ADDON Magic r9000 Quick Installation Manual

Reset the Router's factory defaults by
hold the button pressed down for about
10 seconds.
Power on and off
button
For any further information on ADDON products, please visit our website:
Indicator
Power
WLAN
WPS
WAN
LAN1/LAN2/LAN3/LAN4
Power Port
WAN port is
The Power plug
for
is where you
connecting
will connect the
the router to
power adapter.
a cable/DSL
Modem.
Color Status
Green On Power is on.
- Off Power is off or the device is down.
Green Blink Data is being transmitted.
- Off Radio switch is shut off.
Green On Connection succeeds under Wi-Fi Protected Setup.
Green Blink Negotiation is in progress under Wi-Fi Protected Setup.
- Off Wi-Fi Protected Setup is disabled.
Green On Connection succeeds.
Green Blink Data is being transmitted.
- Off No WAN connection.
Green On LAN connection succeeds.
Green Blink Data is being transmitted.
- Off No LAN connection.
Press the button to active WPS
function.
4 x 10/100Mbps
Ethernet ports can
be connected to
Ethernet switch,
Ethernet router and
NIC card.
