CB 9 Series
Installation | Confi guration | Operation | Troubleshooting
Administrator Guide
800.205.7186
www.codeblue.com
•

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CB 9 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Code Blue CB 9 Series

Summary of Contents for Code Blue CB 9 Series

  • Page 1 CB 9 Series Installation | Confi guration | Operation | Troubleshooting Administrator Guide 800.205.7186 www.codeblue.com •...
  • Page 2 OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF. Code Blue Corporation reserves the right to make any modifications to this guide or the information contained herein at any time without notice. The software described herein may also be governed by the terms of a separate user license agreement.

  • Page 3: Table Of Contents

    11 CB 9-s with Dual Faceplates High Voltage Exploded View....16 12 How to Replace LED Light Connectors..........17 13 CB 9 Series Installation Instructions............19 14 CB 9 Series Tower Base Gasket Installation Instructions....21 15 CB 9 Optional WM-180 Installation Instructions........23 16 CB 9 Series Anchor Bolt Installation Instructions.........26 17 Remote Mount Beacon/Strobe Installation Instructions.......27...

  • Page 4: Introduction

    • Custom colors and graphics • Remote Mount LED Beacon/Strobe Kit This guide contains all of the CB 9 Series information for the CB 9-s and the CB 9-s Dual. This guide contains a general overview of the CB 9 Series options and its application, installation and wiring.

  • Page 5: Getting Started

    1. EIA/TIA, ANSI, CSA and BICSI cabling or similar standards shall be adhered to for proper operation of Code Blue communication devices connected to copper or fiber infrastructures. Communications cable and electrical cable in the same conduit is not an acceptable instal- lation and shall not be supported.

  • Page 6: Spare Parts

    41545 (2pk) Manifold R/B 5-way 40101 Analog Surge Suppressor 41471 IP Surge Suppressor 41421 Blank Lexan Plate Assembly 40067 CB 9 Series Additional Options Part Part Number Multi Tap Transformer 120V, 240V, 277V 40104 (powers accessories) Blank Lexan Plate Assembly 40067...

  • Page 7: Power Requirements

    CB 9 Series Administrator Guide 5 Power Requirements (2020) (The following power requirements include the 9 Series and also ALL OTHER Code Blue units.) Component Specs Faceplates Voltage Max Current Max Watts Norm Current Norm Watts KWHrs High V IA4100 24V AC 0.40...
  • Page 8 0.22 S-1050 LED Strobe w/ Photocell 24V AC 2.80 67.20 0.22 5.28 0.13 12V DC 2.68 32.16 0.38 4.56 0.11 CB 9 Series 24V DC 2.68 64.32 0.38 9.12 0.22 LED Light Bar 24V AC 0.04 0.96 0.04 0.96 0.02 12V DC 0.04...
  • Page 9 ® CB 4-u w/ NightCharge 0.22 120V AC 0.13 0.11 CB 9 Series 0.22 0.02 0.01 0.02 Administrator Guide 1.21 Power Requirements continued Models With IP5000 Faceplate Voltage Current Watts KWHrs CB 1-e 24V AC 0.33 7.92 0.19 12V DC 0.43...

  • Page 10: Legacy Power Requirements

    CB 9 Series Administrator Guide 6 Legacy Power Requirements (The following power requirements include the 9 Series and also ALL OTHER Code Blue units.) Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 10 of 39 GU-159-N •...
  • Page 11 CB 9 Series Administrator Guide Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 11 of 39 GU-159-N • • • •...

  • Page 12: Software Configuration

    A sophisticated emergency management platform for your blue light phone network, ToolVox offers unique real-time monitoring and provisioning options for emergency phones and public address speakers, effectively acting as a hub for connecting Help Points and other Code Blue devices. Us- ® ing our proprietary incident response software, Blue Alert MNS and EMS, you can send alerts via ®...

  • Page 13: Cb 9-S Low Voltage Exploded View

    CB 9 Series Administrator Guide 8 CB 9-s Low Voltage Exploded View BALL # PART # DESCRIPTION BALL # PART # DESCRIPTION 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP CALL Standard / Custom Graphic 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP...

  • Page 14: Cb 9-S High Voltage Exploded View

    CB 9 Series Administrator Guide 9 CB 9-s High Voltage Exploded View BALL # PART # DESCRIPTION BALL # PART # DESCRIPTION CALL Standard Graphic 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP CALL Custom Graphic 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP...

  • Page 15: Cb 9-S With Dual Faceplates Low Voltage Exploded View

    CB 9 Series Administrator Guide 10 CB 9-s with Dual Faceplates Low Voltage Exploded View BALL # PART # DESCRIPTION BALL # PART # DESCRIPTION CALL Standard / Custom Graphic 50104 Single Button IP5000 VoIP Phone – EMERGENCY 41471 Analog Surge Suppressor 50105 Double Button IP5000 VoIP Phone –...

  • Page 16: Cb 9-S With Dual Faceplates High Voltage Exploded View

    CB 9 Series Administrator Guide 11 CB 9-s with Dual Faceplates High Voltage Exploded View BALL # PART # DESCRIPTION BALL # PART # DESCRIPTION CALL Standard / Custom Graphic 50104 Single Button IP5000 VoIP Phone – EMERGENCY 41471 Analog Surge Suppressor 50105 Double Button IP5000 VoIP Phone –...

  • Page 17: How To Replace Led Light Connectors

    Administrator Guide 12 How to Replace LED Light Connectors As of 2020, Code Blue strobe, area and faceplate lights come with Wago connectors. These con- nectors provide ease of use and a much stronger connection. Below are the steps needed to change to the new connectors.
  • Page 18 CB 9 Series Administrator Guide Strip all wires and twist tight. Place small screwdriver into square hole and push down. Insert cut wire into round hole and remove screwdriver. Repeat on the rest of the connectors. Once all connectors have been switched, you are ready to apply power to the LED.

  • Page 19: Cb 9 Series Installation Instructions

    To accomplish this, use a small level and check all three directions. These nuts are not adjustable after the unit is in place. The bottom edge of the Code Blue unit will be ½-inch above the concrete when installed.
  • Page 20 CB 9 Series Administrator Guide Figure 1 All wiring must be installed and connected by experienced and certified personnel to meet local and national electrical codes, and will include a service disconnect. Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186...

  • Page 21: Cb 9 Series Tower Base Gasket Installation Instructions

    A small error will be magnifi ed after installation. 2.2 Set the Code Blue unit on the anchor bolts. Align the phone plate in the desired direction and lift the Code Blue unit over the anchor bolts. The unit may be lifted using the bracket on the inside of the unit.
  • Page 22 CB 9 Series Administrator Guide 3.0 Install the Base Gasket 3.1 Access the mounting studs through the access door on the side of the unit. 3.2 Set the gasket on the bolts and cut a small hole where the conduit is located.

  • Page 23: Cb 9 Optional Wm-180 Installation Instructions

    IP Controller board. Reference IA4100 Admin and User Guide for programming of analog controller board. Reference IP5000 Admin and User Guide for programming of IP controller board. Code Blue Guides are located at www.codeblue.com > support > downloads. WITHOUT CONTROLLER BOARD...
  • Page 24 CB 9 Series Administrator Guide Product wiring diagram shown reasonably represents current offering and is intended to assist in component identifi cation and service. Earlier product production may have different components and wiring connections. Reference the model and serial number from the unit ID tag and contact manufacturer to confi rm replacement part version and availability.
  • Page 25 CB 9 Series Administrator Guide 2.50 10.00 15.00 3.50 MTG HOLES 8.50 1.13 CONDUIT HOLE 4.05 2.05 7.50 BACK VIEW 20.10 15.12 10.40 Specifications subject to change without notice or obligation 1.13 CONDUIT HOLE on the part of the manufacturer.

  • Page 26: Cb 9 Series Anchor Bolt Installation Instructions

    1.3 Set the Anchor Bolts in the Wet Foundation – Four 24-inch L-shaped anchor bolts and an aligning template are supplied for anchoring the Code Blue unit. The bolts should be set into the foundation so that six inches are left showing above the finished grade level. The anchor bolts should be aligned, using the supplied template in such a way that the phone faceplate on the unit will face in the desired direction.

  • Page 27: Remote Mount Beacon/Strobe Installation Instructions

    CB 9 Series Administrator Guide 17 Remote Mount Beacon/Strobe Installation Instructions ATTACH J-BOX TO THE POLE Thread the banding (B) through the pole bracket (A) located on the backside of the J-box (C). Wrap the banding around the pole. Cut the banding to desired length.

  • Page 28: Poe Installation Instructions

    CB 9 Series Administrator Guide 18 PoE Installation Instructions PoE extractor. Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 28 of 39 GU-159-N • • • •...

  • Page 29: Cb 9 Series Deck Mount Installation Instructions

    CB 9 Series Administrator Guide 19 CB 9 Series Deck Mount Installation Instructions 1.0 DECK MOUNT FOUNDATION 1.1 Drill Deck Holes – Drill four holes through the deck or floor for the four 3/4” threaded rods. The holes should be aligned, using the template provided in such a way that the phone face- plate on the unit will face in the desired direction (see figure below).

  • Page 30: (Prior To 2015) (With Multi-Tap Power Brick)

    CB 9 Series Administrator Guide 20 CB 9 Series 24V or 120V Multi-Tap Power Brick Wiring (prior to 2015) Product wiring diagram shown reasonably represents current offering and is intended to assist in component identifi cation and service. Earlier product production may have different components and wiring connections.

  • Page 31: Cb 9 Series 24V Standard Wiring

    CB 9 Series Administrator Guide 21 CB 9 Series 24V Standard Wiring (after 2015) (with Fuse Block) (with Fuse Block) Product wiring diagram shown reasonably represents current offering and is intended to assist in component identifi cation and service. Earlier product Product wiring diagram shown reasonably represents current offering and is intended to assist in component identifi cation and service.

  • Page 32: Cb 9 Series 120V Standard Wiring

    CB 9 Series Administrator Guide 22 CB 9 Series 120V Standard Wiring (prior to 03/2013) (with Hammond Transformer) (with Hammond Transformer) Product wiring diagram shown reasonably represents current offering and is intended to assist in component identifi cation and service. Earlier product production may have different components and wiring connections.
  • Page 33 CB 9 Series Administrator Guide 23 CB 9-s/9-s Dual 120V Standard Wiring (after 2015) (with Triad Transformer) Product wiring diagram shown reasonably represents current offering and is intended to assist in component identifi cation and service. Earlier product production may have different components and wiring connections. Reference the model and serial number from the unit ID tag and contact manufacturer to confi rm replacement part version and availability.

  • Page 34: Multi-Tap Transformer Wiring

    CB 9 Series Administrator Guide 24 Multi-Tap Transformer Wiring Side of the Incoming Power from Primary Side of the Secondar Supplier Transformer Transformer Neutral Source L1 (White) Primary Volt Amps 250 Secondar olt Amps 160 ETL – UL ______________ Source L2 (Black)

  • Page 35: Maintenance Schedule

    CB 9 Series Administrator Guide 25 Maintenance Schedule LEGEND Guard tasks Technician tasks DAILY OR WEEKLY Perform functional communications check Action: Press red button Strobe activates  Red LED “Call Placed” light turns on  Message plays  Call connects, green LED “Call Received” light turns on ...
  • Page 36 Administrator Guide UNIT SURFACE MAINTENANCE The painted and stainless steel Code Blue models require periodic care to sustain their aesthetic appearance. Units located outdoors are vulnerable to harsh environmental conditions, including UV rays, acid rain, diesel fumes and airborn iron particles (i.e., dust) which over time may cause unit discoloring.

  • Page 37: Locating Unit Serial Numbers

    CB 9 Series Administrator Guide 26 Locating Unit Serial Numbers Remove the access plate cover with the special security bit. The serial number will be listed on the manufacturer’s label located on the backside of the access plate cover (1).

  • Page 38: Warranty

    Administrator Guide 27 Warranty Code Blue Corporation provides a limited warranty on this product. Refer to your sales agreement to establish the terms. In addition, Code Blue’s standard warranty language, as well as information regarding support for this product while under warranty, is available at www.codeblue.com/support.

  • Page 39: Download Information

    CB 9 Series Administrator Guide Download Information 28 Download Information Code Blue now has a centralized location where you can find installation, setup, information, configuration and operation instructions. ® 1. Centry Administrator Guide: www.codeblue.com/resources/guides 2. CB 1 Series Administrator Guide: www.codeblue.com/resources/guides...
