- Page 1 AV700 IP65 MIL-STD-810G Rugged Computer with Intel® Core i7-7820EQ, 9V to 36V DC-in, Extended Temp -40 to 70°C User’s Manual Revision Date: : 06.10.2020...
-
Page 2: Safety Information
AV700 User’s Manual Revision Date: : 06.10.2020 Safety Information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. -
Page 3: Revision History
AV700 User’s Manual Revision Date: : 06.10.2020 Revision History Revision Date(yyyy/mm/dd) Changes V1.0 2019/05/23 Initial release V2.0 2020/6/10 Upgrade Motherboard Packing list Ordering information... -
Page 4: Table Of Contents
AV700 User’s Manual Revision Date: : 06.10.2020 Table Contents Safety Information ..........................1 Revision History ............................2 Packing list .............................. 2 Ordering information ..........................2 Table Contents............................3 Chapter 1: Product Introduction ......................4 Key Features ........................4 Dimensions ......................... 5 Panel Component ....................... -
Page 5: Chapter 1: Product Introduction
AV700 User’s Manual Revision Date: : 06.10.2020 Chapter 1: Product Introduction 1.1 Key Features System High Power Processor Intel® Core™ i7-7820EQ Processor Memory type DDR4 Up to 32GB SO-DIMM BIOS BIOS Front I/O DC-In 1 (Amphenol TV07RW-11-54P) Power Button 1 x Power Button with LED backlight... -
Page 6: Dimensions
AV700 User’s Manual Revision Date: : 06.10.2020 1.2 Dimensions... -
Page 7: Panel Component
AV700 User’s Manual Revision Date: : 06.10.2020 1.3 Panel Component... -
Page 8: Chapter 2: Connector Pin Definition
AV700 User’s Manual Revision Date: : 06.10.2020 Chapter 2: Connector pin definition... - Page 9 AV700 User’s Manual Revision Date: : 06.10.2020...
- Page 10 AV700 User’s Manual Revision Date: : 06.10.2020...
-
Page 11: Chapter 3: Ami Bios Utility
AV700 User’s Manual Revision Date: : 06.10.2020 Chapter 3: AMI BIOS UTILITY This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMI BIOS setup utility. 3.1 Starting To enter the setup screens, perform the following steps: •... -
Page 12: Main Menu
AV700 User’s Manual Revision Date: : 06.10.2020 3.3 Main Menu The Main menu is the screen that first displays when BIOS Setup is entered, unless an error has occurred. System Date Use this function to change the system date. Select System Date using the Up and Down <Arrow> keys. Enter the new values through the keyboard. -
Page 13: Cpu Configuration
AV700 User’s Manual Revision Date: : 06.10.2020 your system or let you set some features according to your preference. Setting incorrect field values may cause the system to malfunction. 3.4.1 CPU Configuration... -
Page 14: Power & Performance
AV700 User’s Manual Revision Date: : 06.10.2020 3.4.2 Power & Performance... -
Page 15: Pch-Fw Configuration
AV700 User’s Manual Revision Date: : 06.10.2020 3.4.3 PCH-FW Configuration 3.4.4 ACPI Setting... -
Page 16: It8786 Super Io Configuration
AV700 User’s Manual Revision Date: : 06.10.2020 3.4.5 IT8786 Super IO Configuration User can choose a mode (RS232/RS422/RS485) on each serial port. - Page 17 AV700 User’s Manual Revision Date: : 06.10.2020...
-
Page 18: Hardware Monitor
AV700 User’s Manual Revision Date: : 06.10.2020 3.4.6 Hardware Monitor... -
Page 19: Csm Configuration
AV700 User’s Manual Revision Date: : 06.10.2020 3.4.7 CSM Configuration 3.5 Chipset... -
Page 20: Sa Configuration
AV700 User’s Manual Revision Date: : 06.10.2020 3.5.1 SA Configuration 3.5.1.1 Graphics Configuration... - Page 21 AV700 User’s Manual Revision Date: : 06.10.2020 3.5.1.2 LCD Control Primary IGFX Boot Display: Select the Video Device which will be activated during POST. This has no effect if external graphics present. Secondary boot display selection will appear based on your selection.
-
Page 22: Pch-Io Configuration
AV700 User’s Manual Revision Date: : 06.10.2020 3.5.2 PCH-IO Configuration 3.6 Security... -
Page 23: Boot
AV700 User’s Manual Revision Date: : 06.10.2020 3.7 Boot Bootup NumLock State: Select the keyboard NumLock state. Quiet Boot: Enables or disables Quiet Boot option. Fast Boot: Enables or disables boot with initialization of a minimal set of devices required to launch active boot option. -
Page 24: Save & Exit
AV700 User’s Manual Revision Date: : 06.10.2020 3.8 Save & Exit This screen provides functions for handling changes made to the BIOS settings and the exiting of the Setup program. Save Changes and Exit Exit system setup after saving the changes.
