Motion Test - Metro DataVac Flexline FL420 User Manual

Test keypad keys:
- Press various keys and a charactesr will display as follows:
Key Selected Displays (left upper line of display)
0 to 9 0 to 9
Sign Out S
OK O
Function F
Clear C
CS N
Select T
< <
> >
Display Light D
Key Lock Switch Test
Unlock the cart with a key. An "L" should display in the upper right
section of the display.
- Press OK twice to end test.
- Press "SIGN OUT" to exit Service Mode.

Motion Test:

- Press OK to wake up touch pad.
- Enter Service Code and press OK.
- Press "FUNCTION" key several times until "TEST THE MOTION
SENSOR" is displayed & Press OK.
- Open and close the drawers or pat the right side of the cart to test
the sensors. A short tone will sound every time motion is sensed.
- If the sensors are not sensitive enough, press OK to exit the test
and physically adjust the sensors (MD1 and MD2 - PC board
drawing, Section 1).
Configure CS Drawer:
Note:
Only for carts that are equipped with a Controlled Substance
drawer. CS drawers are configured at the factory.
- Press OK to wake up touch pad.
- Enter Service Code and press OK.
- Press "FUNCTION" key several times until "CONFIGURE CS
DRAWERS" is displayed followed by the number (1 or more) for
the number of keyless drawers in the cart.
- If no number, no drawers are configured.
- Press OK to display "SET CS DRAWER".
- Enter the number 1, Press OK.
- Press "SIGN OUT" to exit Service Mode.
Set Audit Log:
Note: When using the Data Manager computer program with your
cart. The Audit function on each cart must be enabled to allow the
cart data to be downloaded and uploaded to a laptop PC via USB
port on the back of the cart. The service routine allows you to check
or change the status of the audit feature.
- Press OK to wake up touch pad.
- Enter Service Code and press OK.
- Press "FUNCTION" key several times until "SET AUDIT LOG" is
displayed.
- Follow the prompts to change the setting.
- Press "SIGN OUT" to exit Service Mode.
Enable Card Reader:
Note: One of three readers is available. Readers are designed
specifically for one type of card, e.g. if your cart has a bar code
reader, a magnetic stripe card can not be used to unlock the cart.
The card reader is enabled at the factory. This service routine allows
you to check or change the status of the card reader.
- Press OK to wake up touch pad.
- Enter Service Code and press OK.
FL420 Electronic Locking User Guide - General Operating Instructions
- Press "FUNCTION" key several times until "ENABLE CARD
READER" is displayed.
- Follow the prompts to enable the appropriate reader.
- Press OK.
- If an incorrect reader is selected, press "SELECT" when the current
reader displays. The display will then show that no reader is selected.
- Press "SELECT" key again to scroll through the available reader
options.
- Press "SIGN OUT" to exit Service Mode.
Adjust the Main Servomotor:
Note: Used to locate the pulse widths that are sent to the main cart
Servomotor when commanding it to move to a position.
There are three positions (1) locked, (2) unlocked. (3) idle. The
adjustment takes 2 minutes to complete.
Important:
1. The motor must be adjusted after a PC board or the
Servomotor is replaced.
2. It must be adjusted after reconfiguring memory.
3. If executed, this function should not be interrupted.
4. The cart must never be relocked manually while adjustment is
underway.
5. If the adjustment is interrupted by pressing the "FUNCTION" or
"SIGN OUT" key, the original Servo position will be maintained.
- Press "FUNCTION" key several times until "ADJUST THE MAIN
SERVO" is displayed.
- Press OK.
- Wait until servo self adjusts. When complete, "ADJUST THE MAIN
SERVO" will be displayed.
- Press "SIGN OUT" to exit Service Mode.
Adjust Servomotor Idle Position:
- Press OK to wake up touch pad.
- Enter Service Code and press OK.
- Press "FUNCTION" key several times until "ADJUST SERVO IDLE
POSITION" is displayed.
Note: Used to reset the Servomotor offset idle. The factory setting is
typically 5. Adjust the setting from 1 to 9 as directed by the factory
using the numeric keys.
- Press "SIGN OUT" to exit Service Mode.
Read Battery Voltage:
- Press OK to wake up touch pad.
- Enter Service Code and press OK.
- Press "FUNCTION" key several times until "READ BATTERY
VOLTAGE" is displayed.
- Press OK to see current voltage.
- Press OK.
- Press "SIGN OUT" to exit Service Mode.
Set Battery Warning Levels:
- Press OK to wake up the touchpad.
- Enter Service Code and press OK
- Press "FUNCTION" key several times until "SET BATTERY
WARNING LEVELS" is displayed and press OK.
- Set the input voltage to 11.95 V. The input voltage is the warning level
at which "LOW BATTERY-RECHARGE" will display.
- Press OK. The display will indicate "BATTERY WARNING LEVELS
ARE SET".
- Press "SIGN OUT" to exit Service Mode.
