- Page 1 Fixed LED & LCD Wall Mount Tighten the two bolts by using the (CC) Allen Key to secure the bracket. 7416 VESA Compatible 75kg 100/200/300/400/400x600 FOR LCD/LED 37"– 50"...
- Page 2 (BB) (AA) (CC) 6x Mounting Screws 6x Concrete Wall 8x50mm (I) Anchors ( J ) 6x Metal washers (K) 8x Short Spacers (M) 8x Long Spacers (N) 4x Square washers (L)
- Page 3 1. Mounting the Wall Plate 1-2 For Solid Brick and Concrete Mounting 1-1 For Wood Stud Wall Mounting...
- Page 4 B/D/F/G choose washer hole that best matches screw diameter choose washer hole that best matches B/D/F/G screw diameter choose washer hole that best matches screw diameter choose washer hole that best matches screw diameter Position the adapter brackets as close to vertical centre as possible.
