Bill Of Materials - Parallax 27150 Manual

Warning
Any attempt to assemble or complete this kit voids any warranty that is covered by Parallax Inc. and/or
SchmartBoard. Inspect your board carefully for manufacturing flaws before proceeding. If you have
questions regarding assembly please review the steps and if further questions arise you can call our
Technical Support staff at 888-997-8267 and they will be happy to help with your questions.

Bill of Materials

Please refer to the schematic appended to the end of this PDF for the Location Used references.
Part # Description
150-01031 Resistor, 10 kΩ [ brown, black, orange ]
150-04710 Resistor, 470 Ω [ yellow, violet, brown ]
150-11031 Resistor, 10 kΩ SMT*
150-14712 Resistor, 470 Ω SMT*
200-11503 Capacitor, 10 µF *
201-01050 Capacitor, 1 µF electrolytic
201-01062 Capacitor, 10 µF electrolytic
213-01051 Capacitor, 1 µF SMT*
251-05000 5 MHz Crystal
300-27150 PCB SchmartBoard
350-00006 LED-Red - T1
350-10001 LED-Red 0603 SMT*
400-00025 Push Button
451-00201 2-Pin Header [ single row ]
451-01002 10-pin SIP Socket
40-pin SIP Header [ optional header ]
451-04001
451-04002 4-pin Header [ right angle ]
452-00007 Power Jack [ 2.1mm ]
601-10335 3.3 Voltage Regulator [ 17-33 ] SMT
601-10340 5.0 Voltage Regulator [ 117-5 ] SMT
700-00037 PCB Rubber Feet
602-10001 512K EEPROM
P8X32A-Q44 Propeller Chip [ P8X32A-Q44 ]
* These SMT are surface-mount options for the corresponding through-hole parts supplied.
Tools Required (Not Included)
• Basic soldering iron with 2.4 mm soldering tip
• Lead-Free Solder (with or without resin core)
• Standard flux
• 70% or higher isopropyl alcohol & cleaning utensils (soft bristled brush works nice)
• Probe soldering tool (or other non conductive tool)
•
Helping Hands tool w/ magnifier (not needed, but helpful)
• Soldering Wick
• Wire Cutters
Copyright © Parallax Inc. P8X32A-Q44 SchmartBoard (#27150)
Quantity Location Used
2 R2, R3
1 R1
2 R2, R3
1 R1
3 C1, C2, C3
1 C4
3 C1, C2, C3
1 C4
1 Y1
1 N/A
1 D1
1 D1
1 SW1
1 J3
4 J5, J6, J7, J8
1 J5, J6, J7, J8
1 J2
1 J1
1 U4
1 U3
1 Underside of PCB
1 U2
1 U1
v1.2 9/10/2009 Page 2 of 9
