- Page 1 BH18-084-097-32 GRAMERCY 61" Roll Arm Loveseat CREAM ASSEMBLY INSTRUCTIONS Customer Service Support: 1-800-379-9973...
- Page 2 Chair Assembly Instructions Carefully unpack all parts and identify them against the parts list before attempting to assemble. To avoid scratching the components, assemble the chair on a protected surface. We are here to help if you have any questions, comments, or are in need of warranty replacement parts. Visit our website at: www.truecustomersupport.com Or call us toll free at: 1-800-379-9973 (Monday - Friday 6:00 AM - 5:00 PM Pacific Time)
- Page 3 Parts Thumb Bolts (3) Wood legs with Washers (4) Wood Legs (3) Armrest with “L” Label (1) Armrest with “R” Label (1) Seat Frame (1) Back Frame (1) Seat Cushions (2) Seat Covers (2) Back Cushions (Left & Right) (2) Back Covers (Left &...
- Page 4 Step 1 Remove all parts from the carton and separate them into part number groups as indicated in the parts list. Gramercy 61" Roll Arm Loveseat...
- Page 5 Step 2 There is a connection between Arms (D1 & D2) and Seat Frame (E). Slide the Armrest with “L” Label (D1) into the Seat Frame (E) until fully engaged as shown. Slide the Seat Frame (E) into the Armrest with “R” Label (D2) until fully engaged as shown . Gramercy 61"...
- Page 6 Step 3 Remove the plastic caps on the threaded bolts of each leg. Attach the Wood Legs with Washers (B) to the bottom of the Armrests (D1 & D2). LEGS LEGS CORRECT BOTTOM VIEW INCORRECT BOTTOM VIEW Gramercy 61" Roll Arm Loveseat...
- Page 7 Step 4 Turn over the Seat Frame (E) and slide the Back Frame (F) into the Seat Frame (E) until fully engaged. Align the holes of the Back Frame (F) to the Arm Frames (D1 & D2) and secure with two Thumb Bolts (A). Gramercy 61"...
- Page 8 Step 5 Secure the bottom and back flaps with hook and loop tape. Remove the plastic caps on the threaded bolts of each leg. Attach the Wood Legs with Washers (B) to the corners of the sofa. Gramercy 61" Roll Arm Loveseat...
- Page 9 Step 6 Open the vacuum packed Seat Cushions (G) by carefully cutting the bags with a pair of scissors. Insert the Back Cushions (I) into the appropriate Back Covers (J). Insert the Seat Cushions (G) into the appropriate Seat Covers (H). Remember to keep the top side of the Seat Cushions (G) with the top side of the Seat Covers (H).
-
