ADDON NWAR3650 Quick Installation Manual

For any further information on ADDON product, please visit our website: www.addon-tech.com
Indicator Status
Off The power is off.
Green The power is on and the device operates normally.
The power is self-testing.
Power
The device enters the console mode of the boot loader.
Red
The self-testing of the power fails if the LED is always red.
Blink Red Upgrading software.
Off No signal is detected.
ADSL Blink Green The DSL line is training.
Green The DSL line connection is established.
Off No internet connection.
Internet Green The users can access the Internet.
Red Device attempts to become IP connected but fails.
Off No Ethernet signal is detected.
LAN4/3/2/1 Blink Green The user data is passing through Ethernet port.
Green Ethernet interface is ready to work
Off No radio signal is detected.
WLAN Blink Green The user data is passing through.
Green WLAN interface is ready to work.
Off WPS service is not during using, or WPS service is setup successfully.
WPS
Blink Green The WPS service tries to establish.
Off No USB signal is detected.
USB Blink Green The user data is passing through USB port.
Green The USB interface is ready to work.
Description
1
