchors into the holes, and then lightly tap them flush to the wall with a hammer.
- Page 5 Carefully attach the display to the M7232 mounting arm assembly’s pocket. Lock the mounting head to the mounting The M7232 provides a wealth of display adjustment options to offer the best viewing arm tightly with the other two screws (K). Insert from many different seating positions.
- Page 6 6.9 shown in fig. 6.5. MAINTAINING THE M7232 Panning - Position display at an angle to the wall for viewing from opposite sides of the room. Regular cleaning of this product with a clean dry cloth is usually sufficient.
