HIKVISION DS-MH2111/32G
DS-MH2111/32G/GLF User Manual

HIKVISION DS-MH2111/32G DS-MH2111/32G/GLF User Manual

Ds-mh2111 series body camera

Advertisement

Quick Links

Body Camera
User Manual
UD.6L0204D1154A01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-MH2111/32G DS-MH2111/32G/GLF and is the answer not in the manual?

Questions and answers

Summary of Contents for HIKVISION DS-MH2111/32G DS-MH2111/32G/GLF

  • Page 1 Body Camera User Manual UD.6L0204D1154A01...
  • Page 2 BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
  • Page 3 Body Camera User Manual Regulatory information FCC information FCC compliance: Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 4 Body Camera User Manual This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: this device may not cause interference, and this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 5 Only use the battery, power adapter and assembly parts specified by the manufacturer. ● Consult the authorized dealer or technician from Hikvision for any question and request for product using. ●...
  • Page 6 Body Camera User Manual Applicable Models This manual is applicable to the models listed in the following table. Series Model DS-MH2111/32G DS-MH2111 Series DS-MH2111/32G/GLF Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance...
  • Page 7: Table Of Contents

    Body Camera User Manual TABLE OF CONTENTS TABLE OF CONTENTS ..........................6 Chapter 1Introduction ..........................8 Package List ............................. 8 Buttons and Interfaces ........................8 SIM Card Installation........................10 Shoulder Clip Installation/Uninstallation ..................10 Charging ............................11 1.5.1 Charger Specification ......................11 1.5.2 How to Charge ........................
  • Page 8 Body Camera User Manual Device Login........................... 30 Password Recovery ........................31 Media Information ......................... 32 7.4.1 File Operation via Assistant....................33 7.4.2 File Operation in USB Mode....................34 Device Configuration ........................35 7.5.1 User Information Settings ....................35 7.5.2 Encoding Parameters ......................36 7.5.3 Time Synchronization .......................
  • Page 9: Chapter 1Introduction

    Body Camera User Manual Chapter 1 Introduction Purpose: Body camera is a video recording system that is typically used by law enforcement to record their interactions with the public and gather video evidence at crime scenes. 1.1 Package List Following objects are delivered with package list. If something loses, contact us or our supplier for it. ...
  • Page 10 Body Camera User Manual Table 1. 1 Buttons’ Description Button Description  Recording Hold down it to start/stop recording.  Hold down it for 3 seconds to turn on IR positioning light.  Taping Press it to start/stop taping.  Hold down it for 3 seconds to turn on/off fluorescent.
  • Page 11: Sim Card Installation

    Body Camera User Manual 1.3 SIM Card Installation Purpose: DS-MH2111/32G/GLF series body camera supports 3G/4G wireless network. You need to install SIM card before dialing. Steps: SIM card slot locates at the bottom of body camera. Open the cover to show the SIM card slot. Figure 1.
  • Page 12: Charging

    Body Camera User Manual Push the shoulder clip into top of the clip slot as the direction shown in the following figure, till you hear a click sound. Figure 1. 5 Install Shoulder Clip  To uninstall clip, do following steps: Press and hold the stick as the direction 1 shown in the following figure.
  • Page 13: How To Protect Charger

    Body Camera User Manual Figure 1. 7 Open the Cover Connect body camera to the charger or USB port of computer with the USB data cable. The LCD will show the charging status. The charging status via charger or computer is different. Figure 1.
  • Page 14: Chapter 2Start-Up

    Ensure the power is sufficient. If not, charge body camera. For details, refer to 1.4 Shoulder Clip Installation/Uninstallation. Step: Press the Sleep/Wake button. After this the LED (3) turns green, the HIKVISION logo pops up in LCD, and you will hear an audio notification. All of these indicate the body camera starts successfully. 2.2 Sleep/Wake up Step: The LCD goes to sleep automatically when there is no operation in the predefined time.
  • Page 15: Chapter 3Basic Functions

    Body Camera User Manual Chapter 3 Basic Functions 3.1 Live View Icons Purpose: Once the body camera starts up completely, it automatically enters the live view image. 11 icons are shown in live view. Figure 3. 1 Live View Icons Table 3.
  • Page 16: Menu Operation

    Body Camera User Manual Number Name Description  Succeeded: Battery information Shows the remaining battery and charging status. Zoom status Shows the zoom status. Remaining memory capacity Shows the remaining memory capacity Memory status Shows whether memory is recognized. 3.2 Menu Operation Before you start: Wake up LCD.
  • Page 17: Record And Capture

    Body Camera User Manual Enter Camera Settings interface. Press the button to position the cursor on Picture Quality. And click the button to enter Picture Quality menu. Press the button to select picture quality. And click the button to save the settings. Enter live view mode, or you will fail to take pictures.
  • Page 18: Playback

    Body Camera User Manual  You can play back the audio in playback menu or download and save it in computer local path. For detailed steps of downloading audios, you can refer to 7.7 Assistant File Saving Path. 3.6 Playback Purpose: You can play back recorded videos, pictures, and audios.
  • Page 19 Body Camera User Manual “Memory is full.” will pop up in LCD. To save new files, including videos, pictures, and audios, you need to backup device first and clear memory. Memory full alarm is on by default and cannot be turned off. Figure 3.
  • Page 20: Chapter 4Network Settings

    Body Camera User Manual Chapter 4 Network Settings 4.1 Dialing Purpose: For DS-MH2111/32G/GLF series body camera, you can access internet by dialing via 3G/4G SIM card. Before you start: Install SIM card first. For details, refer to 1.3 SIM Card Installation. Steps: Enter Network Settings interface.
  • Page 21: Wi-Fi

    Body Camera User Manual 4.2 Wi-Fi Purpose: You can access internet by connecting to a Wi-Fi. Before you start: Configure Wi-Fi parameters, including SSID and key, in body camera assistant. For detailed steps, refer to 7.5.4 Wi-Fi Parameters. Steps:  To turn on Wi-Fi on LCD menu, do following steps: Enter Network Settings interface.
  • Page 22: Network Transmission Parameters

    Body Camera User Manual 4.3 Network Transmission Parameters Purpose: By setting network transmission parameters, you can determine the resolution, frame rate, and bitrate used by iVMS platform when it views body camera’s image. Steps: Enter Network Settings interface. Main Menu > Network Settings Figure 4.
  • Page 23: Chapter 5Camera Settings

    Body Camera User Manual Chapter 5 Camera Settings Purpose: You can set the parameters for video, including resolution, frame rate, bitrate, and so on. Steps:  To configure camera parameters on LCD menu, do following steps: Enter Camera Settings interface. Main Menu >...
  • Page 24: Chapter 6System Settings

    Body Camera User Manual Chapter 6 System Settings To enter System Settings menu, do following step: Press the button to position the cursor on System Settings menu. And press the button to enter System Settings menu. 6.1 System Sound Purpose: You can turn on and turn off system sound if necessary.
  • Page 25: Language Settings

    Body Camera User Manual Figure 6. 2 LED Menu 6.3 Language Settings Purpose: Two languages are provided: Chinese and English. Steps: Enter System Settings menu. Press the button to position the cursor on Language. And press the button to enter Language settings menu.
  • Page 26: Positioning Settings

    Body Camera User Manual Figure 6. 4 Infrared Menu Press the button to position the cursor on OFF, ON, or AUTO.  OFF: By default, IR light is off. The status adapts to daylight period.  ON: In night period or dark environment, it is recommended to turn on IR light. ...
  • Page 27: Battery Information

    Body Camera User Manual Steps: Enter System Settings interface. Press the button to position the cursor on System Information item. And press the button to enter System Information menu. Figure 6. 6 System Information 6.7 Battery Information Purpose: Battery information menu shows the remaining battery, time to fully charged, and charging status. Steps: Enter System Settings interface.
  • Page 28: Chapter 7Body Camera Assistant

    Body Camera User Manual Chapter 7 Body Camera Assistant Purpose: Log into body camera via the Body Camera Assistant to view device’s logs, videos, audios, and pictures, and configure parameters remotely. Assistant mentioned below refers to the Body Camera Assistant. 7.1 Assistant Installation Purpose: The body camera assistant’s installation package is delivered with the CD.
  • Page 29 Body Camera User Manual Figure 7. 2 Destination Location Click Next to enter Select Start Menu Folder window. Optionally, you can edit the shortcut name and click Browser to select the folder where to create shortcut. Figure 7. 3 Start Menu Folder Click Next to enter Select Additional Tasks window.
  • Page 30 Body Camera User Manual Figure 7. 5 Ready to Install During the installation process, the following window will pop up. Figure 7. 6 Device Driver Installation Wizard Click Next to start installing device driver. Figure 7. 7 Device Driver Installation Wizard Click Finish in Device Driver Installation Wizard and click Finish in Body Camera Assistant Wizard to finish the installation.
  • Page 31: Device Login

    Body Camera User Manual Figure 7. 8 Finish Then the body camera assistant window appears. Figure 7. 9 Body Camera Assistant 7.2 Device Login Purpose: You need to connect the assistant with body camera. Before you start: Connect the body camera to your computer with the USB data cable. Steps: Run the assistant.
  • Page 32: Password Recovery

    Body Camera User Manual window shows. If you forget the password, refer to 7.3 Password Recovery to recover password. CHANGE THE DEFAULT PASSWORD The default password (123456) for the Admin account is for first-time log-in purposes only. You must change this default password to better protect against security risks, such as the unauthorized access by others to the product that may prevent the product from functioning properly and/or lead to other undesirable consequences.
  • Page 33: Media Information

    Body Camera User Manual Figure 7. 12 Login Window. Click the Forget Password button. Click the File Export button to export file DeviceKey.xml. Send the file to your manufacturer. They will send you an encryption file. Click the button to import the encryption file received in step 4. Click Verifying Encryption to start verifying.
  • Page 34: File Operation Via Assistant

    Body Camera User Manual and switching device into USB mode. 7.4.1 File Operation via Assistant Purpose: You can download or clear files here. Steps: Log in device via assistant. Click the Media Information tab. Figure 7. 14 Media Information Click All, Video, Audio, or Picture tab to select which file type you want to view. Check the checkboxes of files you want to download.
  • Page 35: File Operation In Usb Mode

    Body Camera User Manual Figure 7. 15 File Download Click the icon to select Local File Saving Path. Click OK to start downloading. Optionally, you can click the button in top right corner to view downloading status. Figure 7. 16 Downloading Status 7.4.2 File Operation in USB Mode Steps: Log in device via assistant.
  • Page 36: Device Configuration

    Body Camera User Manual Figure 7. 17 Dialog Box Enter Computer window to view the body camera. It will be recognized like an USB flash disk. Figure 7. 18 Devices with Removable Storage Double-click the disk to enter it and operate files. 7.5 Device Configuration 7.5.1 User Information Settings Purpose:...
  • Page 37: Encoding Parameters

    Body Camera User Manual 7.5.2 Encoding Parameters Purpose: You can set the parameters for video, including resolution, frame rate, bitrate, and so on. Steps: Click the Device Configuration tab, and click Device Information item in the left menu. Select Video Res.@Frame Rate, Net Transfer Res.@Frame Rate, Bitrate, and Net Transfer Bitrate from respective drop-down list.
  • Page 38: Wi-Fi Parameters

    Body Camera User Manual 7.5.4 Wi-Fi Parameters Purpose: You can access internet by connecting to a Wi-Fi. Wi-Fi parameters can only be configured in assistant. Steps: Click the Device Configuration tab, and click Network Settings item in the left menu list. Check the checkbox of Enable.
  • Page 39: Security Settings

    Body Camera User Manual In the situation of both dialing and Wi-Fi are connected, device prioritise access to internet through Wi-Fi. 7.5.6 Security Settings CHANGE THE DEFAULT PASSWORD The default password (123456) for the Admin account is for first-time log-in purposes only. You must change this default password to better protect against security risks, such as the unauthorized access by others to the product that may prevent the product from functioning properly and/or lead to other undesirable consequences.
  • Page 40: Formatting

    Body Camera User Manual Figure 7. 25 Platform Settings Check the checkbox of Enable to enable platform connection. Edit IP, Port, and Device ID.  IP: The IP address of platform server you want to connect.  Port: The port of platform. The default port of iVMS is 7660. ...
  • Page 41: System Resetting

    Body Camera User Manual 7.5.9 System Resetting Purpose: You can reset all parameters to default settings by resetting system. Steps: Click the Device Configuration tab, and click System Settings item in the left menu. Click the Factory Defaults button. Figure 7. 28 System Reset Input device password in the text field and click OK to start resetting.
  • Page 42: Assistant File Saving Path

    Body Camera User Manual Figure 7. 30 Log Information To search logs in a specified duration, do following steps: Edit the log’s start time and end time. Figure 7. 31 Search Condition Click the Search button to start search. The matched logs will be listed. To export searched logs, do following steps: Search the logs you want to export.
  • Page 43: Upgrading Device

    Body Camera User Manual Figure 7. 32 Local Configuration 7.8 Upgrading Device Purpose: It is recommended to upgrade device with the help of professional technical support. Steps: Switch to USB mode. For detailed steps, refer to 7.4.2 File Operation in USB Mode. Enter the Removable Disk of body camera through Computer.
  • Page 44 Body Camera User Manual Figure 7. 34 Exit and Switch Device...
  • Page 45: Chapter 8Troubleshooting

    Body Camera User Manual Chapter 8 Troubleshooting  Unable to start up. Possible Reason: Device runs out of power. Solution: Get device be charged. Possible Reason: Device is abnormal. Solution: Hold down the Sleep/Down button for 15 seconds to reset device. ...
  • Page 46 Body Camera User Manual Specifications Model DS-MH2111/32G DS-MH2111/32G/GLF Type CMOS, 16MP Sensor Lens Angel Horizontal FOV: 127° Display Displayer 2.0″ TFT LCD Video Input 1080p Recording 1080p/60fps, 720p/120fps, 704*480 Main stream: 1080p/60fps; Dual-Stream Sub-stream:720p/30fps Video Format .mp4 Picture Resolution Up to 16MP Video Picture Format .jpg...
